- Page 1 AGITO AGITO OWNERS MANUAL Firmware Version: r3 Motion Impossible Ltd. www.Motion-Impossible.com +44 1454 501010 AGITO Owners’ Manual v1.0 Firmware r3...
-
Page 2: Document Revision History
AGITO DOCUMENT REVISION HISTORY REVISION: DATE: DESCRIPTION: July 2019 Initial Document Release – Firmware Release r3.0 www.Motion-Impossible.com Motion Impossible Ltd. AGITO Owners’ Manual v1.0 Firmware r3 +44 1454 501010... -
Page 3: Table Of Contents
Mode Switch ...................... 14 Menu ......................... 14 MASTER I/O Connections ..................... 14 Safety Functions ......................14 MASTER USER INTERFACE .................... 15 Menu Structure (Firmware r3) ..................15 Motion Impossible Ltd. www.Motion-Impossible.com +44 1454 501010 AGITO Owners’ Manual v1.0 Firmware r3... - Page 4 MASTER Controller Interface I/O Connectors ............36 RF Module Pass-through Box ................. 36 AGITO Tower Connections ................... 37 Further Support ......................38 Distributor Service Centres ..................38 www.Motion-Impossible.com Motion Impossible Ltd. AGITO Owners’ Manual v1.0 Firmware r3 +44 1454 501010...
-
Page 5: Introduction
DISCLAIMER Motion Impossible Ltd reserves the right to revise this Owner’s Manual and make changes from time to time without obligation to notify any persons of such revisions or changes. In no event shall Motion Impossible Ltd, its employees or authorized agents be liable for any damages or losses, direct or indirect, arising from the use of any technical or operational information contained in this document. -
Page 6: General Safety
By using AGITO, you acknowledge that you have read, understand, and agree to this disclaimer. You agree that you are solely responsible for your conduct while using AGITO and for any direct or indirect consequences that may result from its use. -
Page 7: Case Contents, Dimensions & Shipping Weights
Dimensions (HxWxD): Shipped Weight: CORE Case 550 x 820 x 430mm 32Kg Part Name 2x AGITO Sports Ends 4x Wheel Nuts Wheel Nut Spanner 4x Sports Lock-out Bars Motion Impossible Ltd. www.Motion-Impossible.com +44 1454 501010 AGITO Owners’ Manual v1.0 Firmware r3... -
Page 8: V-Con Pro
Tower Case Details will be updated when TOWER is released TRAX DRIVE-ENDS Dimensions (HxWxD): Shipped Weight: Trax Drive-Ends Cases (x2) Details will be updated when TRAX is released www.Motion-Impossible.com Motion Impossible Ltd. AGITO Owners’ Manual v1.0 Firmware r3 +44 1454 501010... -
Page 9: Agito Core Overview
AGITO 3. AGITO CORE OVERVIEW INTRODUCTION The CORE is the heart of your AGITO Modular Dolly System, within this module is contained all of the power management, RF and steering drivers. CORE DIMENSIONS 16x 3/8” threaded 1 inch/25.4mm pitch 460mm... -
Page 10: Core Rf Module Socket
Payload mounting is provided via the 2 mounting rails on each side of the chassis. The threaded holes are 3/8 inch spaced at 1-inch intervals. These allow for the fitting of all our current and future stabilisation / camera mounting solutions. www.Motion-Impossible.com Motion Impossible Ltd. AGITO Owners’ Manual v1.0 Firmware r3 +44 1454 501010... -
Page 11: Drive-Ends Overview
Sports Drive-Ends are our Free-roaming drive module, with multiple Wheel-type options: Dolly Wheel Multi-terrain Wheel Monster Wheel Track Wheel Snow-Trax Details to follow Details to follow TRAX DRIVE-ENDS Details to follow shortly Motion Impossible Ltd. www.Motion-Impossible.com +44 1454 501010 AGITO Owners’ Manual v1.0 Firmware r3... -
Page 12: Payload Overview
Mitchell Mount is a non-isolated fixture – further details to be released soon. V-CON STACKING RISERS Available as an option extra, the risers are designed to lift the V-Con up above the AGITO chassis – further details to be released soon. www.Motion-Impossible.com Motion Impossible Ltd. -
Page 13: Master Controller Overview
When turning on the MASTER Controller be careful not to press any button other than the power switch, specifically the Throttle Input. On start-up the controller runs through a calibration process, if the Throttle Input is not centered then the AGITO may accelerate unexpectedly. The calibration process finishes when the main menu screen appears. -
Page 14: Function Switch
FUNCTION SWITCH – Emergency Brake: In Firmware R3, this switch is set to Emergency Brake, switching this during operation will command the AGITO to stop as quickly as possible and hold the AGITO in position. There are three modes of operation, AUTO, UP & DOWN, these are explained later in the manual. -
Page 15: Master User Interface
Always ensure that AGITO is stationary and safely positioned prior to using Menus. INITIAL START-UP / CALIBRATION SCREEN This page gives the user the option to calibrate the steering of the AGITO, with or without maintaining any Trim adjustments. There is also the option to proceed without Calibration, we do not recommend skipping the Calibration process, but there are occasions when it may not be possible. - Page 16 MASTER. Operating AGITO with either a RED RF Signal Strength or Battery indicator is not recommended. Always resolve the issue before continuing with the use of AGITO.
-
Page 17: Drive-Ends Menu
OFF* stops the steering from switching ends. Maintaining the front end at all times. ON enables the steering end of the Agito to swap depending to the direction of movement. Invert Steering on Control the Steering direction behaviours when the chassis is Reverse reversing. -
Page 18: User Profiles Menu
Kilometres Per Hour Miles Per Hour Revolutions Per Minute Battery Icon Change how battery values are displayed: Image Voltage Readout* Percentage Select the PID turning you require: R2 Legacy www.Motion-Impossible.com Motion Impossible Ltd. AGITO Owners’ Manual v1.0 Firmware r3 +44 1454 501010... -
Page 19: Moves Menu
This page enables the Recording and Playback of repeatable moves. ITEM DESCRIPTION * denotes default value Record Select to begin recording a move Replay Select to begin replaying a saved move Motion Impossible Ltd. www.Motion-Impossible.com +44 1454 501010 AGITO Owners’ Manual v1.0 Firmware r3... -
Page 20: Setting Up Agito
Chassis and IMPERIAL tools for Drive-Ends and camera mount (3/8 Inch). AGITO is supplied with a tool kit which includes all of the necessary tools to perform all of the set-up’s and basic maintenance as outlined in this manual. Should any of these tools need replacing please see our recommendations below: Metric Hex Keys: 2.5mm, 3mm, 5mm... -
Page 21: Inserting Drive-Ends
Align the hexagons on the wheel and the shaft and slide in Using the supplied AGITO Wheel Nut Tool to screw on the wheel nut. Make sure it is tight (but take care not to damage the thread or nut) to prevent it coming loose whilst in motion. -
Page 22: Setting Wheel Tracking
Make sure these are tight and do not come loose. ALWAYS ensure the Payload is properly and securely fixed to the AGITO core, use a minimum of four fixture points. Always try to keep the payload over the centre of the chassis, especially when operating at high speeds. -
Page 23: Adjusting / Tuning V-Con Pro
While twisting the preload make sure you don’t unscrew the shock cap from the main shock body. Too High Correct Too Low Motion Impossible Ltd. www.Motion-Impossible.com +44 1454 501010 AGITO Owners’ Manual v1.0 Firmware r3... -
Page 24: Adjusting The Kick-Up
To remove the battery first pull back on the silver locking mechanism and then pull the battery towards the back of the chassis until it releases. Always run AGITO with two batteries that are of equal charge to ensure optimum run-times... -
Page 25: Attaching Payload: Tower
Details will be updated when the Tower is released (Due: August) ATTACHING PAYLOAD: MITCHELL MOUNT Details will be updated when the Mitchell Mount is released (Due: August) Motion Impossible Ltd. www.Motion-Impossible.com +44 1454 501010 AGITO Owners’ Manual v1.0 Firmware r3... -
Page 26: Configuring Agito
The MASTER will show the main menu screen. For more details see Section 7. If the AGITO is fully laden its good practice to slightly lift the AGITO while it performs this calibration. This will reduce unnecessary the wear of the steering actuators and tyres. -
Page 27: Throttle Mode
The Maximum Speed dial can be adjusted whilst AGITO is in motion, however if operating in ‘Encoded’ mode, the Maximum Speed will be capped at 500 rpm/ 2.20 mps / 6.0 kmh / 4.5 mph. -
Page 28: Braking And Emergency Stop Function
MOVES MODE This is AGITO’s repeatable moves option, here you can record a move, store a move, replay a move, recall and delete previously stored moves. You can record any number of moves, memory capacity is limited by time used, and gives over 30 mins of storage. -
Page 29: Operating Agito
10. OPERATING AGITO DRIVE DYNAMICS Setting up the AGITO to best suit your driving style and the requirements of the shot is essential. There are many user configurable software options, see Section 7, that combined with the hardware set-up, summarised in section 8, that will vary the drive dynamics. -
Page 30: Kick Up
AGITO Driving the AGITO along a 5-meter line will confirm that the alignment is correct, if the system does not follow the line check the mechanical tracking of the “front end”. Now reverse the AGITO back along the line, if the chassis does not follow the line accurately then double check the mechanical tracking, take note of the tracking of the “rear end”. -
Page 31: Firmware Updates
We recommend using a WINDOWS PC for all updates. Care should be taken to ensure that the computer and AGITO Core / Master Controller are not Do not unplug the MASTER or CORE from the PC or allow the battery to fail during the update unplugged during an update procedure. -
Page 32: Maintenance
Use BRAKE CLEANER (do not use WD40) to help remove any dirt / grit around the piston shaft. Check that no grit is present in the piston head. Now rebuild and re-mount the Shock to the Drive-end. www.Motion-Impossible.com Motion Impossible Ltd. AGITO Owners’ Manual v1.0 Firmware r3 +44 1454 501010... -
Page 33: Specifications, Dimensions & Connector Pin-Outs
30.1" 952mm 952mm 952mm Overall Length 37.5” 37.5” 37.5” 47.5Kg 47.5Kg 48.8Kg Weight (excluding Payload) 104.7lbs 104.7lbs 107.5lbs 20Kg Max Payload 44lbs Note: Conversion to imperial approximate Motion Impossible Ltd. www.Motion-Impossible.com +44 1454 501010 AGITO Owners’ Manual v1.0 Firmware r3... -
Page 34: Example Dimension Diagrams
IMPORTANT: Exact dimensions are specific to the modular configuration, the examples below are used for reference only. SPORTS DRIVE-END, WITH DOLLY / MULTI-TERRAIN WHEEL Length = 952mm SPORTS DRIVE-END, WITH MONSTER WHEEL www.Motion-Impossible.com Motion Impossible Ltd. AGITO Owners’ Manual v1.0 Firmware r3 +44 1454 501010... -
Page 35: Connector Pin-Outs
AUX 1 LEMO-EGG.2T.310.CLL LEMO-FGG.2T.310.CLAD72 AUX 2 LEMO-EGG.2T.310.CLL LEMO-FGG.2T.310.CLAD72 Connector Label Connector P/N Pin # Description Mating Connector P/N AUX 3 RS 862-1573 USB 2.0 Type B Plug Motion Impossible Ltd. www.Motion-Impossible.com +44 1454 501010 AGITO Owners’ Manual v1.0 Firmware r3... -
Page 36: Master Controller Interface I/O Connectors
Mating Connector P/N Data EGG.0B.304.CLL EGG.0B.304.CLAD52Z TX RS-232 Data RX RS-232 Data Connector Label Connector P/N Pin # Description Mating Connector P/N Power EGG.0B.302.CLL EGG.0B.302.CLAD52Z +12VDC 1A Max www.Motion-Impossible.com Motion Impossible Ltd. AGITO Owners’ Manual v1.0 Firmware r3 +44 1454 501010... -
Page 37: Agito Tower Connections
Connector P/N Pin # Description Mating Connector P/N Data pass- through (lower) Data pass- through (upper) Connector Label Connector P/N Pin # Description Mating Connector P/N Tower Ctl Motion Impossible Ltd. www.Motion-Impossible.com +44 1454 501010 AGITO Owners’ Manual v1.0 Firmware r3... -
Page 38: Further Support
AGITO FURTHER SUPPORT For technical documents, spares and assistance please visit www.motion-impossible.com/support Alternatively, you can contact Motion Impossible Customer Support on: Phone: +44 1454 501010 (UK Office Hours) Email: Support@Motion-Impossible.com 12 Brunel Court Dean Road Yate BRISTOL BS37 5NR United Kingdom DISTRIBUTOR SERVICE CENTRES Camadeus Film Technologies Inc., Los Angeles...
