Seat functions and operation
* if fitted ** depending on model
24

Swivel

The swivel is released by pulling the locking
lever. The seat can then be swivelled by 20
degrees to the right or to the left. It can be
locked into position at steps of 10 degrees.
WARNING. Risk of accident!
Do not operate the locking lever for
swivel while driving.
After the adjustment, the locking lever
must latch into the desired position with an
920
audible click. It should not be possible to
move the driver's seat into another position
when it is locked.

Fore/aft isolator

The fore/aft isolator improves the absorption
of shock impacts in the direction of travel by
the driver's seat.
The cushioning effect is permanently activated
and cannot be locked via an operating
element.
924

Fore/aft adjustment

The fore/aft adjustment is released by lifting
the locking lever.
WARNING. Risk of accident!
Do not operate the locking lever
while driving.
After the adjustment, the locking lever
must latch into the desired position with an
audible click. It should not be possible to
move the driver's seat into another position
919
when it is locked.
Do not lift the locking lever with your leg
or calf.
*** optional extra
