Summary of Contents for OHIOSTEEL AllFitHD AF-1250SLR
- Page 1 AF-1250SLR 1250 LB STEEL FOLDING LOADING RAMPS U.S. PATENT No. 5,645,394 READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT 6000661 - REV A 10/10...
-
Page 2: Safety Rules
Safety Rules This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Read and understand all safety rules and operating instructions before using these loading ramps. -
Page 3: Carton Contents
Carton Contents 2 (2) 1 (2) 12 (x4) 4 (x4) 13 (x2) 3 (x4) 11 (x4) 10 (x8) 9 (x4) 5 (x8) 8 (x8) 7 (x8) 6 (x8) TOOLS REQUIRED FOR ASSEMBLY: • 3/4" Wrench or Socket • Adjustable Wrench •... - Page 4 Assembly Instructions Attach support bars to ramp top. Tighten bolts at this time. Slide support bar pads onto bars as shown. Note: Apply soapy water inside support bar pad, this will allow the pad to slide onto the bar easier. Invert ramp bottom so that flanges face up.
-
Page 5: Maintenance
Operating Instructions USAGE: Look for a wall or depression to reduce the loading angle, the lower the ramp angle the easier the loading of the vehicle will be. Park the loading vehicle on flat, firm, or grassy terrain. Set the emergency brake and chock the tires of the loading vehicle to prevent any movement while loading and unloading the equipment. -
Page 6: Warranty
Warranty If this product fails due to a defect in material or workmanship within TWO YEARS from the date of purchase, we will at our option repair or replace it free of charge. This warranty does not cover: • Repairs necessary because of operator abuse or negligence. •... -
Page 7: Repair Parts
Repair Parts... - Page 8 Notes...
- Page 9 Notes...
- Page 10 DESIGNED AND TESTED IN COLUMBUS, OHIO MANUFACTURED IN THE U.S.A. FROM DOMESTIC AND IMPORTED COMPONENTS MODEL # AF-1250SLR (800) 652-2321...
