Intaride INTA-650 Instructions

knob:
On/Volume
Twist the knob Clockwise to turn the radio ON. After a few seconds the radio will bleep and a voice will
announce the channel it is set to .
Twisting it fully anti-clockwise will turn the radio OFF
Twisting the knob clockwise will increase the volume, anti-clockwise will decrease the volume.
Channel Knob:
Twisting the knob clockwise will sequentially select between channels 1 to 16. Any channels not
programmed will result in continued bleeps to let you know that the channel is not programmed for use.
PTT Button:
This "Press To Talk - PTT" Button is located to the side of the radio. You need to press it firmly until a
RED LED shows on the top of the radio. Keep pressing whilst you speak and release when you finish
talking. It is good practice to press for about 1/2 second before you talk to allow the radio to go into
transmit mode and for the receiving radios to "wake-up" into receive mode.
Microphone:
The radio has a built-in microphone hidden below the speaker grille.
It is good practice to speak across the microphone rather than directly into it. This gives a far clearer
voice transmission.
1st Button below PTT:
This function button has been disables
nd
2 Button below PTT
This is a channel & battery level check button. A single press will give a audible report of which channel
Is selected. Double press for battery level report.
Battery pack:
To remove the battery pack, prise the small tab on the bottom of the battery outward.
To insert the battery is a reversal of the removal process.
Charging:
Plug the drop-in base into the charger adapter and plug into a suitable 230v ac mains socket and turn
the socket ON.
Place the radio or just the battery pack into the charger base, making sure that the battery pack
engages the lugs in the drop-in compartment.
The light will go red until the radio is charged, whereupon the light will go green.
Average charging time for a fully discharged battery is about 4 hours.
INTA-650 Radio
Instructions
