Barko 830B Service Manual

Wheeled feller buncher (wfb)
Hide thumbs Also See for 830B:
Table of Contents

Advertisement

Quick Links

®
MANUAL P/N
SERVICE MANUAL
800-00479
REVISION
0
DATE
WHEELED FELLER BUNCHER (WFB)
06/07/2019
830B
Serial Number Range:
11983025001 thru
Machine Serial Number:
NOTE:
This Service Manual does not include safety, operation, or parts information. Seperate Oprator's and Parts Manuals are
available for this machine and can be purchased through your Barko dealer. The Operator's Manual include safety instructions
which must be read and understood before operating or servicing this machine. Keep the machine's Operator's Manual with
the machine at all times.
The information and illustrations in this manual have been approved as accurate at the time of printing. However, this manual
may contain information on options not present on your loader. The right is reserved by Barko Hydraulics, LLC to make
changes and improvements in its product at any time without notice or obligation.
Grapple and attachment information is not included in this manual. See separate Grapple and Attachment Owner's,
Installation, Parts and Service Manual(s) which accompanies all grapples from the factory.
®
1 Banks Avenue • Superior • WI • 54880
Phone: 800-544-6532 • 715-395-6700
Fax: 800-772-2448 • 715-392-9348
Web: www.barko.com Email: Support@barko.com
