Self Service Manual
This Self Service Manual describes all approved service procedures for the Rusoh
including the following:
I. Replacing Tamper Seal (page 2)
II. Replacing Hose Strap (page 2)
III. Replacing Rusoh
IV. Replacing Handle Assembly (page 3)
V. Replacing Valve Assembly (page 4)
VI. Replacing Instruction Label (page 4)
VII. Reloading Information (page 5)
VIII. Disposal Procedure (page 5)
IX. Replacement Parts and Accessories (page 6)
Fig. A
REFER TO THE OWNER'S MANUAL FOR INSTALLATION, OPERATION, 30-DAY INSPECTION, ANNUAL INSPEC-
TION, AND WARRANTY INFORMATION.
For more information, visit www.rusoh.com.
SAVE THIS SELF SERVICE MANUAL FOR FUTURE REFERENCE.
©2018 RUSOH Inc.
ELIMINATOR
SELF SERVICE, RELOADABLE,
DRY CHEMICAL FIRE EXTINGUISHER
Fluffing Wheel (page 3)
™
CO
CARTRIDGE
2
Cartridge cover
Puncture lever
Tamper seal
Lock
Tag loop
Alignment marking
Alignment rib
AGENT CARTRIDGE
with instruction label
Rusoh
™
fluffing wheel
®
®
Handle
Hose clip
Hose
Valve lever
Valve nozzle
For Model Numbers
SELF SERVICE 0930001
SELF SERVICE 0930002
Eliminator
fire extinguisher,
®
®
DISCHARGE HEAD
VALVE ASSEMBLY
Form 76-410B
Advertisement
Table of Contents
Related Manuals for Rusoh ELIMINATOR
Summary of Contents for Rusoh ELIMINATOR
- Page 1 SELF SERVICE 0930001 SELF SERVICE 0930002 ELIMINATOR ® SELF SERVICE, RELOADABLE, DRY CHEMICAL FIRE EXTINGUISHER This Self Service Manual describes all approved service procedures for the Rusoh Eliminator fire extinguisher, ® ® including the following: I. Replacing Tamper Seal (page 2) II.
- Page 2 Self Service Procedures IMPORTANT: After repairing/replacing any parts of this fire extinguisher, it is recommended that you perform the Annual Inspection described in the Owner’s Manual. I. Replacing Tamper Seal 1. Ensure the lock on the discharge head is in the horizontal (locked) position (Fig. B). 2.
- Page 3 NOTE: The screw is locked in place with adhesive; the initial torque to loosen the screw will be high. Remove and recycle the damaged wheel. 2. Place the new Rusoh™ wheel onto the bottom of the inverted agent cartridge, Rusoh ™...
- Page 4 6. Secure the handle to the extinguisher with the four screws provided. Tighten the screws using a power screwdriver, set to 10 inch-pounds maximum. NOTICE: Overtightening can result in the stripping of screws. 7. Follow the Annual Inspection procedure found in the Owner’s Manual to reinstall the CO cartridge and place the extinguisher back into service.
- Page 5 Avoid flowers and grasses. 2. Remove the CO cartridge from the Eliminator™ discharge head and confirm it is punctured. If it is not, return the cartridge to the unit and repeat the discharge procedure outlined in step 1 above.
- Page 6 IX. Replacement Parts and Accessories The following replacement parts can be ordered by calling the Rusoh Customer Service Department at 1-800-318-2944: Inspection Tags PN 76-213 Tamper Seals (indicator) PN 81-534 Rusoh™ Fluffing Wheel PN 81-584 Hose Strap PN 81-533 Valve Assembly (model specific)
