Summary of Contents for METVISA BIMG RDA Series
- Page 2 IMG-BRASIL Gastronomy Machinery Industry Ltda. CNPJ 11.193.347/0001-14 - CREA 131726-3 Rod. Antônio Heil – KM 23 Nº 5825 – Bairro: Limoeiro – CEP 88352-502 - Brusque – SC – Brasil Phone/fax. +55 47 3251-5555 - Site: www.metvisa.com.br E-mail: sac@metvisa.com.br - export@metvisa.com.br - export2@metvisa.com.br...
-
Page 3: Table Of Contents
INDEX Safety Information ....................4 General Instructions ......................4 Mechanical Safety ......................5 Electrical Safety ......................... 6 Technical Specifications ..................6 Main Components ......................6 Technical Data ........................7 2.3 Supply and Disposal of Packing ..................8 Installation ......................8 Device Layout ........................ -
Page 4: Safety Information
1. Safety Information 1.1 General Instructions • There are care/precautions that should be observed when assembling, use, maintenance and discontinue using this device; • Before performing any operation (installation, use, maintenance and reuse after prolonged interruption in the use of the device), read the manual; •... -
Page 5: Mechanical Safety
1.2 Mechanical Safety • Never place fingers, hands or objects (as spoons or knifes) inside the Nozzle, it might cause an accident; • When cleaning the Disc while device is turned off, be careful. Discs are extremely sharpened and might cause an accident (cuts, for example) if not carefully handle. •... -
Page 6: Electrical Safety
1.3 Electrical Safety • Periodically check the condition of cables and electrical parts; • If the power cord is damaged it must be replaced by a new one. The exchange must be made by the manufacturer, authorized agent or a qualified person in order to avoid risks; •... -
Page 7: Technical Data
See below the main components of the Device: Note: To exploded drawing with spare parts list, see annexes. 2.2 Technical Data Nominal Nominal Measures Voltage Capacity Model Current WidthxHeightxLength Weight (kg/h) (mm) (kg) RDA127M605 RDA220M605 RDA110M604 RDA220M501 285x440x595 26,1 45** RDA220M502 RDA220M504 RDA220M604... -
Page 8: Supply And Disposal Of Packing
2.3 Supply and Disposal of Packing The device is packed with wood or cardboard, to ensure the perfect integrity during transportation and is accompanied by the following: • Instruction Manual for Installation, Maintenance, Use and Safety; IMPORTANT The packaging components (cardboard, wood, foam, foil, etc.) are products assimilable to urban solid waste and can be disposed off without difficulty. -
Page 9: Electrical Connection
WARNING! The installation and the place where it will be set must comply with the rules of prevention of risk and safety at work (Regulatory Standard NR-12 for Brazil or according to regulatory standard present on your country). The manufacturer is not responsible for possible direct or indirect damages caused by the non-compliance of the said rules and other instructions in this manual. -
Page 10: Security Measures And User Instructions
The Terminal Block shown on figure beside is an additional protection to the main supply grounding, it must be connected to a bar of Grounding Terminals, not depending on the main supply connection, other devices that have accessible metal parts and are stationary, must also be connected to this bar, as well as the workbench, if it is metallic. -
Page 11: Commands
4.2 Commands This device has a Voltage Selector Switch (multi-voltage devices) and On/Off Switch. The On/Off Switch is located on the left side of the device, when seen from Nozzle frontal. See description of each button: • On/Off Switch – used to turn on an off the device. In position "1" turn on, in position "0" turn off. 4.3 Operating Procedures Before operating your device, perform a cleaning of components that have contact with food (Tray, Nozzle, Discs, etc.), to do so make sure that the device is disconnected from the power outlet,... - Page 12 Check the assembly and disassembly procedure described below. • Disassembly: • Assembly: The assembly procedure is the reverse of removal. When remounting the Disc, choose the suitable Disc model to the process, mount it on the motor axle and turn until the Disc Notch (located behind the Disc) locks on the axle pin.
- Page 13 • Operation: The device can be operated only after verify if the Disc and the Nozzle are locked, and if the device’s voltage is the same as the mains. After verified all those items, follow the operation procedures: • Connect the power cord to the electrical outlet; •...
-
Page 14: Cleaning And Maintenance
IMPORTANT The operator must use the appropriate PPE (personal protective equipment). For example: use cap in hair preventing it from locking up in moving parts and appropriate gloves to guarantee hygiene when handling food, also protects the operator during the process. IMPORTANT The manufacturer is not responsible for possible direct or indirect damages caused by non- compliance with rules and instructions in this manual. -
Page 15: Procedures For Cleaning And Products To Be Used
The device must be cleaned as many times as possible, to prevent dry food waste from sticking on parts. For cleaning, dilute soap or mild detergent in warm water and apply with a soft cloth. With a cloth humidified with water rinse the device and then, dry the parts with a soft dry cloth. Never use products or abrasive sponges for cleaning, it may scratch or damage the surface of the pieces. -
Page 16: Prolonged Interruption In Use Of The Device
To detect any malfunction or nonconformity, send your device to the nearest service. See list of technical assistance in the link on our website: www.metvisa.com.br 5.3 Prolonged interruption in use of the Device When you have to leave the device stopped for a long period of time, disconnect it from the power outlet and clean it, including the different accessories. -
Page 17: Annex
6. ANNEX Wiring Diagram ATTENTION: The ground connection varies depending on the power cord plug. During installation observe the current regulatory standards of the country, in special about ground connection (if applicable). -
Page 18: Exploded Drawing
Exploded Drawing... -
Page 19: Spare Parts List
Spare Parts List Posição Código Descrição Quant. ETR142 Structure MTE204 Electric Motor 1/3 cv 60 Hz 127 V MTE205 Electric Motor 1/3 cv 60 Hz 220 V MTE030 Electric Motor 1/3 cv 50 Hz 220 V CJT548 Grater Disc CAB012 Nozzle EPR006 Mobile Cover... - Page 20 IMG-BRASIL Gastronomy Machinery Industry Ltda. CNPJ 11.193.347/0001-14 - CREA 131726-3 Rod. Antônio Heil – KM 23 Nº 5825 – Limoeiro CEP 88352-502 - Brusque – SC – Brazil Phone/fax. +55 47 3251-5555 - Site: www.metvisa.com.br E-mail: sac@metvisa.com.br - export@metvisa.com.br - export2@metvisa.com.br...
