INSTALLATION / OPERATING
INSTRUCTIONS FOR
LED CEILING PANEL
MODEL NUMBER: LEDP6640CW
Please read these instructions fully
before attempting installation.
IF IN DOUBT, INSTALLATION SHOULD
BE MADE BY A QUALIFIED
ELECTRICIAN IN ACCORDANCE WITH
CURRENT WIRING REGULATIONS.
• Typical applications commercial
buildings, schools, hospitals, offices etc.
ADVANTAGES
Energy saving up to 50%
•
• Even lighting output
• Instant start, no flicking, no humming
• Unique circuit design, each group of
LEDs work separately, avoiding any
problems with light output caused or
influenced by single faulty LED
• No RF interference
Super slim only 12mm thick
•

SAFETY INFORMATION

These instructions should be read carefully
prior to any installation and retained after
completion for further reference and
maintenance.
Please give these instructions to the building
owner/occupier after installation.
IMPORTANT
This unit should be installed to current
IEE wiring regulations, if in doubt please
consult a qualified electrician.

INSTALLATION INSTRUCTIONS

1. Remove a suitable 600 x 600mm
ceiling panel or an existing panel
light fitting.
2. Ensure the mains has been made
safe.
3. Connect the LED driver to the
230V AC mains supply, ensuring
Brown/Red goes to Live and
Blue/Black goes to neutral.
4. Connect driver output to LED panel
with the supplied connectors.
5. Position the LED panel into the
ceiling using existing frame.
6. Re connect supply and turn on to
check illumination.

NOTICE FOR USER

1. Do not disassemble the product.
2. Electricity supply should be turned
off when checking, replacing and
installing the panel.
3. Do not use water to clean the panel.
4. This product should only be used for
indoor lighting.
