- Page 1 POWERCUBE User Manual...
-
Page 2: Table Of Contents
POWERCUBE User Manual Content Statement of Law ............................. 1 Safety Precautions ............................ 2 Preface ..............................3 1 Introduction ............................1 1.1 Brief Introduction .......................... 1 1.2 Product Properties ........................1 1.3 Product identity definition ......................1 2 Product Specification ..........................3 2.1 Size and Weight .......................... -
Page 3: Statement Of Law
Customer can check the related information on the website of Jiangsu Daqin New Energy Technology Co., Ltd when the product or technology is updated. Web URL：http://www.dyness.net/ Please note that the product can be modified without prior notice. Revision History Revision NO. -
Page 4: Safety Precautions
POWERCUBE User Manual Safety Precautions Warning ⚫ Please do not put the battery into water or fire, in case of explosion or any other situation that might endanger your life. ⚫ Please connect wires properly while installation, do not reverse connect. ⚫... -
Page 5: Preface
This user manual describes 4Box, 5Box, and 6Box in the Powercube series. It details the basic structure, parameters, installation, and operation and maintenance of the equipment. -
Page 6: Introduction
1.2 Product Properties Powercube series energy storage product’s anode materials are lithium iron phosphate, battery cells are managed effectively by BMS with better performance, the system feature as below: ⚫... - Page 7 POWERCUBE User Manual After the battery life is terminated, the battery can continue to be used after it recycled by the professional recycling organization and do not discard it at will. This battery product meets European directive requirements. This battery product passed the TUV certification test.
-
Page 8: Product Specification
POWERCUBE User Manual 2 Product Specification 2.1 Size and Weight Table 2-1 Powercube series Device Model Nominal Nominal Dimension Weight Product Product Series Voltage Capacity (mm) (kg) Level Powercube Powercube-4BOX DC48V 296Ah 492×600×862 ≈183 IP65 Powercube Powercube-5BOX DC48V 370Ah 492×600×862 ≈215... -
Page 9: Battery Management System(Bms)
POWERCUBE User Manual Table 2-3 Interface Definition Item Name Definition RJ45 network cable Reserve connector RJ45 network cable CAN/RS485 communication interface (Factory default connector CAN communication mode) Total negative cable The battery DC output negative pole waterproof connector Total positive cable The battery DC output positive pole waterproof connector 2.4 Battery Management System(BMS) -
Page 10: Temperature Protection
POWERCUBE User Manual Protection is over after rated time delaying. Over Current Protection in Discharging： Device stops discharging when discharging current exceeds the protection value. Protection is over after rated time delaying. 2.4.3 Temperature Protection Less/Over temperature protection in charging： When battery’s temperature is beyond range of 0 ℃... -
Page 11: Installation And Configuration
POWERCUBE User Manual 3 Installation and Configuration 3.1 Ready for installation Safety Requirement This system can only be installed by personnel who have been trained in the power supply system and have sufficient knowledge of the power system. The safety regulations and local safety regulations listed below should always be followed during the installation. -
Page 12: Technical Preparation
POWERCUBE User Manual Inclined pliers Insulating tape Needle nose pliers The thermometer Clip forceps Wrist strap Wire stripper AVO meter Electric drill Tape 3.1.3 Technical preparation Electrical interface check Devices that can be connected directly to the battery can be user equipment, power supplies, or other power supplies. - Page 13 POWERCUBE User Manual Quantity Item Specification Figure 4Box 5Box 6Box 492×600×862mm Cabinet 492×600×1000mm 48V/74Ah Battery-B4874 384×481×130mm Positive parallel Orange cable of battery /25mm /L115mm module Orange /25mm /L3250mm Total positive cable Orange /25mm /L3400mm Negative parallel Orange cable of battery /25mm /L115mm module...
-
Page 14: Engineering Coordination
POWERCUBE User Manual 3.1.5 Engineering coordination Attention should be paid to the following items before construction: ⚫ Power line specification. The power line specification shall meet the requirements of maximum discharge current for each product in table2-2. ⚫ Mounting space and bearing capacity. Make sure that the battery has enough room to install, and that the battery rack and bracket have enough load capacity. -
Page 15: Electrical Installation
POWERCUBE User Manual 2. Place the B4874 unit on the cabinet bracket as shown in the figure and push it into the cabinet to the installation position. Figure3-2 3. Fix the B4874 unit in the cabinet with nuts through the mounting holes top on the hanging ears of the B4874 module chassis. - Page 16 POWERCUBE User Manual Caution Note: If you have any questions during installation, please contact your dealer to avoid damage to the equipment. 1. Install the power cable Install the negative parallel cables and the positive parallel cables as shown in Figure 3-4, then connect the positive cable and the total negative cable.
- Page 17 POWERCUBE User Manual Inverter Circuit breaker External CAN communication line 2 Total negative Total cable positive cable External CAN communication line 1 Negative Positive parallel cable parallel cable Internal CAN communication Figure 3-4 Wiring diagram line...
- Page 18 POWERCUBE User Manual Table 3-3 Battery& Inverter power matching table B4850 B4874 Inverter Power System System Parallel Powercube Parallel Powercube Energy Energy number Type number Type (kWh) (kWh) Powercube- 7.5-10.0 5Box Powercube- 10.0-12.5 12.0 5Box Powercube- Powercube- 12.5-15.0 14.4 14.21 6Box 5Box Powercube-...
-
Page 19: Use, Maintenance And Troubleshooting
POWERCUBE User Manual 4 Use, maintenance and troubleshooting 4.1 Battery system usage and operation instructions After completing the electrical installation, follow these steps to start the battery system. Press the ON/OFF button to the ON position, press and hold the SW button for 3 seconds. -
Page 20: Analysis And Treatment Of Common Faults
POWERCUBE User Manual please deal with it according to Table 4-1. Table 4-1 Main alarm and Protection Alarm Statue Alarm category Processing indication Stop charging and find out Cell over-voltage the cause of the trouble Charging Stop charging and find out state Over-current the cause of the trouble... - Page 21 Jiangsu Daqin New Energy Tech Co., Ltd Address: 158# South Ji'an Road, Hi-Tech District, Yangzhou City, Jiangsu Province, China, 211400. Email: Sales@dyness.net Website: www.dyness.net...
