Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2019 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
56936
Battery and charger sold separately
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
56939
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
19k
Advertisement
Table of Contents
Related Manuals for Atlas 56936
Summary of Contents for Atlas 56936
- Page 1 (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. 56936 56939 Battery and charger sold separately Visit our website at: http://www.harborfreight.com...
- Page 2 13. Store idle appliances indoors - When not in use, work boots to help prevent injury appliances should be stored indoors in dry, and caused by flying debris. high or locked-up place - out of reach of children. Page 2 For technical questions, please call 1-888-866-5797. Item 56936 56939...
- Page 3 4. Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire. Item 56936 56939 For technical questions, please call 1-888-866-5797. Page 3...
- Page 4 7. To reduce vibration, maintain the appliance tingling, numbness, and white or blue fingers), as explained in this manual. If any abnormal seek medical advice as soon as possible. vibration occurs, stop use immediately. Page 4 For technical questions, please call 1-888-866-5797. Item 56936 56939...
- Page 5 No Load Revolutions per Minute (RPM) Risk of Electric Shock. Properly connect Charger’s power WARNING marking concerning Risk cord to appropriate outlet. of Eye Injury. Wear ANSI-approved safety goggles with side shields. Item 56936 56939 For technical questions, please call 1-888-866-5797. Page 5...
- Page 6 Specifications 56936 56939 Atlas Li-Ion 40V (57008) or Atlas Li-Ion 40/80V (57014) Battery Type 40/80V (57014) (sold separately) (sold separately) Charger Type 56993 or 56997 Atlas Li-ion No Load Speed 6000 RPM Replacement Line Type .080″ Nylon ambient temperature ranges Operation 6.8 - 104°F...
- Page 7 Guard WarninG! tO prEVEnt SEriOuS inJury FrOM FLyinG DEBriS: install the guard only in the orientation shown. 56936 Guard attachment: 1. Turn Trimmer Head upside down and 3. Align holes on the Guard with holes on Trimmer remove two Screws from head.
- Page 8 3. Adjust Handle to desired position from Auxiliary Handle. and tighten Screws to secure. 2. Place Auxiliary Handle and Clamp onto the shaft and use Screws to connect together. Screws auxiliary Handle clamp Page 8 For technical questions, please call 1-888-866-5797. Item 56936 56939...
- Page 9 • Remove battery pack. 3. DO nOt rESt triMMEr On GrOunD. • Wipe external surfaces of the appliance with clean cloth. Store in an indoor dry area out of reach of children. Item 56936 56939 For technical questions, please call 1-888-866-5797. Page 9...
- Page 10 2. Press both tabs marked ‘Push’ on the Trimmer Head to release Spool Cover. Spool cover Spool trimmer Head 4. Clean interior of Trimmer Head with soft cloth. 5. Replace Spool. 6. Replace Spool Cover. Page 10 For technical questions, please call 1-888-866-5797. Item 56936 56939...
- Page 11 8. Turn Spool counterclockwise to feed line into Spool Trimmer Head. Leave 5″ of line on each side. nOticE: For best performance with 56936, use a line that is .080″ in diameter and no more than 13’ in length. For 56939, use a line that is .095″...
- Page 12 List and Diagram 56936 parts List part Description part Description Hex Socket Screw Hex Socket Screw Right Handle Right Housing Heat-Shrink Tube Wire Retaining Plate Heat-Shrink Tube Speed-Control Switch Male Terminal Assembly Dust Sponge Left Handle Volute Motor Connector...
- Page 13 56936 assembly Diagram Item 56936 56939 For technical questions, please call 1-888-866-5797. Page 13...
- Page 14 Fan Blade Ring Rubber Pad Head Assembly Wire Retaining Plate Ribbon Heat-Shrink Tube Heat-Shrink Tube Corrugated Pipe Heat-Shrink Tube Bolt note: Parts may not be interchangeable. Specify item number when ordering. Page 14 For technical questions, please call 1-888-866-5797. Item 56936 56939...
- Page 15 56939 Diagram Item 56936 56939 For technical questions, please call 1-888-866-5797. Page 15...
- Page 16 Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
