Lectrosonics MTCR Instruction Manual

Miniature time code recorder

Advertisement

Quick Links

MTCR
Miniature Time Code Recorder
microSDHC Logo is a trademark of SD-3C, LLC
Fill in for your records:
Serial Number:
Purchase Date:
INSTRUCTION MANUAL

Quick Start Steps

1) Install good battery and turn the power on (p. 3, 6).
2) Insert microSDHC memory card and format it with
the MTCR (p. 3, 4).
3) Timecode jam source (p. 7, 8).
4) Connect microphone or audio source.
5) Set input gain (Mic Level p. 8).
6) Select record mode (p. 9).
7) Set output level (HP Volume p. 8).
8) Begin recording (p. 5-9).
CAUTION: See card formatting
warning on page 4.
Rio Rancho, NM, USA
www.lectrosonics.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MTCR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lectrosonics MTCR

  • Page 1: Quick Start Steps

    Quick Start Steps 1) Install good battery and turn the power on (p. 3, 6). 2) Insert microSDHC memory card and format it with the MTCR (p. 3, 4). 3) Timecode jam source (p. 7, 8). 4) Connect microphone or audio source.
  • Page 2: Table Of Contents

    Versatility The MTCR can be tethered to a camera to capture a higher quality or backup audio recording. The input connector is the industry standard TA5M jack that accepts any mic or line level signal, and provides bias voltage to power a wide variety of electret lavaliere microphones.
  • Page 3: Battery Installation

    The audio recorder is powered by a single AAA Lithium battery for 6 hours of operation. Please note that the MTCR and SPDR are designed Zinc-carbon batteries marked “heavy-duty” or “long- for use with the microSDHC memory cards. There are lasting”...
  • Page 4: Installing The Card

    Extension) wave format which has sufficient data space in the header for the file information and the time code imprint. The SD card, as formatted by the MTCR, can be cor- rupted by any attempt to directly edit, change, format or view the files on a computer.
  • Page 5: Features And Controls

    HOLD HOLD Recovery screen will appear. If there is no card in the MTCR or the card is not prop- erly formatted, the Main Window appears. Settings are accessed by pressing MENU/SEL on the keypad, and then using the UP and DOWN arrow buttons and BACK button to navigate the menu items and select functions.
  • Page 6: Operating Instructions

    Menu, Info If any samples are lost during recording, a warning (available recording time if SD card installed, MTCR info screen will appear displaying “slow card.” Typically the if no card in unit), and the REC (record start) and LAST lost audio is less than 10 milliseconds and is barely no- (play last clip) functions.
  • Page 7: Navigating Menus

    Use arrow keys to select Press to set Remote BACK analog or digital BACK function (For information Rev: v2.00 About MTCR purposes only.) BACK Restore defaults? Default Use arrow keys to return BACK to default settings Rio Rancho, NM...
  • Page 8: Timecode

    File naming can be set as: • Sequence: a progressive sequence of numbers Choose to use the clock provided in the MTCR as opposed to a timecode source. Set the clock in the Set- • Clock Time: the time of the internal clock at the tings Menu, Date &...
  • Page 9: Settings

    WARNING: Since the real time clock/calendar browser. can be manipulated and/or stop with loss of 2) Copy the MTCR v1_xx.ldr file to the memory card, power, it should not be relied upon for accurate then safely eject the card from the computer.
  • Page 10: Recovery Process

    If “No” is chosen, nothing is done to the card and • Yes the MTCR will not use the card. If “Yes” is chosen”, a prompt appears asking for the length of the recording If you wish to record audio on the card, you must to recover, specified as a number of hours and minutes.
  • Page 11: Copying Recordings To A Computer

    Portable Digital Recorder Copying Recordings to a Computer 1. Remove your MicroSD card from the MTCR by lightly pressing inward on the card and, when released, the card should pop out of the recorder enough to remove it. Write Protect Tab 2.
  • Page 12: Pdrremote

    • Mic Gain Level arrow to select mode • Lock/Unlock The MTCR tones are unique to the MTCR and will not react to “dweedle tones” meant for Lectrosonics transmitters. The screens appear differently for iOS and Android phones, but perform the same functions.
  • Page 13: 5-Pin Input Jack Wiring

    If this occurs please call voltage source for 4 volt servo bias wiring. our toll-free number listed under Service and Repair in this manual or visit: www.lectrosonics.com/US PIN 3 Microphone level input and bias supply. +5 VDC PIN 4 Bias voltage selector for Pin 3.
  • Page 14: Microphone Cable Terminationfor Non-Lectrosonics Microphones

    The shield contact reduces noise with some microphones and the insulation clamp increases ruggedness. NOTE: This termination is intended for UHF transmitters and the MTCR only. VHF transmitters with 5-pin jacks require a different termination. Lectrosonics lavaliere microphones are terminated for compatibility with VHF and UHF transmitters, which is different from what is shown here.
  • Page 15: Wiring Hookups For Different Sources

    In addition to the microphone and line level wiring hook- A lot of information regarding microphone wiring is also ups illustrated below, Lectrosonics makes a number of available in the FAQ section of the web site at: cables and adapters for other situations such as con- http://www.lectrosonics.com...
  • Page 16: Included Accessories

    MTCR Included Accessories Additional Accessories 55010 microSDHC memory card; Speed Class 10; UHS MC35 line level adapter cable. Female XLR to female Speed Class 1; UHS Speed Class I TA5F; 37 inches long. Feed line level signal to pin 5 on the TA5M jack.
  • Page 17: Specifications

    Portable Digital Recorder Specifications Available Recording Time Using a microSDHC memory card, the available re- Recording cording times are as follows. The actual time may vary Storage media: microSDHC memory card* slightly from the values listed in the tables. File format: .wav files (BWF - Broadcast Wave File) HD mono mode Split gain mode...
  • Page 18 MTCR LECTROSONICS, INC.
  • Page 19: Service And Repair

    LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In warranty repairs are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a modest flat rate plus parts and shipping.
  • Page 20 This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
