Lateral Isolator; Internal Safety System - Grammer MAXIMO Evolution Dynamic Operating Instructions Manual

Seat functions and operation
* if fitted ** depending on model
28

Lateral isolator *

Under certain operating conditions, it is useful
to activate the lateral isolator. This means that
lateral shock impacts can be better absorbed
by the driver's seat.
1
The cushioning effect can be activated with
0
the help of this locking lever.
0 lateral isolator OFF
lateral isolator ON
1
923

Internal safety system

If a power-consuming element fails, the
internal safety system should be checked first.
When viewing in the direction of travel, the
fuses are located in the area of the rear
suspension in the upper left, covered by the
bellows.
Before a fuse can be replaced, the bellows
must be removed on the upper side of the
suspension in the left rear area. Then the
93
defective fuse can be removed and replaced
by a new one.
Protection: 15A
You can identify a blown fuse when its
wire has melted; a blown fuse must always be
replaced by a new one of the same color and
with the same Ampere value.
*** optional extra
Do not bridge a blown fuse and
do not replace it by a fuse of
different color or with a different
Ampere value; otherwise the seat
may catch fire caused by
overloaded electrical lines.
GB
