47 Inch Triple Swivel Surface Cleaner
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #63594
READ & SAVE THESE INSTRUCTIONS
Advertisement
Table of Contents
Related Manuals for North Star 63594
Summary of Contents for North Star 63594
- Page 1 47 Inch Triple Swivel Surface Cleaner Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #63594 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a NorthStar™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Main Parts of Surface Cleaner ......................7 Assembly Instructions .......................... 7 Before Each Use ............................ 9 Operating Instructions .......................... -
Page 4: Intended Use
Intended Use The NorthStar 47 Inch Triple Swivel Surface Cleaner is designed for high-pressure cleaning of a variety of outdoor surfaces. The surface cleaner attaches to a pressure washer offering faster cleaning without streaks. Its ultra-wide 47” width cleans up to 20 times faster than a pressure washer with a standard nozzle. - Page 5 ⚠WARNING WORK AREA SAFETY • Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas may put you dangerously close to cutting tools and rotating parts. •...
-
Page 6: Specific Operation Warnings
product with a damaged part. • Do not use a product with a malfunctioning switch. Any power tool that cannot be controlled with the power switch is dangerous and must be repaired by an authorized service representative before using. • Disconnect the power/air supply from the product and place the switch in the locked or off position before making any adjustments, changing accessories, or storing the tool. -
Page 7: Main Parts Of Surface Cleaner
Main Parts of Surface Cleaner Subassembly Spray Wand with Quick Connects Lance with Quick Connects Handle Bar Cover with Castor, Swivels, and Frame Assembly Instructions ⚠WARNING • Do not connect to a water source until the surface cleaner is fully assembled. Page 7 of 16... - Page 8 Check the contents of the shipping carton against the Packaging Contents to ensure all parts are present. 1. Insert the handlebar into the frame and secure it using the two bolts (18) and two spring clips (13). 2. Screw in the bottom of the hose to the swivel piping (shown below, left) and the top to the connection at the wand (17).
-
Page 9: Before Each Use
Before Each Use Perform the following inspections before each use to ensure the surface cleaner is working properly. • Check for any worn or damaged parts. Replace any damaged part before using the surface cleaner. • Check that all parts are tightly fastened. Tighten any that are loose. •... -
Page 10: After Each Use
After Each Use Perform the following inspections after each use to clean the surface cleaner and prepare it for the next use. • Clean out any dirt or foreign material from under the housing, wheels, and casters. If necessary, use a cloth or sponge to wash the surface cleaner and rinse it with tap water. •... -
Page 11: Replacing The Swivel Fixture
Replacing the Swivel Fixture 1. Remove the hose bottom connection (shown below, left) then remove the swivel piping from the top of the housing (below right). 2. Support the swivel fixture from the bottom housing with a rolled-up cloth to avoid the fixture dropping to the floor, possibly damaging it. -
Page 12: Troubleshooting
The following chart is based on a normal operation schedule. Maintenance Interval Maintenance Point • Check for any worn or damaged parts. Replace any such part before using the surface cleaner. • Check that all the parts are tightly fastened. Tighten any that are loose. -
Page 13: Parts Diagram
Parts Diagram 6, 7, 8 Page 13 of 16... -
Page 14: Parts List
Parts List Ref. Number Part Number Description Quantity 63594.1 Handle Bar 63594.2 Long Hose 63594.3 Housing 63594.4 Complete Wheel Component 63594.5 Twin Caster 63594.6 Easy Repair Kit 63594.7 High Pressure Filter 63594.8 Complete Swivel 63594.9 Cap Nut 63594.10 Washer 63594.11 Bearing 63594.12... -
Page 15: Limited Warranty
Limited Warranty Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the NorthStar product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of two years from date of purchase for consumer household use. - Page 16 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in Germany Page 16 of 16...
