- Page 1 Hardware Manual for the PCD7.D61x0TL series (embedded Windows XP) Controls Division Document 26/865; Version pEN1 | 2009-06-11...
-
Page 2: Table Of Contents
Saia-Burgess Controls AG Contents Content Content Document History ................... 0-3 Trademarks ..................... 0-3 Introduction Product description User side ......................2-2 Slot side ......................2-2 Interfaces ....................... 2-3 2.3.1 Compact Flash slot ..................2-3 2.3.2 VGA/COM1/PS/2 interface ................2-3 2.3.3 Ethernet, USB ....................2-4 Back ........................ - Page 3 Saia-Burgess Controls AG Contents Manual for the PCD7.D61x0TL series│Document 26 / 865│Version pEN 1│2009-06-11...
-
Page 4: Document History
Saia-Burgess Controls AG Contents Document History Version Published Changed Remarks pEN1 2009-06-11 Initial version Trademarks Saia ® is a registered trademark of Saia-Burgess Controls AG. Microsoft, Windows 2000, Windows XP, Windows CE and the Windows logo are either registered trademarks or trademarks of Microsoft Corporation in the USA and/or other countries. -
Page 5: Introduction
Saia-Burgess Controls AG Introduction Introduction The PCD7.D61x0 series is suitable for visualising process data of low to medium complexity. The process architecture used (AMD Geode LX800) gives the units a lower power leakage and higher operating temperature range than earlier x86 systems, combined with lower equipment costs. -
Page 6: Product Description
Saia-Burgess Controls AG Product description Product description The PCD7.D61xxTL series comprises compact, mechanically robust, fanless industrial PCs. This embedded PC system is supplied both as a box and in combination with high-contrast industrial colour TFT displays. Screen sizes of 10.4“, 12“ and 15“ are available. The analogue resistive touchscreen is the basis for man-machine communication. -
Page 7: User Side
Saia-Burgess Controls AG Product description User side; Slot side User side Colour resistive touch TFT display - 10.4“, 12“ or 15“ Slot side Manual for the PCD7.D61x0TL series│Document 26 / 865│Version pEN 1│2009-06-11... -
Page 8: Interfaces
Saia-Burgess Controls AG Product description Interfaces Interfaces 2.3.1 Compact Flash slot The PCD7.D61xxTL series web panels units are fitted with a CFA standard (type 1) Compact Flash slot as standard. Position of Captive screw Compact Flash slot Note: Only Compact Flash cards from SANDISK may be used in conjuction with the web panel. -
Page 9: Ethernet, Usb
Saia-Burgess Controls AG Product description Back 2.3.3 Ethernet, USB Ethernet 1 (RJ45) Ethernet 2 (RJ45) USB 1/2 Back Manual for the PCD7.D61x0TL series│Document 26 / 865│Version pEN 1│2009-06-11... -
Page 10: Commissioning
Saia-Burgess Controls AG Commissioning Power supply Commissioning Power supply The PCD7.D61xxTL devices must only be run on functional extra-low voltage with secure insulation in accordance with EN60950. The control transformer must comply with EN60742. The supply voltage must be checked against the type plate. When wiring the power supply andthe connector, the details on the type plate must be observed. -
Page 11: Earthing Concept
Saia-Burgess Controls AG Commissioning Earthing concept / Flush mounting / Switch-on Earthing concept To ensure that electrical faults are dealt with safely, the following points should be observed: ● Connect device and switching cabinet by the shortest route to a central earthing point. -
Page 12: Basic Settings And First Steps
Basic settings and first steps Saia-Burgess Controls AG Taskbar Basic settings and first steps This section is still being written and will be published with the next release. Manual for the PCD7.D61x0TL series│Document 26 / 865│Version pEN 1│2009-06-11... -
Page 13: Technical Data
Saia-Burgess Controls AG Technical data Physical dimensions Technical data Physical dimensions Clearance To ensure that the heat generated in the device can be dissipated, a 50 mm space must be kept clear around the unit. Manual for the PCD7.D61x0TL series│Document 26 / 865│Version pEN 1│2009-06-11... -
Page 14: 5.1.1 Pcd7.D6100Tlxxx Exterior/Flush Mounting Dimensions
Saia-Burgess Controls AG Technical data Physical dimensions 5.1.1 PCD7.D6100TLxxx exterior/flush mounting dimensions Front plate: Width 318 mm Height 244 mm Aperture size: Width 303 mm Height 228 mm Depth: 77 mm Weight: approx. 2.8 kg Type of fixing: 6 aluminium or plastic brackets with M5×30 grubscrews; DIN 914, with head and hexagonal recess, zinc-plated. -
Page 15: Pcd7.D6100Tlxxx Unit Dimensions
Saia-Burgess Controls AG Technical data Physical dimensions 5.1.2 PCD7.D6100TLxxx unit dimensions Blick auf die Geräteunterseite Seitenansicht Blick auf die Geräterückseite Seitenansicht Blick auf die Geräteoberseite 23.5 Manual for the PCD7.D61x0TL series│Document 26 / 865│Version pEN 1│2009-06-11... -
Page 16: 5.1.3 Pcd7.D6120Tlxxx Exterior/Flush Mounting Dimensions
Saia-Burgess Controls AG Technical data Physical dimensions 5.1.3 PCD7.D6120TLxxx exterior/flush mounting dimensions Front plate: Width 364 mm Height 296 mm Aperture size: Width 345 mm Height 277 mm Depth: 77 mm Weight: approx. 2.8 kg Type of fixing: 8 M4 threaded bolts recessed into the front plate. Surround thickness max. -
Page 17: Pcd7.D6120Tlxxx Dimensions
Saia-Burgess Controls AG Technical data Physical dimensions 5.1.4 PCD7.D6120TLxxx dimensions: Blick auf die Geräteunterseite Seitenansicht rechts Blick auf die Geräterückseite Seitenansicht links EPC/Z308/A Blick auf die Geräteoberseite 23.5 Manual for the PCD7.D61x0TL series│Document 26 / 865│Version pEN 1│2009-06-11... -
Page 18: 5.1.5 Pcd7.D6150Tlxxx Exterior/Flush Mounting Dimensions
Saia-Burgess Controls AG Technical data Physical dimensions 5.1.5 PCD7.D6150TLxxx exterior/flush mounting dimensions Front plate: Width 452 mm Height 334 mm Aperture size: Width 429 mm Height 334 mm Depth: 86 mm Weight: approx..kg Type of fixing: 6 aluminium or plastic brackets with M5×30 grubscrews; DIN 914, with head and hexagonal recess, zinc-plated. -
Page 19: Pcd7.D6150Tlxxx Unit Dimensions
Saia-Burgess Controls AG Technical data Physical dimensions 5.1.6 PCD7.D6150TLxxx unit dimensions: Blick auf die Geräteunterseite Seitenansicht rechts Blick auf die Geräterückseite Seitenansicht links EPC/Z308/A Blick auf die Geräteoberseite 23.5 Manual for the PCD7.D61x0TL series│Document 26 / 865│Version pEN 1│2009-06-11... -
Page 20: Electrical Data
Saia-Burgess Controls AG Technical data Electrical data / Environmental conditions Electrical data Model PCD7.D6100TLxxx PCD7.D6120TLxxx PCD7.D6150TLxxx Power supply Operating voltage 24 V ± 20%, reverse voltage protected Current consumption approx. 0.90 A approx. 1.10 A approx. 1.5 A Fuse 2.5 A slow-blow Jumper time 1 ms at 19.2 V (Ub-20%) Display unit... -
Page 21: Maintenance And Support
Saia-Burgess Controls AG Maintenance and support Battery changing / Replacing background lighting Maintenance and support Battery changing The devices are fitted with an integrated lithium battery for data buffering. Battery type: CR2032, 3V / 230mAh coin cells Manufacturer: e.g. Varta, type 6032 Buffer current: 2 µA typ. -
Page 22: Cleaning
Saia-Burgess Controls AG Maintenance and support Cleaning / Usage instructions for touch screens Cleaning Only mild cleaning agents should be used to clean the front of the unit (e.g. neutral soap solution or dilute washing-up liquid). Always use a clean, soft cloth for cleaning. Do not use any cleaning agents that contain granules (e.g. -
Page 23: A Annex
Saia-Burgess Controls AG Annex Icons Annex Icons In manuals, this symbol refers the reader to further information in this manual or other manuals or technical information documents. As a rule there is no direct link to such documents. This symbol means that death or serious injury may result if the relevant precautions are not taken. -
Page 24: Address Of Saia-Burgess
Saia-Burgess Controls AG Annex Address Address of Saia-Burgess Saia-Burgess Controls AG Bahnhofstrasse 18 CH-3280 Murten / Switzerland Tel: +41 26 / 672 71 11 Fax: +41 26 / 672 74 99 E-mail: pcd@saia-burgess.com Homepage: www.saia-pcd.com Support: www.sbc-support.ch Postal address for returns from customers of the Swiss Sales office: Saia-Burgess Controls AG Service Après-Vente...
