- Page 1 ESP8266-DevKitS User Guide Version 1.0 Espressif Systems Copyright © 2020 www.espressif.com...
- Page 2 About This Guide This user guide provides information on ESP8266-DevKitS-development board. Release Notes Date Version Release notes 2020.02 V1.0 Initial release. Documentation Change Notification Espressif provides email notifications to keep customers updated on changes to technical documentation. Please subscribe here.
-
Page 3: Table Of Contents
Tables of Contents 1. Overview ..........................2. Functional Description ......................3. How to Flash a Board ......................3.1. Hardware Preparation ........................ 3.2. Hardware Setup ......................... 3.3. Software Setup .......................... 4. Board Dimensions ......................... 5. Hardware Reference ......................5.1. Block Diagram .......................... -
Page 4: Overview
ESP8266-DevKitS is Espressif’s flashing board designed specifically for ESP8266. It can be used to flash an ESP8266 module without soldering the module to the power supply and signal lines. With a module mounted, ESP8266-DevKitS can also be used as a mini development board like ESP8266-DevKitC. -
Page 5: Functional Description
2. Functional Description Functional Description Figure 2-1. ESP8266-DevKitS This chapter introduces key components, interfaces and controls of ESP8266-DevKitS development board: • Spring Pins Connect and fix the module. These spring pins fit castellated holes on the module. • 2.54 mm Female Headers Connect to jumper wires and other development boards. - Page 6 2. Functional Description • 5V-to-3.3V Low dropout voltage regulator (LDO). • Boot Button Download button. Holding down the Boot button and pressing the EN button initiates the firmware download mode. Then users can download firmware through the serial port. • Micro USB Port/Micro USB Connector USB interface.
-
Page 7: How To Flash A Board
1 x PC loaded with Windows, Linux or Mac OS • 3.2. Hardware Setup Please mount a module of your choice onto your ESP8266-DevKitS according to the following steps: Gently put your module on the ESP8266-DevKitS board. Make sure that castellated •... -
Page 8: Board Dimensions
4. Board Dimensions Board Dimensions Figure 4-1. Board Dimensions Espressif ! /9 2020.02... -
Page 9: Hardware Reference
5. Hardware Reference Hardware Reference 5.1. Block Diagram Figure 5-1. ESP8266-DevKitS Block Diagram 5.2. Power Supply Options There are three mutually exclusive ways to provide power to the board: • Micro USB port, default power supply • 5V and GND header pins •... - Page 10 5. Hardware Reference CHIP_EN GPIO14 GPIO12 GPIO13 GPIO15 GPIO2 GPIO0 External 5V GPIO16 U0TXD U0RXD GPIO4 EXT_RSTB GPIO5 To TOUT after a voltage divider Espressif ! /9 2020.02...
-
Page 11: Appendix-Learning Resources
Resources A.1. Must-Read Documents ESP8266-DevKitS Reference Design • Description: This zip package include ESP8266-DevKitS schematics, PCB layout, gerber and BOM files, and spring design files. ESP8266 Quick Start Guide • Description: This document is a quick user guide to getting started with ESP8266. It includes an introduction to the ESP-LAUNCHER, how to download firmware on to the... -
Page 12: Must-Have Resources
Appendix A ESP8266 Hardware Resources • Description: This zip package includes manufacturing specifications of the ESP8266 board and the modules, manufacturing BOM and schematics. ESP8266 AT Command Examples • Description: This document introduces some specific examples of using Espressif AT commands, including single connection as a TCP Client, UDP transmission and transparent transmission, and multiple connection as a TCP server. - Page 13 Disclaimer and Copyright Notice Information in this document, including URL references, is subject to change without notice. THIS DOCUMENT IS PROVIDED AS IS WITH NO WARRANTIES WHATSOEVER, INCLUDING ANY WARRANTY OF MERCHANTABILITY, NON-INFRINGEMENT, FITNESS FOR ANY PARTICULAR PURPOSE, OR ANY WARRANTY OTHERWISE ARISING OUT OF ANY PROPOSAL, SPECIFICATION OR SAMPLE.
