ML Knightsbridge SK005 Installation & Maintenance Manual

OPERATION
• Separate on/off switch for 13A sockets & USB
charger sockets
Swivel up silver lifting handle
and pull socket upwards
• Never force to lift up or push down the unit – always check that
there are no obstacles that could be interfering with the operation
of this product during extension and retraction
To open the socket, gently lift up the silver handle on the top cover
and pull the socket up until all socket outlets are exposed and the
stop/release button clicks and locks the unit into place (Fig.4) Press
the master switch at the base of the unit on. The unit is now ready
for use
To close the socket, press the stop/release button and push the unit
4
down until it is flush with surface. Appliances may be left plugged
into the socket when in the closed position
TO LIFT THE UNIT, ONLY USE THE SILVER HANDLE
Press
PLEASE NOTE THE IP54 RATING IS ONLY APPLICABLE WHEN
to release
NO PLUGS ARE ATTACHED TO THE DEVICE AND THE UNIT IS
IN ITS CLOSED POSITION FLUSH TO THE SURFACE
TROUBLESHOOTING
This socket contains a short circuit and overload protection feature. If there is no power from the USB
socket unplug the connected device. Check to ensure the USB socket and USB device have not come
into contact with water, liquid or debris and the cable to the device is not damaged. With no device
connected to the USB socket, it will automatically reset and be ready for use
We recommend using high quality USB charging cables as low cost options may cause compatibility
issues and may inhibit your device's ability to charge efficiently
ML Accessories Limited
LU5 5TA
www.mlaccessories.co.uk
SK005_INSTRUCTIONS.indd 1
Press
to release
09-14 V1 – BT
INSTALLATION & MAINTENANCE MANUAL
SK005
IP54 13A 2G POP UP SOCKET WITH DUAL USB CHARGER &
BLUETOOTH SPEAKER SYSTEM
IP
230V
54
50Hz
11
09/10/2014 15:08
