Summary of Contents for Kontron DSP-8200
- Page 1 DSP-8200 Fanless Mini Digital Signage Player w/ ARM® Cortex®-A17 Based Processor, Rockchip RK3288 User’s Guide...
-
Page 2: Table Of Contents
Chapter 1 Introduction ....................10 Overview ..................... 10 Product Specifications ................ 11 System tour ..................12 Mechanical Dimensions ..............16 Chapter 2 Getting Started ..................17 Setting up your PC ................17 Mounting your PC to a display ............21 DSP-8200 User’s Manual... -
Page 3: Figures & Tables
Figure 5 HDMI .................... 17 Figure 6 Connecting USB mouse & keyboard..........18 Figure 7 RJ45 connector ................19 Figure 8 Turning on the system ..............20 Figure 9 VESA mounting ................21 Table 1 Product Specifications ..............11 DSP-8200 User’s Manual... -
Page 4: Safety Instructions
Turn off system power, turn off the power supply, and then disconnect the power cord from its source before removing the chassis cover. Turning off the system power switch does not remove power to components. DSP-8200 User’s Manual... -
Page 5: When Working Inside A Computer
ESD procedure, which can include wrist straps and smocks, when servicing equipment. You can also take the following steps to prevent damage from electrostatic discharge (ESD): When unpacking a static-sensitive component from its shipping carton, do not DSP-8200 User’s Manual... -
Page 6: Instructions For Lithium Battery
(e.g. to the collecting points for disposal of batteries) Voltage Ratings The external power adaptor of the DSP-8200 has the following voltage ratings: Input: 100~240 VAC, 50~60 Hz ... -
Page 7: Preface
Failure to do so may cause damage to internal components, particularly the hard disk drive. Humidity High-humidity can cause moisture to enter and accumulate in the system. This moisture can cause corrosion of internal components and degrade such DSP-8200 User’s Manual... - Page 8 Line conditioners keep a system’s AC power source voltage at a fairly constant level and, therefore, can handle brownouts. Because of this added protection, line conditioners cost more than surge protectors. However, line conditioners cannot protect against a complete loss of power. Uninterruptible Power Supply DSP-8200 User’s Manual...
- Page 9 Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. DSP-8200 User’s Manual...
-
Page 10: Chapter 1 Introduction
Introduction Overview DSP-8200 is an ARM and Android based fanless mini media player designed for digital signage. It has a HDMI2.0 port to supports 4K Ultra HD video output. With built-in Wi-Fi and Bluetooth technology, it enables wireless connection to streaming content and data transfer. -
Page 11: Product Specifications
Operation Temp.: 0°C ~ 60°C / 32°F ~ 140°F Environmental Storage Temp.: -25°C ~ 70°C / -13°F ~ 158°F Characteristics Humidity: 10% ~ 90% Mounting VESA Mount (100 x 100 mm) Security 1x Kensington Security Slot (on rear) Table 1 Product Specifications DSP-8200 User’s Manual... -
Page 12: System Tour
ADB (Android Debug Bridge) button facilitates a variety of device actions, such as installing and debugging apps, and it provides access to a Unix shell that users can use to run a variety of commands on a device. DSP-8200 User’s Manual... -
Page 13: Figure 2 Rear Panel
The USB (Universal Serial Bus) port is compatible with USB devices such as keyboards, mouse devices, cameras, and hard disk drives. USB allows many devices to run simultaneously on a single computer, with some peripheral acting as additional plug-in sites or hubs. DSP-8200 User’s Manual... - Page 14 Kensington Lock Slot The slot is used for attaching a lock-and-cable apparatus. Locks are generally secured in place with a key or combination lock attached to a rubberized metal cable. DSP-8200 User’s Manual...
-
Page 15: Figure 3 Top Panel
Chapter 1 Top Panel Figure 3 Top Panel Power LED The power LED will light when the PC is power-on. DSP-8200 User’s Manual... -
Page 16: Mechanical Dimensions
Chapter 1 Mechanical Dimensions 167.5 x 120 x 26.5 mm (W x D x H) Figure 4 Mechanical Dimensions DSP-8200 User’s Manual... -
Page 17: Chapter 2 Getting Started
Chapter 2 Chapter 2 Getting Started Setting up your PC Connecting the monitor Connect the HDMI cable from your display to the HDMI port. HDMI2.0 Figure 5 HDMI DSP-8200 User’s Manual... -
Page 18: Figure 6 Connecting Usb Mouse & Keyboard
Chapter 2 Connecting USB mouse & keyboard Your DSP-8200 does not come with a keyboard and mouse, but you can use any USB keyboard or mouse with your computer. USB OTG USB2.0 Figure 6 Connecting USB mouse & keyboard NOTE Using a third-party USB mouse or keyboard may require software drivers. -
Page 19: Figure 7 Rj45 Connector
Connecting to a network device Connect one end of a network cable to the GbE LAN port on the system rear panel and the other end to a hub or switch. RJ45 Figure 7 RJ45 connector DSP-8200 User’s Manual... -
Page 20: Figure 8 Turning On The System
Chapter 2 Turning on the system Connect the power adapter cable to the DC jack (DC IN) of DSP-8200 Connect the power cable to the power adapter Connect the power cable to a power outlet The system will power on automatically when power is applied... -
Page 21: Mounting Your Pc To A Display
Chapter 2 Mounting your PC to a display Secure the DSP-8200 to your display directly with four screws. NOTE To fasten the DSP-8200, your display must comply with VESA100 standard. Figure 9 VESA mounting DSP-8200 User’s Manual...
