Wiseup WIFI38 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
I. Product Overview
1
2
3
5
7
6
1. Reset Button
2. Power Button
3. Micro SD Card Slot
4. USB Port
5. Battery Charging Indicator Light
6. WIFI Indicator Light
7. Power Indicator Light
8. Camera Lens
9. Infrared Leds
User Manual
Model Number: WIFI38
(Android Version)
4
600ml
500ml
8
400ml
9
300ml
200ml
100ml

Advertisement

loading
Need help?

Need help?

Do you have a question about the WIFI38 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wiseup WIFI38

Summary of Contents for Wiseup WIFI38

  • Page 1 User Manual Model Number: WIFI38 (Android Version) I. Product Overview 600ml 500ml 400ml 300ml 200ml 100ml 1. Reset Button 2. Power Button 3. Micro SD Card Slot 4. USB Port 5. Battery Charging Indicator Light 6. WIFI Indicator Light 7. Power Indicator Light 8.

  • Page 2: What's In The Package

    II. What's in the Package? -1×Travelling Mug Camera -1×USB Cable -1×AC110-240V to DC 5V Power Adapter -1×16GB Micro SDHC Class 10 Card (already inserted into the Micro SD card slot) III. Get the Camera Ready 3.1 Make sure that a micro SD card is formatted and has been inserted into the SD card slot of the camera.
  • Page 3 IV. P2P Connection Setup (LAN Mode) 4.1 Turn on the camera, when you see the WIFI indicator light is flashing slowly, indicating that the camera's wifi signal is ready. 4.2 Search for "Camvip" on the Google Play store and install the APP on your mobile device. camvip 4.3 Open the WLAN settings page of your mobile device, connect your mobile device to the camera's WIFI hotspot.
  • Page 4 4.4 Run the APP "Camvip". 12:30 camvip 4.5 Add the camera to the APP "Camvip" . Option 1 12:30 12:30 WIFICAM WIFICAM 2019/06/14 11:28:42 IPCAM Welcome WIFICAM Weather refresh Searched 1new device,want to add? CANCLE Add device...
  • Page 5 Option 2 12:30 12:30 WIFICAM Add device LAN search device LAN search device,ensure the current phone isconnected to the device(ipc) network,or the same network with ipc Add device manually Welcome Enter the UID of device manuallly.or Scan QR Code in the device Configue device to connet remotely Enter the UID of device manuallly.or Scan QR Code in the device Add device...
  • Page 6 4.6 When you see the live video is on your mobile device, that means the P2P connection setup is succeed. 12:30 WIFICAM 2019/06/14 11:28:42 IPCAM WIFICAM Weather refresh V. Remote View Configuration (WAN Mode) 5.1 Run the app "Camvip" , make sure that the camera has been added to the app and it is online.
  • Page 7 5.2 Tap the setting icon on the app. 12:30 WIFICAM 2019/06/14 11:28:42 IPCAM WIFICAM Weather refresh 5.3 Tap "Network configuration". 12:30 PPRT-088410-BXVFE Device name Device password Share Alarm notification Network configuration Motion detection set IO detection set TF card set High level configuration Delete device...
  • Page 8 5.4 Search for the available WIFI networks. 12:30 Confirm Network configuration wifi name TEST-WIFI choice your home wifi name password input your home wifi password IP address 192.168.234.1 Subnet mask 255.255.255.0 Gateway 192.168.234.1 Prefered DNS 192.168.31.1 5.5 Connect the camera to one of the available wifi networks, then the camera will restart automatically.
  • Page 9 12:30 12:30 Confirm Network configuration wifi name SSID-1 PPRT-088410-BXVFE choice your home wifi name Device name password Device password IP address 192.168.234.1 Share Subnet mask 255.255.255.0 Alarm notification Gateway 192.168.234.1 Loading Network configuration Prefered DNS 192.168.31.1 Motion detection set IO detection set TF card set High level configuration Camip:Set Success...
  • Page 10 5.7 Return to the WLAN settings page on your mobile device and disconnect the camera from the current WIFI network. 12:30 12:30 Settings Settings SIM cards & mobile networds WLAN 12:30 12:30 WLAN details Cancel WLAN Disconnect SSID-1...
  • Page 11 5.8 Enroll your mobile device in another wifi network, or enable the data network connection. 12:30 12:30 WLAN WLAN WLAN WLAN SSID-2 SSID-2 12:30 12:30 12:30 WLAN Settings SIM cards & mobile networks WLAN Mobile data Allow this device to use mobile data SIM cards &...

  • Page 12: Motion Detection Setup

    5.9 Run the APP Camvip again, if you see the live video on your mobile device, that means the remote view setup is succeed. 12:30 12:30 WIFICAM IPCAM 2019/06/14 11:28:42 camvip WIFICAM Weather refresh <Note>: If the camera status is "Connect Fail", indicating that the remote view setup is failed, please set up again.
  • Page 13 6.2 Tap the setting icon on the app, then select "Motion detection set". 12:30 12:30 WIFICAM IPCAM 2019/06/14 11:28:42 PPRT-088410-BXVFE Device name Device password Share WIFICAM Alarm notification Weather refresh Network configuration Motion detection set IO detection set TF card set High level configuration Delete device 6.3.
  • Page 14 12:30 Confirm Motion detection set Motion detection Alarm space 60Second Picture mail notification after alarm Picture FTP upload after alarm Video FTP upload after alarm <Note>: The motion detection video resolution is 1280x720P and the video format is AVI. VII. Record to the Local Memory Card 7.1 Run the app "Camvip"...
  • Page 15 7.2 Tap the setting icon on the app, then select "TF card set". 12:30 12:30 WIFICAM IPCAM 2019/06/14 11:28:42 PPRT-088410-BXVFE Device name Device password Share WIFICAM Alarm notification Weather refresh Network configuration Motion detection set IO detection set TF card set High level configuration Delete device 7.3 Tick "Full time recording", set the video clip length, then tap "Confirm"...
  • Page 16 12:30 12:30 Confirm Confirm TF card set TF card set Capacity (Available / Capacity (Available / 14964 M/15199M 14964 M/15199M Total) Total) Unistall SD card Unistall SD card Format SD card Format SD card Select Stop recording Stop recording Full time recording Full time recording Recording length Recording length...
  • Page 17 8.2 Tap the camera. 12:30 WIFICAM IPCAM 2019/06/14 11:28:42 WIFICAM Weather refresh 8.3 Tap the video recording button to start recording. 12:30 GMT 2019-06-14 15:22:49 LIVE 1080P 720P 640P IPCAM 2019/06/14 15:22:45...
  • Page 18 8.4 Tap the audio record button to enable the audio recording. 12:30 GMT 2019-06-14 15:22:49 LIVE 1080P 720P 640P 2019/06/14 15:22:45 IPCAM 8.5 All the video files will be saved to the mobile device and you can play the video by following the steps below.
  • Page 19 12:30 12:30 Local file WIFICAM /storage/emulated/0/IPCAM PPRT-088410-BXVFE-() IPCAM 2019/06/14 11:28:42 WIFICAM Weather refresh 2019-06-14 2019-06-14 2019-06-14 15-26-52.MP4 15-26-23.MP4 15-24-25.MP4 Add Device Local File 2019-06-14 2019-06-14 2019-06-14 15-24-06.MP4 15-22-55.MP4 15-15-00.MP4 Exit <Note>: The video resolution is 640x360 or 1280x720P, the video format is MP4. IX.
  • Page 20 9.2 Tap the file icon on the app to enter into the local memory card. 12:30 WIFICAM 2019/06/14 11:28:42 IPCAM WIFICAM Weather refresh 9.3 Select one of the video files to play. 12:30 TF card video management Normal Alarm Time-lap All file recordin recordin...

  • Page 21: Change The Camera Name

    X. Reset Operation: When the camera is turned on, press and hold down the reset button for 10 seconds to reset the camera to the factory settings. XI. Change the Camera Name 11.1 Run the APP "Camvip". 12:30 camvip...
  • Page 22 11.2 Make sure that the camera has been added to the app successfully and it is online. 12:30 WIFICAM IPCAM 2019/06/14 11:28:42 WIFICAM Weather refresh 11.3 Tap the setting icon on the app, select "Device name". 12:30 12:30 WIFICAM IPCAM 2019/06/14 11:28:42 PPRT-088410-BXVFE Device name...
  • Page 23 11.4. Input a new camera name. 12:30 Device name Kitchen Living room Bedroom Lounge Countryard 11.5 Tap "OK" to confirm the modification. 12:30 12:30 Device name PPRT-088410-BXVFE Home Device name Home Kitchen Living room Bedroom Device password Lounge Countryard Share Alarm notification Network configuration Motion detection set...
  • Page 24 XII. Change the Camera's Login Password 12.1 Run the app "Camvip" and make sure that the camera has been added to the app successfully and it is online. 12:30 12:30 WIFICAM 2019/06/14 11:28:42 IPCAM camvip WIFICAM Weather refresh 12.2 Tap the setting icon on the app, select "Device password". 12:30 12:30 WIFICAM...
  • Page 25 12.3 Enter the default password "888888". 12:30 Device password Device ID:PPRT-088410-BXVFE 888888 PassWord： 12.4 Input a new password, then tap "OK" to save the modification. 12:30 12:30 12:30 Device password Device password Device ID:PPRT-088410-BXVFE Device ID:PPRT-088410-BXVFE PPRT-088410-BXVFE PassWord： PassWord： Device name Home Device password Share...

  • Page 26: Back-Up Battery Charging

    XIII. Back-up Battery Charging Connect your camera to an external power source to charge the battery, both power and charging indicator light will be solid on during the charging process. It would take about 7 hours to obtain a full charge. When the charging time is over 6 hours, please disconnect the camera from the external power source.
  • Page 27 between the camera and your mobile device. Q: How to add the camera to more mobile devices? A: Install and launch the APP “Camwf” on the other mobile devices, tap “+” to scan the QR code on the camera, or input the camera UID and password to add the camera. Q: What can I do if I forget the login password? A: Reset the camera to factory default settings.
