Summary of Contents for Whirlwind H7
- Page 1 H7 Manual Whirlwind - H7 – User Manual – P. 1...
- Page 2 Table of Contents 1. Principle to Self-Balancing HoverKart ..................... 3 2. Assembly Instructions ........................... 4 3. How to Use ............................... 10 4. Technical Parameters .......................... 15 Whirlwind - H7 – User Manual – P. 2...
-
Page 3: Principle To Self-Balancing Hoverkart
Before driving, make sure that the tires are in good condition and there are no loose parts. Please use the product sensibly otherwise you risk personal injury and property loss. Please do not modify its components by yourself. Whirlwind - H7 – User Manual – P. 3... -
Page 4: Assembly Instructions
5 X 45mm Bolts 9 X Anti-Slip Nut 4 X Screws (Use image as a reference only – 2 X Velcro Straps quantities are different from image shown) 1 X HoverBoard Whirlwind - H7 – User Manual – P. 4... - Page 5 1 X Seat 1 X Front Panel 1 X Wheel 1 X Nob 2 X Handle 1 X Main Frame 2 X HoverBoard Bracket Whirlwind - H7 – User Manual – P. 5...
- Page 6 1 X Rear Stabilizer Wheel Whirlwind - H7 – User Manual – P. 6...
- Page 7 Make sure both parts are aligned so that you can insert the large black 44mm Bolt through the hole of the tube and tighten with an Anti-Slip nut using an Allen Key. Whirlwind - H7 – User Manual – P. 7...
- Page 8 Release the Nob into a selected hole – the hole chosen will determine the Length of the HoverKart and this can be adjusted by selecting any of the other holes in the Front Panel. Whirlwind - H7 – User Manual – P. 8...
- Page 9 HoverBoard and tighten using the Velcro on each Strap. 6. Make sure all parts are secured tightly and are not going to move around during use a) Make sure you test each part is secured before use. Whirlwind - H7 – User Manual – P. 9...
-
Page 10: How To Use
Remember that the more relaxed your body is; the easier it will be. Please avoid drastic shakes or an abrupt shift in your centre of gravity. Stay still and make slow and gradual movements until you feel more confident. Whirlwind - H7 – User Manual – P. 10... - Page 11 Always look behind you when reversing so that you can see where you are going and avoid accidents. Whirlwind - H7 – User Manual – P. 11...
- Page 12 Slowly and gently practice going in small circles until you become confident – while making sure you don’t become to disorientated to avoid an accident. Whirlwind - H7 – User Manual – P. 12...
- Page 13 Please proceed with caution. Make sure you practice turning backwards on one spot and that you are comfortable doing so, before moving on to the next step. Whirlwind - H7 – User Manual – P. 13...
- Page 14 HoverKart to turn fast and sharply. Only turn this way if you absolutely have to as it may cause the HoverKart to slide along the surface and for the driver to lose control. Whirlwind - H7 – User Manual – P. 14...
-
Page 15: Technical Parameters
Max Speed (mph) Max Range Max Climbing Angle Battery Capacity Battery Type Battery Brand Charge time (hours) Max Loading 120KG Size (mm) (H) 400 x (W) 800 x (D) 440 Working Temperature (°C) Whirlwind - H7 – User Manual – P. 15... - Page 16 Whirlwind - H7 – User Manual – P. 16...
