Lectrosonics SPDR Instruction Manual

Stereo portable digital recorder

Advertisement

Quick Links

SPDR
Stereo Portable Digital Recorder
Fill in for your records:
Serial Number:
Purchase Date:
INSTRUCTION MANUAL
Quick Start Steps
1) Install batteries (or connect to external power) and
turn the power on (p. 5).
2) Insert microSDHC memory card and format it with
the SPDR (p. 6).
3) Jam to a timecode source, if needed.(p. 10).
4) Connect microphone or audio source (p. 7).
5) Set input type and level, if analog source (p.12).
6) Select record mode (p. 11).
7) Set output level (HP Volume p. 10).
8) Begin recording (p.8).
microSDHC Logo is a
trademark of SD-3C, LLC
Rio Rancho, NM, USA
www.lectrosonics.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPDR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lectrosonics SPDR

  • Page 1 1) Install batteries (or connect to external power) and turn the power on (p. 5). 2) Insert microSDHC memory card and format it with the SPDR (p. 6). 3) Jam to a timecode source, if needed.(p. 10). 4) Connect microphone or audio source (p. 7).
  • Page 2 SPDR LECTROSONICS, INC.
  • Page 3: Table Of Contents

    Timecode ................10 Inputs ..................10 HP Volume ................10 Scene & Take ..............10 SD Card ................10 Settings ................11 About SPDR ................11 Default .................11 Operating Instructions ............12 Recording in Analog Mode ..........12 Recording in Digital Mode ...........12 Browsing/Playing Back Recordings ........13 Copying Recordings to a Computer ........14 Recovering an Interrupted Recording .........14...
  • Page 4: Technical Highlights

    At 96 kHz, the microSDHC memory card will be used up The SPDR can be tethered to a camera to capture a twice as fast, but will have slightly less phase distortion higher quality or backup audio recording.
  • Page 5: Power Options

    Stereo Portable Digital Recorder Power Options Power Input Connector The SPDR is designed to be used with the CH12 exter- Battery Installation nal (or equivalent) power source. The nominal voltage to operate the unit is 12 VDC, although it will operate The audio recorder is powered by two AA Quantum at voltages as low as 6 VDC and as high as 17 VDC.
  • Page 6: Memory Card Preparation

    We have tested a wide variety of microSDHC memory see if it has been formatted for use with the SPDR. If it cards and these performed the best with no issues or hasn’t, a prompt appears offering to do so.
  • Page 7: Features And Controls

    When recording, the light will blink blue. the playback. If both batteries and external power are connected to the SPDR, it will run on external power and the LED will be blue. The Power LED will briefly blink blue rapidly on receiv- ing a successful time code jam.
  • Page 8: Powering On

    The Power Button will not work while the unit is recording (stop recording first HOLD HOLD before powering down) or if the SPDR has been locked Press and Hold BACK (unlock the recorder first). and DOWN arrow to...
  • Page 9: Navigating Menus

    Lithium function Bat 3.16 v Remote Remote enabled? Use arrow keys to select Press to set analog or digital function About SPDR Rev: v0.14 About SPDR Ser: BACK Restore Use arrow keys to return Default defaults? to default settings BACK...
  • Page 10: Main Menu And Sub Menus

    ‘R’, ‘Q’, etc. as needed to avoid a naming conflict. The “01” after the ‘S’ Choose to use the clock provided in the SPDR as is the scene number. ‘T’ means take, and the “001” is opposed to a timecode source.
  • Page 11: Settings

    [SPDR Storage used Storage capacity To return the recorder to its factory default settings, use E.......F the UP and DOWN arrow buttons to choose Yes. SPDR 0/ 14G Available recording default settings: time (H : M : S) Max Rec Time...
  • Page 12: Operating Instructions

    When the Input Type is set to Digital, the two tricolor au- 2) Prepare the signal source(s). Position dio level indicator LEDs on the top of the SPDR will be microphone(s) the way it will be used in actual blue for a signal above -40 and off otherwise. In Digital operation and have the user speak or sing at the mode, the input is AES 3 compatible.
  • Page 13: Browsing/Playing Back Recordings

    Audio Levels Play from 00 : 52 : 29 beginning The status indicator will alert you if there is no microSDHC memory card in the SPDR. Question mark blinks 00 : 01 : 33 LAST Rio Rancho, NM...
  • Page 14: Copying Recordings To A Computer

    If “No” is chosen, nothing is done to the card and the appear as an icon on the desktop. Double-click to SPDR will not use the card. If “Yes” is chosen”, a prompt open it. appears asking for the length of the recording to re- 5.
  • Page 15: Using A Remote Control App

    Select • Mic Gain Level Adjustments Function • Lock/Unlock The SPDR tones are unique to the SPDR, and the recorder will not react to “dweedle tones” meant for Lectrosonics transmitters. The screens appear differently for iOS and Android Tap function phones, but perform the same functions.
  • Page 16: 5-Pin Input Jack Wiring

    SPDR 5-Pin Input Jack Wiring Audio input jack wiring: The wiring diagrams included in this section represent the basic wiring necessary for the most common types PIN 1 of microphones and other audio inputs. Some micro- Shield (ground) for positive biased electret lavaliere phones may require extra jumpers or a slight variation microphones.
  • Page 17: Microphone Cable Termination For Non-Lectrosonics Microphones

    NOTE: This termination is intended for UHF transmitters only. VHF transmitters with 5-pin jacks require a different termination. Lectrosonics lavaliere microphones are terminated for compatibility with VHF and UHF transmitters, which is different from what is shown here.
  • Page 18: Input Jack Wiring For Different Sources

    In addition to the microphone and line level wiring hook- A lot of information regarding microphone wiring is also ups illustrated below, Lectrosonics makes a number of available in the FAQ section of the web site at: cables and adapters for other situations such as con- http://www.lectrosonics.com...
  • Page 19: Line Level Signals

    Wiring Diagram for MCAES3 Digital Cable The MCAES3 cable is used to connect the AES output of a digital mixer or recorder to the SPDR AES input. It is constructed with a TA5F jack, rugged coaxial cable and a 3-pin female XLR connector. The connectors have soldered connections to the cable, allowing them to be serviced or replaced if the need arises.
  • Page 20: Optional Accessories

    SPDR Optional Accessories MCAES3 Used to connect the output to the AES3 digital input of a mixer or recorder; TA5F jack to 3-pin female XLR connector 26526 Wire belt clip P1354 dust and moisture plug for headphone/line out- put and timecode sync port.
  • Page 21: Specifications

    Stereo Portable Digital Recorder Specifications External Power Supply: DCR12/A4U 90-240 VAC, 50/60 Hz input; 12 VDC (regulated), 400 mA max. output. Recording Storage media: microSDHC memory card File format: .wav files (BWF) iXML metadata A/D converter: 24-bit Sampling rate: 48 kHz or 96 kHz Recording modes/Bit rate: Sample Rate HD Stereo Mode...
  • Page 22 SPDR This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 23: Service And Repair

    LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In warranty repairs are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a modest flat rate plus parts and shipping.
  • Page 24 This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
