Please read this installation manual completely before installing the product.
Installation work must be performed in accordance with the national wiring
standards by authorized personnel only.
Please retain this installation manual for future reference after reading it
thoroughly.
www.lg.com
Copyright © 2016 - 2019 LG Electronics Inc. All Rights Reserved.

Advertisement

Table of Contents
loading

Summary of Contents for LG ATUQ22GPLA4

  • Page 1 Installation work must be performed in accordance with the national wiring standards by authorized personnel only. Please retain this installation manual for future reference after reading it thoroughly. www.lg.com Copyright © 2016 - 2019 LG Electronics Inc. All Rights Reserved.
  • Page 2 TIPS FOR SAVING ENERGY TIPS FOR SAVING ENERGY Here are some tips that will help you minimize the power consumption when you use the air conditioner. You can use your air conditioner more efficiently by referring to the instructions below: •...
  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product WARNING It can result in serious injury or death when the directions are ignored CAUTION It can result in minor injury or product damage when the directions are ignored WARNING...
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS Operation • Do not share the outlet with other appliances. It will cause an electric shock or a fire due to heat generation. • Do not use the damaged power cable. Otherwise, it may cause a fire or electrical shock. •...
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS CAUTION Installation...
  • Page 6: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS TIPS FOR SAVING ENER- LEAKAGE TEST AND EVACUATION IMPORTANT SAFETY Preparation Leakage test INSTRUCTIONS Evacuation INSTALLATION OF OUT- TEST RUNNING DOOR UNIT INSTALLATION GUIDE AT WIRING CONNECTION THE SEASIDE Electrical Wiring CONVENIENT FUNC- Connecting Cables between Indoor Unit TIONS and Outdoor Unit Connecting the cable to Outdoor Unit...
  • Page 7: Installation Of Outdoor Unit

    Elevation B (m) Additional MODEL Refrigerant (g/m) Liquid Standard Max. Standard Max. ATUQ22GPLA4 Ø 12.7 (1/2) Ø 6.35 (1/4) Ø 12.7 (1/2) Ø 6.35 (1/4) ABUQ22GM1A4 ATUQ30GPLA4 Ø 15.88(5/8) Ø 9.52(3/8) Ø 15.88(5/8) Ø 9.52(3/8) ABUQ30GM1A4 AUUQ40GH4 Ø 15.88(5/8) Ø 9.52(3/8) AUUQ50GH4 Ø...
  • Page 8 INSTALLATION OF OUTDOOR UNIT Indoor unit Outdoor unit Indoor unit Outdoor unit CAUTION...
  • Page 9: Wiring Connection

    Circuit Breaker) between the power source and the unit. A disconnection device to ade- quately disconnect all supply lines must be fitted. - Model of circuit breaker recommended by authorized personnel only Model Phase(Ø) ELCB ATUQ22GPLA4 ABUQ22GM1A4 ATUQ30GPLA4 ABUQ30GM1A4 AUUQ40GH4 AUUQ50GH4 AUUQ60GH4...
  • Page 10: Connecting Cables Between Indoor Unit And Outdoor Unit

    The power cord connected to the outdoor unit should be complied with IEC 60245 or HD 22.4 S4 (This equipment shall be provided with a cord set complying with the national regulation. 10±3 mm Phase(Ø) Area(mm Model ATUQ22GPLA4 ABUQ22GM1A4 ATUQ30GPLA4 ABUQ30GM1A4 AUUQ40GH4...
  • Page 11 WIRING CONNECTION Precautions when laying power wiring Use round pressure terminals for connections to the power terminal block. Power wire Round pressure terminal When none are available, follow the instructions below. - Do not connect wiring of different thicknesses to the power terminal block. (Slack in the power wiring may cause abnormal heat.) - When connecting wiring which is the same thickness, do as shown in the figure below.
  • Page 12: Connecting The Cable To Outdoor Unit

    WIRING CONNECTION Connecting the cable to Outdoor Unit Remove the side panel for wiring connection. Use the cord clamp to fix the cable. Earthing work - Connect the cable of diameter more to the earthing terminal provided in the control box and do earthing.
  • Page 13: Connecting Pipes

    CONNECTING PIPES CONNECTING PIPES Preparation of Piping Main cause of gas leakage is defect in flaring work. Carry out correct flaring work in the following procedure. C C ut the pipes and the cable - Use the piping kit accessory or the pipes pur- chased locally.
  • Page 14: Connecting The Pipes To The Outdoor Unit

    CONNECTING PIPES Connecting the pipes to the Outdoor unit Align the center of the piping and sufficiently tighten the flare nut by hand. Finally, tighten the flare nut with torque wrench until the wrench clicks. - When tightening the flare nut with torque wrench, ensure the direction for tightening follows the arrow on the wrench.
  • Page 15: Forming The Piping

    CONNECTING PIPES Forming the Piping In cases where the Outdoor unit is installed above the Indoor unit perform the following. Form the piping by wrapping the connecting Tape the piping and connecting cable from portion of the indoor unit with insulation mate- down to up.
  • Page 16: Leakage Test And Evacuation

    LEAKAGE TEST AND EVACUATION LEAKAGE TEST AND EVACUATION Air and moisture remaining in the refrigerant CAUTION system have undesirable effects as indicated below. To avoid nitrogen entering the refrigerant - Pressure in the system rises. system in a liquid state, the top of the cylinder must be higher than its bottom - Operating current rises.
  • Page 17: Evacuation

    LEAKAGE TEST AND EVACUATION Evacuation - Replace the valve caps at both gas and liquid side service valves and fasten them tight. - Connect the charge hose end described in This completes air purging with a vacuum pump. the preceding steps to the vacuum pump to The air conditioner is now ready to test run.
  • Page 18: Test Running

    TEST RUNNING TEST RUNNING Precautions In Test Running - The initial power supply must provide at least 90 % of the rated voltage. Otherwise, the air conditioner should not be operated. CAUTION For test run, carry out the cooling operation firstly even during heating season. If heating operation is carried out firstly, it leads to the trouble of compressor.
  • Page 19 TEST RUNNING CAUTION After the confirmation of the above conditions, prepare the wiring as follows: Never fail to have an individual power specialized for the air conditioner. As for the method of wiring, be guided by the circuit diagram pasted on the inside of control box cover.
  • Page 20: Installation Guide At The Seaside

    INSTALLATION GUIDE AT THE SEASIDE INSTALLATION GUIDE AT THE SEASIDE In case, to install the outdoor unit on the CAUTION seaside, set up a windbreak not to be exposed to the sea wind. • Air conditioners should not be installed in areas where corrosive gases, such as acid or alkaline gas, are produced.
  • Page 21 Veuillez lire ce manuel dans son intégralité avant d'installer le climatiseur. L'installation doit être effectuée conformément aux normes électriques nationales par un personnel agréé uniquement. Après avoir lu ce manuel attentivement, conservez-le pour pouvoir vous y reporter ultérieurement. www.lg.com Copyright © 2016 - 2019 LG Electronics Inc. Tous droits réservés.
  • Page 22 ASTUCES POUR ÉCONOMISER L’ÉNERGIE\ ASTUCES POUR ÉCONOMISER L’ÉNERGIE\...
  • Page 23 Consignes importantes relatives à la sécurité Consignes importantes relatives à la sécurité LISEZ TOUTES LES INSTRUCTIONS AVANT D'UTILISER L'APPAREIL. Respectez toujours les précautions suivantes pour éviter les situations dangereuses et garantir un fonctionnement optimal de votre appareil. AVERTISSEMENT Le non-respect de ces consignes peut entraîner des blessures graves ou mortelles. ATTENTION Le non-respect de ces consignes peut entraîner des blessures mineures ou un endommagem- ent de l'appareil...
  • Page 24 Consignes importantes relatives à la sécurité Fonctionnement...
  • Page 25 Consignes importantes relatives à la sécurité ATTENTION Installation...
  • Page 26 TABLE DES MATIÈRES TABLE DES MATIÈRES ASTUCES POUR ÉCONO- TEST D'ÉTANCHÉITÉ ET MISER L’ÉNERGIE\ ÉVACUATION Consignes importantes Préparation relatives à la sécurité Test d’étanchéité Évacuation INSTALLATION DE L’UNITÉ TEST DE FONCTIONNEMENT EXTÉRIEURE GUIDE D'INSTALLATION RACCORDEMENTS ÉLE- EN BORD DE MER CTRIQUES FONCTIONS PRATIQUES Branchements électriques...
  • Page 27: Installation De L'unité Extérieure

    Longueur A (m) Altitude B (m) Réfrigérant MODÈLE supplémentaire (g/m) Liquide Standard Longueur max. Standard Longueur max. ATUQ22GPLA4 Ø 12.7 (1/2) Ø 6.35 (1/4) Ø 12.7 (1/2) Ø 6.35 (1/4) ABUQ22GM1A4 ATUQ30GPLA4 Ø 15.88(5/8) Ø 9.52(3/8) Ø 15.88(5/8) Ø 9.52(3/8) ABUQ30GM1A4 AUUQ40GH4 Ø...
  • Page 28 INSTALLATION DE L’UNITÉ EXTÉRIEURE Unité intérieure Unité extérieure Unité intérieure Unité extérieure ATTENTION...
  • Page 29 Un dispositif de déconnexion pour débra- ncher adéquatement toutes les lignes d'ali- mentation doit être installé. - Faites installer un disjoncteur de modèle recommandé par un personnel agréé uniquement MODÈLE Phase(Ø) Disjoncteur différentiel ATUQ22GPLA4 ABUQ22GM1A4 ATUQ30GPLA4 ABUQ30GM1A4 AUUQ40GH4 AUUQ50GH4 AUUQ60GH4...
  • Page 30 ATTENTION Le câble d’alimentation raccordé à l’unité extérieure doit être conforme à la norme CEI 60245 ou HD 22.4 S4 10±3 mm Phase(Ø) Zone(mm MODÈLE ATUQ22GPLA4 ABUQ22GM1A4 ATUQ30GPLA4 ABUQ30GM1A4 AUUQ40GH4 AUUQ50GH4 AUUQ60GH4 Le câble d’alimentation raccordé à l’unité extérieure doit être conforme à la norme CEI 60245 ou HD 22.4 S4(Cet équipement doit être muni d'un câble conforme à...
  • Page 31: Raccordements Éle- Ctriques

    RACCORDEMENTS ÉLECTRIQUES Précautions à prendre lors de la pose du câble d'alimentation Utilisez des bornes à pression rondes pour les raccordements à la plaque de bornes d'alimentation. Fil d'alimentation Borne à pression ronde En l'absence d'instructions, suivez les recommandations ci-dessous. - Ne branchez pas des fils d'épaisseurs différentes à...
  • Page 32 RACCORDEMENTS ÉLECTRIQUES Raccordement des tuyaux à l'unité extérieure Retirez le panneau latéral pour le raccordement du câble. Utilisez un collier de serrage pour fixer le câble. Mise á la terre - Raccorder le câble plus épais à la borne de mise à la terre fournie dans la boîte de contrôle et effectuez la mise à...
  • Page 33: Tuyaux De Raccordement

    TUYAUX DE RACCORDEMENT TUYAUX DE RACCORDEMENT Préparation de la tuyauterie La cause principale des fuites de gaz est un défaut d'évasement.Il convient donc d'effectuer les raccordements en respectant la procédure suivante. Découpe des tuyaux et du câble - Utilisez le kit d'accessoires de tuyauterie ou les tuyaux achetés sur place.
  • Page 34: Raccordement Des Tuyaux À L'unité Extérieure

    TUYAUX DE RACCORDEMENT Raccordement des tuyaux à l'unité extérieure Alignez le centre du tuyau et serrez le raccord Tuyauterie côté liquide conique à la main. (diamètre plus petit) Serrez ensuite le raccord conique à l'aide d'une clé dynamométrique jusqu'à ce que vous entendiez un clic.
  • Page 35: Monter La Tuyauterie

    TUYAUX DE RACCORDEMENT Monter la tuyauterie Si l'Unité extérieure est installée au-dessus de l'unité intérieure, procédez comme suit. Montez la tuyauterie en enveloppant la partie de raccordement de l’unité intérieure de mat- Enveloppez de ruban adhésif la tuyauterie ériau isolant et fixez-la avec deux types de et le câble de liaison du bas vers le haut.
  • Page 36: Test D'étanchéité Et Évacuation

    TEST D'ÉTANCHÉITÉ ET ÉVACUATION TEST D'ÉTANCHÉITÉ ET ÉVACUATION L’air et l’humidité restants dans le système ATTENTION réfrigérant ont des effets indésirables tel qu’il est indiqué ci-dessous. Pour éviter que l'azote ne pénètre dans le - La pression dans le système augmente. système de réfrigération à...
  • Page 37: Évacuation

    TEST D'ÉTANCHÉITÉ ET ÉVACUATION Évacuation - Mettez de nouveau en place les capuchons sur les vannes de service, côtés gaz et liquide - Reliez l’extrémité du tuyau de charge décrit et serrez-les. dans les étapes précédentes à la pompe à L'évacuation de l'air avec la pompe à...
  • Page 38: Test De Fonctionnement

    TEST DE FONCTIONNEMENT TEST DE FONCTIONNEMENT Précautions pendant le Test de Fonctionnement - L'alimentation électrique initiale doit assurée au moins 90% de la tension nominale. Autrement, le climatiseur ne peut pas fonctionner. ATTENTION compresseur.Donc, faites attention. Effectuez impérativement le test pour plus de 5 minutes. (Le test sera annulé...
  • Page 39 TEST DE FONCTIONNEMENT ATTENTION Après vous être assuré que les conditions ci-dessus sont remplies, effectuez le câblage comme suit. Prévoyez toujours une alimentation électrique séparée pour le climatiseur.Comme pour le câblage, référez-vous au schéma électrique figurant à l'intérieur du couvercle du boîtier de commande.
  • Page 40: Guide D'installation En Bord De Mer

    GUIDE D'INSTALLATION EN BORD DE MER GUIDE D'INSTALLATION EN BORD DE MER ATTENTION Si l'unité extérieure est néanmoins installée en bord de mer, érigez un coupe-vent de sorte qu'elle ne soit pas exposée au vent marin. allés dans des zones où sont produits des gaz corrosifs, tels que des gaz acides ou alcalins.
