Connecting domestic hot water pump
This operation shall be performed by a person with necessary
qualifications to perform electric installation works.
The pump used to charge the household hot water tank shall be
to the socket (Fig. 4.) identified as "Pompa cwu", using a cable with cross-
section of at least 3x0.75mm
hot water tank's temp. sensor
above the power supply socket.
1
Fig.4. Tech ST-81 controller – rear view.
2
using suitable socket (included). The household
3
shall be connected to the socket located
2
3 4
2
connected
1. Power supply socket
2. Hot household water
pump socket
3. Household hot water
temperature sensor
socket
4. Central heating pump
socket
5. Fuse
5
