eletor Speed Control Series Instruction Manual

SPEED CONTROL - SERVOMOTOR
Microprocessor climate controller belonging to the SPEED CONTROL family. A reliable
device, easy to assemble and utilize with a software available in four build-in language
versions: Polish (default), English, German and Russian. Its programme allows the user
to intuitively set various parameters such as: the temperature, airing, heating, min/max
fan speed and the alarms.
Parameters and features:
Ventilation 1 stage
st
•
output current smooth regulation up to 5A
◦
thermal overload protection
◦
soft start
◦
minimal fan speed calibration
◦
Ventilation 2 nd stage, separated relay up to 3A (one to choose)
•
air heating, separated relay up to 3A (one to choose)
•
NO/NC alarm outputs
•
power outage signalling
◦
min/max temperature threshold exceedance signalisation
◦
one analog input for the temperature measurement
•
two 0-10V outputs
•
power consumption of <3W
•
IP56 hermetic enclosure
•
230V AC 50 Hz power supply voltage
•
ELETOR ELETOR, Zbiczno 43D, 87-305 Zbiczno, Poland, tel. 056 4939379
www.eletor.pl |
Instruction Manual
Climate controller with output
current permissible up to 5A
ELETOR SC-SERVOMOTOR
email:produkcja@eletor.pl
2019.08.14
