Summary of Contents for Italtherm CITY GLASS 20 FR

  • Page 1 instruction Handbook installation adjustment maintenance CITY CLASS 20 FR 25 FR 30 FR 35 FR Green Heating Technology...
  • Page 2: Table Of Contents

    Table of Content Safety warnings    3 Positioning and fastening   � � � � � � � � � � � � � � � � �  17 Hydraulic system (DHW and heating)   � � � � � � �  18 Safety warnings symbols legend  ...
  • Page 3: Safety Warnings

    Safety warnings This instructions manual is an essential and complementary part of the product and it is supplied to- gether with the boiler� Carefully read the manual, achieving all important information for a safe installation, use and servicing� f Carefully keep the manual, together with the documentation of all the accessories of the boiler and of the system, for any further consultation you may need.
  • Page 4: Safety Warnings Symbols Legend

    Safety warnings symbols legend Generic safety Electrical danger Physical danger warning (fulguration) (personal damage) Thermal danger General warning or advice to avoid material damage (burns) or to achieve improvements References to Laws and Norms All references to laws and laws contained in this handbook, as well as all installation, maintenance and use prescriptions and the relevant pictures, are relevant to European and/or Italian regulation.
  • Page 5: User Warnings

    First starting up and Use The first starting up and the maintenance of the boiler must be performed by a professionally qualified staff (for example the installer or the Service Centres authorized by ITALTHERM) The latter will check that: f the label technical data of the gas boiler correspond to those of the gas available;...
  • Page 6: Installation, First Starting Up, Maintenance And Servicing

    f Do not put any object on the gas boiler and don't leave any flammable liquid or solid materials, (e.g. paper, clothes, plastic, polystyrene) in its proximity. f This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervi- sion or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 7: User Guide

    User guide The front control panel Pushbuttons and knobs Stand-by / Functioning mode At every press, the boiler cy- clically switches its working mode. The current mode is displayed by the writing (boiler in stand-by) or by the symbols: = Winter; = Summer (DHW only);...
  • Page 8: Commands On The Lower Side

    Two digit display under the symbol Normally, it displays the CH flow temperature, i.e the temperature of the liquid on boiler's outlet that is sent to the CH system. During the CH temperature setting (by rotating the knob ), it shows the temperature value changing; in case of alarm it displays "E"; during the setting (re- served to the Technician) it displays the chosen parameter ID number (see "PCB param- eters settings (technician menu)"...
  • Page 9: Commands Related To Domestic Hot Water

    tion in force prescribe its positioning, the temperature limits within the user can adjust it and the periods of heating. Remark: an optional, original Remote Control kit is available (see "Remote Control Kit" on page 47 for information) or a cutting-edge chronotermostat kit featuring weekly programming of various temperature levels and other special functions.
  • Page 10: Boiler Activation

    Boiler activation f Press the button • once to set the boiler in summer mode only (DHW only). Summer mode is recognizable by the only symbol presence on the display and not by the symbol presence • pressing twice to set the boiler in winter mode for making the boiler working both for CH and DHW.
  • Page 11: Incidental Malfunctioning

    "User Guide" section and expressly allowed to the User. Always address yourselves to qualified personnel. Boilers must be always equipped with original accessories only. ITALTHERM Srl is not responsible for damages caused by the incorrect, wrong or unreasonable use of not original materials. The burner doesn’t turn on f if the room thermostat (or programmable room thermostat, or similar) is installed, check that it is really requiring the room heating;...
  • Page 12: Stand-By Mode With Anti-Frost & Anti-Locking

    possible loss) in an heating system already filled with an Anti freezing solution, the concentration of the solution could have decreased and it could not guarantee the Anti freezing Protection. • completely empty the hot and cold sanitary water system, including the sanitary circuit and the DHW storage.
  • Page 13: Ambient Anti-Frost" Function

    “Ambient Anti-Frost” Function Note: if you want to use the “Ambient Anti-Frost” function that is often available in common room thermostats or chronothermostats, it is necessary NOT to leave the boiler in mode but in a mode that allows the heating, e.g. Heating Only mode (that saves from useless heating of the DHW storage, although keeping its anti-freeze function active), or in Winter mode.
  • Page 14: Dimensions And Connections

    Dimensions and connections 23÷43 23÷43 front view - hydraulic connections front view - left side view - on the wall hydraulic connections hydraulic connec- (with optional fitting kit) on the boiler tions on the boiler see also page 17 TA / L Legend: 1 Flue outlet RB Return from storage coil (¾”)
  • Page 15: Warnings For The Installation Of Optional Kits

    00381 B 00 City Class 30 FR speed 3 - 2 of the pump The graph is referred to the capacity available to the system. 1000 1200 1400 1000 1200 1400 water flow (l/h) water flow (l/h) 00381 C 00 City Class 35 FR speed 3 - 2 of the pump The graph is referred...
  • Page 16: Domestic Water Supply Characteristics

    ITALTHERM S.r.l. will not be held responsible for consequent damages. Instruct the User about the antifreeze function of the boiler and about the antifreeze product added in the heating system.
  • Page 17: Positioning And Fastening

    32.5 32.5 Positioning and fastening Heating Remark: A re-usable metal jig ( D in the figure) can be ordered sepa- Flow (3/4”) rately, so as to facilitate connections and fixing points positioning Flow to (when the original connection kit is used). If the metal jig and/or storage coil the original connection kit are not used, refer to the paragraph (3/4”)
  • Page 18: Hydraulic System (Dhw And Heating)

    (consider that 1 mm of limestone incrustations reduces of 18% the thermal exchange of the heating element on which it has been formed). ITALTHERM guarantees its products only if the characteristics of the water comply with UNI 8065, re- ported also in laws on energy saving�...
  • Page 19: Piping Between The Boiler And The Storage Unit

    Piping between the boiler and the storage unit Link the connection on the boiler identified by MB (flow to storage) to the MB connection of the Storage Unit, and the RB (return from storage) connection of the boiler to the RB connection of the Storage Unit. Swapping the flow and return connections could lead to malfunctions.
  • Page 20: Gas Connection

    Gas connection Due to various installation possibilities, the gas cock 3 supplied with the original Connections Kit has a simple male Ø ½” connection, facing the rear of the boiler. The gas pipe 4, upstream the gas cock 3, should be supplied by the installer.
  • Page 21: Electrical Connection Between The Boiler And

    ITALTHERM S.r.l. declines any responsibility for damages to persons, animals or things caused by the faulty or missing connection of the boiler earthing and by failure to comply with the rules.
  • Page 22: Flue Systems

    Flue systems General indications To ensure the functionality and the efficiency of the appliance it is necessary to foresee, for the hori- zontal ducts of air inlet and flue outlet, a slope of 2÷5% downwards from the boiler to the outside (see diagram).
  • Page 23: Flue System Types

    Flue system types Split pipe system (C * and B Split pipe system Ø80mm (with splitter on coaxial connection) Model Reducer AS+SC min÷max for length of Ø mm AS+SC (m) 20 FR 45 mm 2 ÷ 16 25 FR 30 FR 2 ÷...
  • Page 24: Adjustment And Maintenance

    Adjustment and Maintenance WARNING: Hereby described operation can be performed by qualified technicians only. When regulation/measuring is over, remember to tighten pressure tapping point screws and ALWAYS check for gas leaks! Before switching on the boiler, make sure that the circulating pump is not blocked due to inactivity: in the middle of the cap there is a hole (should there be a plug, remove it) that gives access to the rotor shaft;...
  • Page 25: Access To The Inside Of The Boiler

    f verify and, if necessary, change the boiler electronic settings to adapt its work to particular system requirements (see "Main boiler parameters (PC)" on page 27); Before turning on the boiler, verify that the pump is not blocked due to inactivity: unscrew the cap located at the centre of the pump’s body, locate the rotor shaft behind the cap and turn it manually using a screwdriver or other suitable tool.
  • Page 26: Inlet Gas Check

    Inlet gas check Remark: The pressure should be measured at nomi- nal input, so this test must be performed with the burner ignited. Loosen (2-3 turns) the screw of pressure tapping point for gas inlet 2 of the gas valve and insert the manometer sensor;...
  • Page 27: Pcb Parameters Settings (Technician Menu)

    • reinsert the connector 4 and check that MAX pressure is not changed; Important: LOCK THE ADjUSTMENT DEVICE AFTER ANY SETTING OPERATION. • mount the cap C ; screw the pressure tapping point screw for gas outlet 1 and verify that there is no gas leak� 8.
  • Page 28 Param- Adj. range Description (fact. set.) eter and values 0…15 (3) Value in minutes. Delay of boiler re-ignition after set Central Heating tem- perature has been reached. (This parameter works only if par. 05 = 0) 0…3 (0) Auxiliary maintenance functions Disabled - normal operation of the boiler (Remember to set this value to 0 at the end of work) function Bleeding on heating side - boiler puts 3-way valve on the heating...
  • Page 29: Combustion Test

    Param- Adj. range Description (fact. set.) eter and values 5…20 (15) Differential (°C) among set DHW temperature and storage coil flow tempera- ture, during preparation. 0; 50…70 Enables the anti-legionella function and sets the relevant temperature (60) Disabled - the boiler won't run any anti-legionella cycle Danger! This setting is strongly deprecated! Legionella is a bacteria that's extremely dangerous for the health and, in some cases, it can be deadly.
  • Page 30: Soft Ignition

    Soft ignition Soft ignition pressure is automatic and it needs no adjustment. • The ignition is achieved by means of a burst of electrical sparks, while the burner is supplied with gas, initially to the MIN pressure set on the valve gas, then pressure increases gradually (soft igni- tion ramp) until the ignition takes place.
  • Page 31: Gas Conversion

    Gas conversion ATTENTION: the operations described below must be carried out only by qualified personnel (authorized by the Manufacturer or by the local authority, if required by the regulation). For gas conversion, use the nozzles supplied by boiler manufacturer only. Using LPG, it is absolutely necessary to install a suitable pressure reducer upstream the boiler.
  • Page 32: Draining The Heating System

    Draining the heating system When it is necessary to drain the heating system, proceed as described here below: f Connect a rubber pipe to the draining tap terminal 1 ; f put the other end of the pipe in a suitable drain or sink; f open the draining tap by turning the nut 2 counter- clockwise, using a suitable spanner;...
  • Page 33 Operations accompanied by the symbol are always reserved to the Technician. Operations with grey background are reserved to the Technician. Signal Probable causes Suggested solutions Boiler just installed Retry the ignition several times: use the button. (air mixed to gas). When the 5 reset possibilities are over, to have 5 more, it's possible to switch off the electrical supply to the boiler for 30 seconds, by using the purposed external switch.
  • Page 34 Signal Probable causes Suggested solutions Insufficient system Restore the correct pressure as described in "Preliminary opera- pressure tions" on page 9 or (preferibly by the Technician) in "Heating (loss of water pressure system filling and pressuring" on page 19. switch triggered) Remark: Consider that the pressure, in normal conditions, should not decrease with the progress of the time.
  • Page 35 Signal Probable causes Suggested solutions Unexpected flame Wait for the boiler automatic reset (5 minutes) or reset it manually by using the button. If the lockout persists or reappears, call the control elec- the Service Centre� tronic has detected the flame on the Detect eventual malfunctioning of the gas valve (that does not burner when this stop fully the gas flow, so the burner remains ignited) or of the elec-...
  • Page 36: Warnings For Servicing

    Clean casing with soapy water only. Do not clean casing, other painted or plastic surfaces with thin- ner� f In any case of parts replacement, it is mandatory to use ITALTHERM original spare parts. ITALTHERM declines any responsibility in case of non-original spare parts utilization.
  • Page 37 Notes Green Heating Technology...
  • Page 38: Technical Data

    Technical data TECHNICAL DATA City Class 20 FR City Class 25 FR U.M. Gas type G30/G31 G30/G31 Class 2H3+ 2H3+ Type B22 - C12 - C32 - C42 - C52 - C62 - C82 Working temperature range °C 0 ÷ +60 0 ÷...
  • Page 39 TECHNICAL DATA (cont'd) City Class 20 FR City Class 25 FR U.M. G30/G31 G30/G31 Gas type Hot water Temperature selection range °C 30÷60 30÷60 (min÷max) Electrical data Voltage / frequency 220÷240 / 50 220÷240 / 50 V / Hz (nominal voltage) (230V) (230V) Power consumption...
  • Page 40 TECHNICAL DATA City Class 30 FR City Class 35 FR U.M. Gas type G30/G31 G30/G31 Class 2H3+ 2H3+ Type B22 - C12 - C32 - C42 - C52 - C62 - C82 Working temperature range °C 0 ÷ +60 0 ÷ +60 (min÷max) Max heat input (Qn) 30.0...
  • Page 41 TECHNICAL DATA (cont'd) City Class 30 FR City Class 35 FR U.M. G30/G31 G30/G31 Gas type Hot water Temperature selection range °C 30÷60 30÷60 (min÷max) Electrical data Voltage / frequency 220÷240 / 50 220÷240 / 50 V / Hz (nominal voltage) (230V) (230V) Power consumption...
  • Page 42: Boiler Internal Components - 20 Fr - 25 Fr

    Boiler internal components - 20 FR - 25 FR - 30 FR Flue pressure switch 11 Drain valve Flue hood 12 Loss of water pressure switch Expansion vessel 13 Gas valve Flame ignition/detection electrode 14 System pressure gauge Safety thermostat on system flow 15 By-pass (in-built in the 3-way valve hydraulic assembly) Temperature Sensor, system flow...
  • Page 43: Boiler Internal Components - 35 Fr

    Boiler internal components - 35 FR Flue pressure switch 11 Drain valve Flue hood 12 Loss of water pressure switch Expansion vessel 13 Gas valve Flame ignition/detection electrode 14 System pressure gauge Safety thermostat on system flow 15 By-pass (in-built in the 3-way valve hydraulic assembly) Temperature Sensor, system flow 16 Burner...
  • Page 44: Electrical Diagram

    Electrical diagram (SP) 13.1 (ST) 13.2 M0101 M0102 M0901 M0900 M0904 Flue pressure switch (*) Optional external devices: Flame ignition/detection electrode SP DHW Storage temperature Probe (**) Safety thermostat on system flow (*) ST DHW Storage Thermostat (*) (**) Temperature Sensor, system flow TA Room thermostat: (or Chronothermostat) SELV simple contact.
  • Page 45: Hydraulic Diagram

    Hydraulic diagram M RB Flue pressure switch 15 By-pass (in-built in the 3-way valve hydraulic assembly) Flue hood 16 Burner Expansion vessel 17 Primary exchanger Safety thermostat on system flow 18 Sealed chamber Temperature Sensor, system flow 19 Fan Motorized 3-way valve Automatic Venting Device (heating circuit, incorporated in the pump) Safety valve 3 bar...
  • Page 46: Addendum

    Addendum Outdoor Sensor Kit Installation and setting The Outdoor Sensor manages automatically the CH flow temperature** as a function of the outdoor temperature, thus avoiding the user to adjust it manually. This function is also named "shifting tempera- ture"� that's the temperature of the heating elements. Don't mistake it with the room temperature (managed by the room thermo- stat or by the Remote Control, but not by the boiler) that doesn't depend on the first one.
  • Page 47: Remote Control Kit

    Remote Control Kit This remote control is more than a simple room thermo- stat. Thanks to this, it is possible to manage the boiler in all its settings like DHW and CH temperature adjustment, boiler reset in case of boiler block, and of course it works as a room thermostat both in manual and weekly program mode.
  • Page 48 Notes Green Heating Technology...
  • Page 49 Notes Green Heating Technology...
  • Page 50 Green Heating Technology www.italtherm.it ITALTHERM Srl Via S. D’Acquisto, 10 • 29010 Pontenure (PC) - IT Tel. +39.0523.575611 • Fax +39.0523.575600 UNI EN ISO www.italtherm.it • e-mail: info@italtherm.it 9001:2015...
