- Page 1 H7 Manual Whirlwind - H7 – User Manual – P. 1...
-
Page 2: Table Of Contents
Table of Contents 1. Principle to Self-Balancing Hoverboard ..................... 3 2. Preparation before use ..........................5 3. How to use ..............................6 4. General Advice ............................10 5. Technical Parameters ..........................13 Whirlwind - H7 – User Manual – P. 2... -
Page 3: Principle To Self-Balancing Hoverboard
It then uses the motor to stabilize and balance the device. The device can go forwards, backwards, turn and stop all being controlled by dynamic equilibrium. It looks cool, is simple operate, uses easy controls and it protects the environment. Whirlwind - H7 – User Manual – P. 3... - Page 4 Green light means fully charged. When green light turns yellow, it means 50% of battery left. When yellow light turns red, it means 10% of battery left and you need to charge the device soon. Whirlwind - H7 – User Manual – P. 4...
-
Page 5: Preparation Before Use
The Hoverboard device has a function to show the battery status. Please check the battery status before using. When the red light is on, the scooter should be charged first as this means that the battery is below 25%. Whirlwind - H7 – User Manual – P. 5... -
Page 6: How To Use
3. How to use Balancing Decelerate Slowly move forward Braking Accelerate Reversing Whirlwind - H7 – User Manual – P. 6... - Page 7 Remember that the more relaxed your body is; the easier it will be. Please avoid drastic shakes or an abrupt shift in your centre of gravity, which might cause you to slip or fall over. Whirlwind - H7 – User Manual – P. 7...
- Page 8 Shift your centre of gravity gradually back from the travelling direction to stop. Please decelerate beforehand when approaching obstacles or traffic lights. Please do not accelerate or brake on slippery surfaces, otherwise this may cause injuries. Whirlwind - H7 – User Manual – P. 8...
- Page 9 Low Battery: If both LED lights flash at the same time it means that the H7 is on low battery mode. There will also be a beeping noise to indicate this. Whilst in low battery mode, the speed limit will be limited to 3mph.
-
Page 10: General Advice
Please do not modify its components by yourself because it may alter the capacity of the scooter and make it dangerous to use. Avoid these Scenarios Bumpy Terrains Entrance height Upslope >15° Downslope >15° Whirlwind - H7 – User Manual – P. 10... - Page 11 Do not start or stop suddenly. Avoid driving The weight of the user should not exceed the on steep slopes. maximum load of 120kgs (indicated in the Manual); otherwise, the driver may get injured Whirlwind - H7 – User Manual – P. 11...
- Page 12 Do not drive in the rain. using your phone, listening to music etc. Do not drive it at night without light. Avoid driving on obstacles, on slippery grounds such as snow, ice, or woody surfaces. Whirlwind - H7 – User Manual – P. 12...
-
Page 13: Technical Parameters
36V, 4.4Ah (158.4W) Battery Type Lithium Battery Brand Samsung Charge time (hours) Max Loading 120KG Size (mm) (H) 300 x (L) 680 x (W) 210 Working Temperature (°C) -20 ~ 60 Whirlwind - H7 – User Manual – P. 13... - Page 14 Whirlwind - H7 – User Manual – P. 14...
