NON-INTERLOCKED HOUSING WARNING
This unit contains high power laser devices internally. Do not open the
laser housing, due to potential exposure to unsafe levels of laser radiation.
The laser power levels accessible if the unit is opened can cause instant
blindness, skin burns and fires.
LASER EMISSION DATA
Laser Classification
Green Laser Medium
Red Laser Medium
Beam Diameter
Pulse Data
Divergence (each beam)
Divergence (total light)
Laser Power
As measured under IEC measurement conditions for classification.
Version: 3.0
This manual contains important laser operation information. Read and
understand all instructions prior to powering on laser unit the first time, to
avoid laser eye injury and to avoid breaking the law. Keep this manual in a
safe place for future reference.
Class 3B
DPSS Nd:YVO4, 532nm
650nm LD
<5mm at aperture
All pulses < 4Hz (>0.25sec)
<2 mrad
<160 degrees
Red>100mW, Green>30mW
Advertisement
Table of Contents
Related Manuals for CR-Tec CR-Laser Fit-F
Summary of Contents for CR-Tec CR-Laser Fit-F
- Page 1 NON-INTERLOCKED HOUSING WARNING This unit contains high power laser devices internally. Do not open the laser housing, due to potential exposure to unsafe levels of laser radiation. The laser power levels accessible if the unit is opened can cause instant blindness, skin burns and fires.
-
Page 2: Product Overview
USER MANUAL PRODUCT OVERVIEW This device has left out premises in absolutely perfect condition. In order to maintain this condition and to ensure a safe operation, it is necessary for the user to follow the safety instructions and warning notes written in this manual. -
Page 3: Control & Function
USER MANUAL NAME DESCRIPTION Power LED Indicates the fixture is switched on Music LED Synchronize to detected music signal The laser effect output aperture. NEVER LOOK Laser Aperture INSIDE THE FIXTURE THROUGH THIS APERTURE WHILE FIXTURE IS OPERATING. Power Switch Switch ON and OFF the fixture Fuse Holder The replaced fuse is hold here... - Page 4 USER MANUAL Operation Stand Alone Preprogram Laser Show Press FUNC to enter MODE OPTION. Till to LED panel shows either one of Aut, Aup, Aud & Sou. Press UP or DOWN to select your favorite Stand Alone mode as above. Press ENTER to confirm the setting.
-
Page 5: Master/Slave Mode
USER MANUAL SOUND ACTIVATED MODE sensitivity setting Press FUNC till to see S 6 Press UP/DOWN to set microphone sensitivity. S 0 is no sound activated, from S 1 to S 9, the sensitivity level is going more sensitive. Press ENTER to confirm and save the setting. MASTER/SLAVE MODE Press FUNC to enter MODE OPTION Till to LED panel shows SLA... -
Page 6: Dmx Protocol
USER MANUAL DMX PROTOCOL DMX VALUE DESCRIPTION CANNEL Laser Block Out 000-019 020-075 ARA Mixed Effect Auto Mode 076-131 SRA Sound Activated Mixture Mode CH 1 MODE 132-188 SOD Sound Activated Moving Dots Mode 189-239 SOP Sound Activated Firework Mode 240-255 DMX MODE 000-036... -
Page 7: Specifications
USER MANUAL SPECIFICATIONS Mains Input: AC100-240V, 50/60Hz Fuse: 250V 1A Slow Blow (20mm Glass) Total Power: Music Control: Internal microphone Laser Power: 100mW-R + 30mW-G CW Laser Classification: Class 3B Laser Safety Standard: EN60825-1 2007 Condition Temperature: 10~40℃ DMX Connections: 3 pins XLR Male/Female DMX Channels 8 channels...
