Summary of Contents for Bell WALLABY
- Page 1 WALLABY CHILD TRAILER FITS KIDS EASY ASSEMBLY DOWNLOAD THE FREE APP Please keep these instructions for future reference. WARNING: Read manual carefully before use, and save to read again regularly.
- Page 2 If you have any questions about the assembly or use of this trailer, call our customer service department at 1-800-456-BELL. For the safety of your child, carefully read and follow these instructions and safety rules before operating your trailer.
- Page 3 Always fasten the harnesses to help reduce the chance of serious injury or death. The child’s seated height should remain below the upper crossbar. Make sure that under no circumstances can your child touch a moving wheel or the roadway. Also make sure your child cannot press the trailer fabric against the tire or wheel, which can cause burns.
- Page 4 Always ride defensively. Never assume you have the right of way. Do not travel on highways, very busy streets, or in areas unsafe for bicycling. A reflector that complies with CPSC regulations shall be visible on the rear of the trailer. Before each ride ensure the attached trailer does not interfere with the braking, pedaling, or steering of the bike.
-
Page 5: Part List
Canopy Safety Flag Upper Cross Bar This procedure will show you how to assemble your Wallaby Child Trailer. To complete, you will need an adjustable wrench unless your rear bicycle wheel has a quick release feature. STEP 1 Remove the... - Page 6 STEP 3 Repeat the previous step for the other three support posts. STEP 4 Rotate side panel to the upright position. Gently depress the two spring loaded buttons on the front and back, and insert the panel arms into the support posts until you hear a click.
- Page 7 STEP 8 Rotate the cross bar to align the pin holes with the holes in the brackets. Use the tethered locking pins to secure the cross bar by passing them through the aligned holes, then secure the locking pins in place. STEP 9 Lift the front panel of the foot bed into place, then...
- Page 8 STEP 12 With the trailer still on its side, insert one of the wheels into the axle hole. Push it gently until you hear it click into place. STEP 13 Rotate the trailer chassis to the opposite side. STEP 14 Insert the remaining wheel into the axle hole.
- Page 9 STEP 16 Position the canopy over the top of the trailer, making sure the reflector is to the rear of the trailer and the mesh screen window is to the front. STEP 17 Pass the hook and loop strap on the rear of the side panel through the buckle on the bottom of the canopy.
- Page 10 STEP 20 Insert the safety flag into its sleeve on the rear corner of the trailer “through canopy eyelet” STEP 21 Remove the black, quick release mounting bracket from the tow bar by disconnecting the locking pin. STEP 22 Remove the rear wheel bolt from your bike and place the mounting bracket onto the axle, then re-secure the...
- Page 11 STEP 24 The trailer is equipped with a safety strap that should always be used while towing the trailer. This is essential for the safety of your child. To use the safety strap, unclip it from the D-Ring and wrap it around the bike frame at its closest point, then securely hook the strap back onto the D-Ring.
-
Page 12: Using The Safety Harness
Note: If a single child is carried in the trailer, they can sit on either side if they weigh less than 50 pounds. If a single child is carried who weighs over 50 pounds, position them in the center of the trailer. See following details for proper seat belt use in these positions. - Page 13 When reinstalling the wheels, be sure you hear an audible click as they lock into place. Lever Congratulations! You’ve now completed the assembly of your Bell Wallaby Child Trailer!
- Page 14 WWW.THEBELLGARAGE.COM © 2017 BELL SPORTS INC. / 1-800-456-BELL 1001 INNOVATION ROAD / RANTOUL, IL 61866 USA MADE IN CHINA...
