- Page 1 ALC-1809 LOUDSPEAKER CONTROLLER ALC-1809 AMPLIFIED LOUDSPEAKER CONTROLLER ADVANCED INSTALLATION AND PROGRAMMING GUIDE Rev A 191104 Theory ALC-1809 User Manual Rev A 191104...
-
Page 2: Table Of Contents
STEP 5 : FOLLOW STEPS 1 THRU 6 IN SURROUNDWIZARD TO CONFIGURE YOUR SYSTEM APPENDIX APPENDIX A - SPECIFICATIONS APPENDIX A - SPECIFICATIONS CONTINUED APPENDIX B - WARRANTY THEORY AUDIO DESIGN, LLC 3-Year Limited Warranty CONTACTING THEORY AUDIO DESIGN, LLC... -
Page 3: Important Safety Instructions
12. Use only attachments/accessories specified by THEORY AUDIO DESIGN, LLC. 13. Use only with hardware, brackets, stands, and components sold with the apparatus or supplied by THEORY AUDIO DESIGN, LLC 14. Unplug the apparatus during lightning storms or when unused for long periods of time. -
Page 4: Welcome
SUBWOOFER CHANNELS 0-1-2 Channels 0-1-2 of the ALC-1809 are rated at 300W (into 4-ohms) and are intended to drive subwoofers and full range speakers. Note that Channel 0, while it is an independent amplifier channel capable of driving subwoofers, the signal driving it is always the same signal that is routed to the Channel 1 output. -
Page 5: Components And Accessories (Front View)
ALC-1809 LOUDSPEAKER CONTROLLER COMPONENTS AND ACCESSORIES (FRONT VIEW) ALC UNIT RACK EAR (2) LCD DISPLAY DISPLAY NAVIGATION BUTTONS COMPONENTS... -
Page 6: Components And Accessories (Rear View)
ALC-1809 LOUDSPEAKER CONTROLLER COMPONENTS AND ACCESSORIES (REAR VIEW) RACK EAR (2) ALC UNIT EURO AUDIO INPUT/LOOP CONNECTOR (8) IEC US POWER CORD (1) EURO TRIGGER RESISTOR ACCESSORY EURO TRIGGER INPUT CONNECTOR (2) EURO-TO-XLR FEMALE ADAPTERS (8) EURO SPEAKER OUTPUT CONNECTOR (9) -
Page 7: Shelf Mounting
SHELF MOUNTING The ALC-1809 ships with small rubber feet attached to the chassis bottom panel allowing the unit to be placed on a shelf or table top when rack mounting is not desired. In this case, the rack ears may be removed and stored for later use, giving the unit a cleaner look. -
Page 8: Hardware Features
ALC-1809 LOUDSPEAKER CONTROLLER HARDWARE FEATURES 1 IN1 SUB15 SUB 1 2*IN1 SUB15 SUB 2 1 - LCD DISPLAY 2 - DISPLAY NAVIGATION BUTTONS ALC FRONT PANEL FRONT PANEL 1 - LCD DISPLAY The display will illuminate and text will appear when the ALC main power is turned on. Once the ALC has completed its initialization process, the display will show details about the ALC configuration and program- ming. - Page 9 DSP settings in addition to those shown on the LCD running on the channel in question. These controls include channel delay, up to five total predefined compensation filters, bass steering, automatic ducking, and customized parametric EQ. To view these settings, connect the ALC to Theory SoundTools™ software.
- Page 10 ALC-1809 LOUDSPEAKER CONTROLLER 1.5 - SPEAKER PROGRAM Column three of the display indicates the speaker program that is installed for the channel. From the factory, the ALC is pre-programmed with no speaker program and this column will display “DISABLED”. 1.6 - SPEAKER APPLICATION Column four of the display indicates the application (where within a surround sound system configuration the speaker is used, for example) of the speaker connected to the output (e.g.
-
Page 11: Rear Panel
ALC-1809 LOUDSPEAKER CONTROLLER 4 - POWER 2 - PROGRAMMING AND CONTROL 1 - STATUS INDICATORS 3 - INPUTS AND OUTPUTS ALC REAR PANEL REAR PANEL With the exception of the LCD display and display scroll buttons, all other features of the ALC-3316 can be found on the rear panel. -
Page 12: Status Area
ALC-1809 LOUDSPEAKER CONTROLLER We’ll now take a look at the features within each area individually. 2.4 TRIGGER LOOP OUTPUT 1.1 - STATUS INDICATORS 2.2 USB PORT 2.3 TRIGGER INPUT 2.1 - DISPLAY BACKLIGHT DEFEAT STATUS, PROGRAMMING AND CONTROL AREAS 1 - STATUS AREA 1.1 - ALC STATUS INDICATORS... - Page 13 ALC-1809 LOUDSPEAKER CONTROLLER 2.2 - USB PORT Connect the ALC to your computer at this port using the supplied mini USB cable. Microsoft Windows 10 will discover the ALC unit and install the required drivers. When doing this for the first time, this process may take a few minutes.
-
Page 14: Input/Output Area
ALC-1809 LOUDSPEAKER CONTROLLER 3.3 BRIDGED STATUS 3.1 ANALOG AUDIO INDICATORS INPUTS 3.4 LOUDSPEAKER OUTPUTS 3.2 ANALOG AUDIO LOOPING OUTPUTS INPUT/OUTPUT AREA 3 - INPUT/OUTPUT AREA 3.1 - BALANCED ANALOG AUDIO EURO BLOCK INPUTS Connect these balanced analog audio inputs to the post-processed analog audio output from your surround sound processor or audio preamp. - Page 15 3.4 - LOUDSPEAKER OUTPUTS Connect any Theory or Pro Audio Technology (PRO) passive loudspeaker system or bi or tri-amp speaker driver to these high-current Euro Block Connectors making sure to observe correct polarity. The terminal blocks will accept bare wire up to 10 gauge in size.
- Page 16 ALC-1809 LOUDSPEAKER CONTROLLER 4.2 MAIN POWER 4.1 AC POWER INLET SWITCH CAUTION: ON CHANNELS OPERATING IN BRIDGED (“BRIDGED TIED LOAD”, OR “BTL”) MODE, BOTH LOUDSPEAKER OUTPUT POSTS ARE CONNECTED TO HOT SIGNALS. DO NOT CONNECT ANY SPEAKER OUTPUT POST TO GROUND OR TO EACH OTHER, OR ALC DAM- AGE WILL RESULT.
-
Page 17: Alc Programming
ALC-1809 LOUDSPEAKER CONTROLLER ALC PROGRAMMING: THEORY SurroundWizard™ SOFTWARE ALC PROGRAMMING... -
Page 18: Programming Overview
“store” any information within the software itself. CONCEPT TO KNOW #3: Each time a Theory ALC is powered-up, the DSP chip is initially “empty” - it does not remember any of the filter settings or programs. At power-up, an on-board micro processor loads the DSP parameter settings from on-board ALC memory. - Page 19 CONCEPT TO KNOW #5: In order for a Theory ALC to “remember” DSP settings when powered off and then powered up again, your settings must be stored into the on-board flash memory so that they can be loaded by the microprocessor during the power-up “initialization”...
-
Page 20: Programming And Wiring Steps
STEP 3 : POWER ON ALC Connecting to a PC for the first time - Internet Connection Required If this is the first time you’ve connected a Theory ALC to your computer, Windows will need USB drivers to establish communication with it. -
Page 21: Step 4 : Download And Run Surroundwizard Software
ALC-1809 LOUDSPEAKER CONTROLLER STEP 4 : DOWNLOAD AND RUN SurroundWizard™ SOFTWARE Go to downloads.theoryaudiodesign.com/surroundwizard.exe to download and install SurroundWizard™ setup software. Once installed and with the ALC connected to the pc and powered on, run the software. The software layout is easy to follow and is intended to “be” the Quick Start User Guide - you can simply follow the steps shown in the software interface. -
Page 22: Step 5 : Follow Steps 1 Thru 6 In Surroundwizard To Configure Your System
5.1 - SELECT SURROUND SPEAKER LAYOUT The software needs to know your surround system layout. When you purchased your Theory surround system, you purchased a particular combination of loudspeakers and subwoofers that will comprise your system or speaker layout. The industry has adopted numerology to indicate these different surround sound system layouts in the format of: X.X.X... - Page 23 ALC-1809 LOUDSPEAKER CONTROLLER A small ATMOS system might have three loudspeakers on the front wall for Left, Center and Right, two subwoof- ers, with two surround speakers in the rear and two mounted overhead for ATMOS. That would be 5.2.2 Determine the layout of the system you purchased and select the appropriate button in the “SPEAKER LAY-...
- Page 24 The software now needs to know which loudpeaker and subwoofer models you purchased for each loudspeaker application. Using the drop-down lists, select the Theory loudspeaker and subwoofer models for each speaker location. 5.3 - MEASURE AND ENTER LOUDSPEAKER AND SUBWOOFER DISTANCES The software needs to know where your loudspeakers and subwoofers are located.
- Page 25 The software now needs to know which loudpeaker and subwoofer models you purchased for each loudspeaker application. Using the drop-down lists, select the Theory loudspeaker and subwoofer models for each speaker location. 5.3 - MEASURE AND ENTER LOUDSPEAKER AND SUBWOOFER DISTANCES The software needs to know where your loudspeakers and subwoofers are located.
- Page 26 ALC-1809 LOUDSPEAKER CONTROLLER the software interface. Note that flat profile (“zip cord” style) speaker wire will be easiest to use with the Theory soundbars and on-wall models when mounted to the wall as there is only 0.25” space between the back of the soundbar and the wall surface.
- Page 27 ALC-1809 LOUDSPEAKER CONTROLLER 5.7 - ADJUST SUBWOOFER TO OPTIMUM LEVEL Using the SurroundWizard subwoofer “TRIM” control, adjust the subwoofer level(s) carefully until you have optimized the subwoofer output to your preference across the widest range of source material. 5.8 - SAVE ALL SETTING IN LOUDSPEAKER CONTROLLER Once you’ve double and triple checked the wiring, verified speaker model designations and confirmed speaker...
-
Page 28: Appendix
ALC-1809 LOUDSPEAKER CONTROLLER APPENDIX APPENDIX... -
Page 29: Appendix A - Specifications
Audio Operation: 96kHz/24-bit On-Board DSP: 96kHz/32-bit DSP Features: Automatic Configuration of Surround System Settings Loudspeaker Processing For All Theory and PRO Models Input Trim Signal Routing Gain Delay (up to 75msec per channel) 80 Parametric EQ Filters Automatic Audio Ducking for Audio Zone Paging... -
Page 30: Appendix A - Specifications Continued
ALC-1809 LOUDSPEAKER CONTROLLER APPENDIX A - SPECIFICATIONS CONTINUED Bandwidth: 5.5Hz-40.6kHz, -6dB Frequency Response: 20Hz-20kHz, +/-0.2dB Amplifier Powers: Channels 0-1-2: 300W, 4-ohms Channels 3-8: 100W, 4-ohms, bridgeable to 300W* Voltage Gain: 30dB Input Sensitivity: Channels 0-2: 1.1V Channels 3-8: 660mV Power Requirements:... -
Page 31: Appendix B - Warranty
APPENDIX B - WARRANTY Disclaimer : THEORY AUDIO DESIGN, LLC is not liable for any damage to loudspeakers or any other equip- ment that is caused by negligence or improper use or installation of this product, including damage caused by connecting Theory loudspeakers and subwoofers to third party amplifiers. - Page 32 © 2019 THEORY AUDIO DESIGN, LLC. All rights reserved. Theory Audio Design routinely engages in programs to improve, modify and revise its products without notice or obligation. As such, your product may differ slightly from what is shown in this guide.
