FVS IFP Series Electric Lift

THANK YOU

Thank you for purchasing the FlexView™ FVS IFP series electric lift. Please read these

instructions thoroughly before installing this product.

PRODUCT FEATURES

• Middle Atlantic PD-815SC (8) outlet, 15 amp power strip with surge and circuit breaker

• Simple display mounting with electric adjustment of display height

• Lever Lock™ for easy mounting of codecs and smaller components

• Adjustable cable management included

Instruction Sheet

FlexView ™

I-00870

Rev -

Table of Contents

Summary of Contents for Map FlexView FVS IFP Series

Page 1 Instruction Sheet FlexView ™ FVS IFP Series Electric Lift THANK YOU Thank you for purchasing the FlexView™ FVS IFP series electric lift. Please read these instructions thoroughly before installing this product. PRODUCT FEATURES • Middle Atlantic PD-815SC (8) outlet, 15 amp power strip with surge and circuit breaker •...
Page 2 GROUNDING INSTRUCTIONS / INSTRUCTIONS DE MISE À LA TERRE This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug.
Page 3 IMPORTANT SAFETY INSTRUCTIONS / INSTRUCTIONS IMPORTANTES SUR LA SÉCURITÉ CAUTION! To avoid an unstable condition, place heavier WARNING/CAUTION! The exclamation point within an components at the bottom of the cabinet. When more than equilateral triangle is intended to alert the user to the one component is placed in the cabinet, begin at the presence of important operating and maintenance bottom of the cabinet and place equipment at the lowest...
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical furnishing, basic precautions should always be followed, including the following: • For institutional use. • Read and follow all instructions before using. • WARNING – Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result the furnishing may tip over on the child.
Page 5: Instructions Importantes Sur La Sécurité
INSTRUCTIONS IMPORTANTES SUR LA SÉCURITÉ Lorsque vous utilisez des mobiliers électriques, toujours respecter les précautions de base, notamment : • Usage institutionnel. • Lire et suivre toutes les instructions avant l'utilisation du matériel. • AVERTISSEMENT - Des blessures graves ou mortelles peuvent survenir si un enfant grimpe sur le meuble d'un équipement audio ou vidéo.
Page 6: Weight Ratings
WEIGHT RATINGS ITEM DETAILS 300 lbs. (136.1 kg) Maximum Display 320 lbs. (145.2kg) Maximum Display (Including Camera Mount and Soundbar Mount) 50 lbs. (23 kg) Maximum Internal 370 lbs. (168 kg) Maximum Total Rated Load CAMERA MAXIMUM: 20LBS (9.1KG) DISPLAY MAXIMUM: 300 LBS (136.1KG) SOUNDBAR MAXIMUM: 20LBS (9.1KG) WARNING - This cart is intended for use only with the products and maximum weights indicated.
Page 7: Required Tools
REQUIRED TOOLS • #2 Phillips Screwdriver • Protective Eyewear WARNING: Use tools with caution and follow all necessary safety protocols. AVERTISSEMENT: Utiliser des outils avec prudence et suivre tous les protocoles de sécurité nécessaires. MOBILITY FEATURES • (4) directional locking casters are supplied to allow easy “steering”...
Page 8: Operation
OPERATION DURING OPERATION: • IF THE FLEXVIEW MAKES UNUSUAL NOISE OR SMELLS, SWITCH OFF THE MAINS VOLTAGE IMMEDIATELY. • TAKE CARE THAT THE CABLES ARE NOT DAMAGED. • BEFORE CART IS MOVED, UNPLUG THE MAINS CABLE ON THE MOBILE EQUIPMENT. Move Move Down...
Page 9 SUPPLIED COMPONENTS AND HARDWARE NOTE: Additional hardware is included FLAT PANEL MOUNTING HARDWARE that may not be required for your installation. M4 x 16 (Qty 8) (Qty 4) M4 x 25 M5 x 12 (Qty 8) 5/16” Flat Washers (Qty 10) M5 x 16 (Qty 6) M5 x 20...
Page 10: Flat Panel Installation
FLAT PANEL INSTALLATION NOTE: If installing optional Camera Mount or Soundbar Mount, they must be installed prior to installing display. Refer to instructions I-00875 for Camera Mount and I-00876 for Soundbar Mount. Selecting The Mounting Hardware To Attach Brackets To Flat Panel 1.
Page 11 DISPLAY INSTALLATION (CONTINUED) Mounting Screws (4) Universal Washers (4) Display Mounts (2) FIGURE C Nylon Spacers (FIGURE D) Nylon spacers add distance between Display Mounting Brackets and display. They will fit all supplied screw sizes. The spacers must be used only when attaching displays which have: •...
Page 12 DISPLAY INSTALLATION (CONTINUED) Hanging the Display 1. Tilt display and hook display mounting brackets onto flange of horizontal display bracket into grooves along the top of the bracket. (FIGURE E) 2. Center display on horizontal display bracket, then push along the bottom of display until both display mount brackets click into place.
Page 13: Door Removal
FLAT PANEL INSTALLATION (CONTINUED) 4. Once display installation is complete, use level adjustment screws on top of display mount brackets to level display. (FIGURE H) 5. For security, a lock (not supplied) can be attached to security holes on both display mount brackets. Leveling Screws Bracket Security Holes...
Page 14 LEVER LOCK™ TOOL FREE INTERNAL MANAGEMENT SYSTEM The FlexView comes equipped with the following Lever Lock™ items: (4) LL receptacle brackets, (2) LL-HC21 horizontal channels, and (1) LL-VP1710 vertical 10” deep plate. Use Receptacle Brackets To Lace Cable Bundles Use Vertical From Top To Bottom Plate To Mount Small Devices...
Page 15: Unit Maintenance
CABLE MANAGEMENT / EQUIPMENT MOUNTING 1. Raise display to highest position before securing cables. Create a service loop to assure adequate cable length when display is fully extended. Cables can be secured to movable clips (provided) using wire ties. Secure Cable Management Clips into existing clip mounting holes in desired locations using supplied wood screws.
Page 16: Warranty
WARRANTY For warranty information, refer to www.middleatlantic.com/terms. Corporate Headquarters Corporate Voice: 973-839-1011 - Fax: 973-839-1976 / International Voice: +1 973-839-8821 Fax: +1 973-839-4982 www.middleatlantic.com - info@middleatlantic.com Middle Atlantic Canada Voice: 613-836-2501 - Fax: 613-836-2690 ca.middleatlantic.com - customerservicecanada@middleatlantic.ca Factory Distribution USA: NJ - CA - IL Canada: ON At Middle Atlantic Products we are always listening.
