Xylem Goulds Marlow Series Instruction Manual
Cast iron swimming pool pumps
Hide thumbs
Also See for Goulds Marlow Series:
- Instruction manual (24 pages) ,
- Instruction manual (8 pages) ,
- Installation, operation and maintenance instructions (8 pages)
Table of Contents
Advertisement
Quick Links
INSTALLER: PLEASE LEAVE THIS MANUAL FOR THE OWNER'S USE.
Marlow Series Cast Iron
Swimming Pool Pumps
3B28EC – 3B32EC
PLEASE FILL IN DATA FROM YOUR
PUMP NAMEPLATE
Pump Model: _______________________________________
Spec. No. ___________________________________________
Serial No. ___________________________________________
Seal No. ____________________________________________
INSTRUCTION MANUAL
SAFETY INSTRUCTIONS
This safety alert symbol will be used in this manual and on the
pump instructions decal to draw attention to safety related
instructions. When used, the safety alert symbol means
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN
A SAFETY HAZARD.
SECTION 360A
AC1683
REVISION D
Advertisement
Table of Contents
Related Manuals for Xylem Goulds Marlow Series
Summary of Contents for Xylem Goulds Marlow Series
- Page 1 INSTRUCTION MANUAL SECTION 360A AC1683 REVISION D INSTALLER: PLEASE LEAVE THIS MANUAL FOR THE OWNER'S USE. Marlow Series Cast Iron Swimming Pool Pumps 3B28EC – 3B32EC PLEASE FILL IN DATA FROM YOUR SAFETY INSTRUCTIONS PUMP NAMEPLATE This safety alert symbol will be used in this manual and on the pump instructions decal to draw attention to safety related Pump Model: _______________________________________ instructions.
-
Page 2: Warranty
WARRANTY WARRANTY – Company warrants title to the product(s) and, except as noted with respect to items not of Company’s manufacturer, also warrants the product(s) on date of shipment to Purchaser, to be of the kind and quality described herein, and free of defects in workmanship and material. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANT- ABILITY AND FITNESS, AND CONSTITUTES THE ONLY WARRANTY OF... -
Page 3: Installation
CONGRATULATIONS You are now the owner of a Marlow pump. This pump was carefully inspected and subjected to final performance tests before releasing for shipment. In order to achieve maximum performance, please follow the simple instructions in this manual. RECOMMENDED PRECAUTIONS 1. -
Page 4: Replacement Parts
MAINTENANCE cont. WARNING tightening hand knob by hand only. The pump seal requires .. All electric work must be done by a licensed no lubrication. The electric motor has bearings and you electrician. Before working on motors be certain that the should refer to the motor manufacturer's instructions for e le ctrical power i s off at the main junction box. -
Page 5: Pump Parts List
INSTRUCTIONS FOR LICENSED ELECTRICIANS Be sure the motor is properly wired to match the voltage and WARNING phase of the power supply line. On three-phase motors be All electric work must be done by a licensed certain the motor is rotating in the proper direction. electrician. -
Page 6: Exploded View Drawing
EXPLODED VIEW DRAWING... -
Page 7: Troubleshooting Guide
TROUBLESHOOTING GUIDE NOTE: Never work on pump without making certain power is off. SYMPTOMS PROBABLE CAUSE RECOMMENDED ACTION 1. Pump will not prime 1. Suction air leak. Make sure strainer gasket is clean and properly positioned. Tighten strainer cover down snugly. Tighten all pipes and fittings on suction of pump. - Page 8 For more information on how Xylem can help you, go to www.xylem.com Xylem, Inc. 8200 N. Austin Avenue...
