- Page 1 MPB S.r.l. Tel +39 0641200744 Via Giacomo Peroni 400/402 Fax +39 0641200653 00131 Rome - Italy info@gruppompb.com www.gruppompb.uk.com User manual Contact Current Meter Updated to Firmware Version: CCM V.1.09 CCM user manual V. 1.15...
- Page 2 This product is intended for industrial environments and laboratories and should be used by authorized personnel only. The CCM was designed and developed to be used according to the norms and regulations of the country where the worker is operating in.
- Page 3 D e c l a r a t i o n of c o nf or m i t y (according to EMC 89/336/EEC directive and low voltage 73/23/EEC) This is to certify that the product: CCM (Contact Current Meter)
-
Page 4: Table Of Contents
Display all the values in the three bands ................. - 11 - 3.2. Auto measure and store ....................- 11 - 3.3. Enable the option ......................- 12 - CCM usage ..........................- 13 - 4.1. Turn on ..........................- 13 - 4.2. First use ........................... - 13 - 4.3. - Page 5 Kit case ..........................- 29 - Jig – Functioning ........................- 30 - 7.1. Equipment ........................- 30 - 7.2. Install the CCM on the JIG ....................- 30 - 7.3. “Ground Plane” test ......................- 31 - 7.4. “Hand” test ........................- 32 - 7.5.
-
Page 6: General Information
USER MANUAL 1. General information 1.1. Introduction CCM was designed to measure in a fast and accurate way the contact current that may be generated when touching electrical/electronic equipment inside a radio frequency field. 1.2. Description CCM (Figure 1-1. CCM) is a portable measuring device with two measurement modes. -
Page 7: Optional Kit
Cable (length 1 m) N(M) sma(M) 1.3.3. Optional Item IEC-60990 Body Simulation Impedance 1.4. Front In Figure 1-2 is shown the CCM front panel: Figure 1-2. CCM front 1.5. Rear In Figure 1-3 is shown the CCM rear panel: Figure 1-3. -
Page 8: Technical Specification
Low band 40 Hz to 2.5kHz Medium band 2.5 kHz to 100 kHz High band 100 kHz to 110 MHz (CCM); 100 khz to 10 MHz (CCM-A) Frequency Response Low band @ 1 mA < ± 1.5 dB Medium band @ 100% <... -
Page 9: Principle Of Operation
Figure 2-1. CCM block diagram 2.2. Measurements The CCM digital nature allows it to measure contact currents through the true RMS (Root Mean Square) value for all analog signals from 40Hz. The RMS value of a waveform signal is equal to a DC current which provides the same power to the load. -
Page 10: Safety
CCM. For more details please scroll down to 4.4. Figure 2-2. GP cover... -
Page 11: Display All The Values In The Three Bands
By activating this functionality, the user is enabled to: program the CCM for automatic read program CCM for starting the measure at specific time and for synchronizing measure between multiple CCMs (if necessary) program CCM for storing the average of measures... -
Page 12: Enable The Option
USER MANUAL For this functionality, the Option CCM-AUTO MEASURE is required (contact your MBP representative for enabling it). 3.3. Enable the option The steps for options enabling are listed below: copy and paste the passkey.txt file received by mail into CCM... -
Page 13: Ccm Usage
Figure 4-2. CCM Menu 4.2. First use If the CCM has just been switched on (or if it's been more than one minute since the last measurement) it is in STANDBY mode. At the first use, the user will have to set date &... - Page 14 (if enabled) and, simultaneously, by a brighter display illumination. All measures are automatically stored by the CCM. In both modes the measuring tip of the CCM must never be removed from the equipment under test. Figure 4-3. GP cover message Figure 4-4.
-
Page 15: Standby Screen
Ground Plane before doing the HAND measurement (so that, in extreme cases, a high current will simply discharge on the ground). In the Hand measurement mode the CCM will instead consider the real impedance value of the human body. - 15 -... -
Page 16: Bandwith / Total
USER MANUAL Figure 4-6. Hand or GP mode 4.5. Bandwith / Total The central key, BW/T, allows the user to choose the visualization mode: BANDWITH: Display of the measurement divided by bands (or selective measurement), with the final result expressed in mA. ... -
Page 17: Built-In Self-Test
WARNING: in case of such message the instrument cannot be used and it will be mandatory to send it back to MPB for a full check. In case the test is passed, a GP mode measurement (always through the cover provided) will be allowed. Performed the measurement and stored the data, it will be allowed to switch to Hand mode, after showing the message “warning HAND mode, remove the cover”. - Page 18 USER MANUAL Figure 4-8. Flow Chart - 18 -...
-
Page 19: Ccm Menu
From the standby screen, by pressing the MENU key, you will reach the screen shown in Figure 4-11. This screen is intended as a reminder for the user, since it displays the limit values for which the CCM is designed. - 19 -... -
Page 20: Beep On Press
USER MANUAL Figure 4-11. Limits 4.7.2.Beep on press The second page of the menu allows you to enable or disable the beep every time you press the corresponding key. To change this setting enter the page by pressing the key SET, as in Figura 4-12. Figura 4-12. -
Page 21: Auto Off
USER MANUAL Please do not forget that the percentage value is parametric compared to the frequency of the input signal (see the graph shown on the first page of the menu - Chapter 4.7.1). Figure 4-13. Alarm 4.7.4. Auto off Through this setting the user can decide how long after inaction it will take before the device will automatically shut down. -
Page 22: Data & Time
USER MANUAL 4.7.5. Data & Time The fifth menu item allows you to change the date and time of the device (Figure 4-15). It is important that this information is correct, because the results of the measurements in the downloaded data (csv file generated by the device) are associated with the day and time of the measurements. -
Page 23: Clear Data
Example: Figure 4-18. Example A In this mode, clicking the orange trigger, the CCM reads every 5 seconds and stores the measurements up to 100 values. B. measure the value in repetition mode and start at a specific time (used to synchronize measurements): ... - Page 24 Figure 4-19. Example B IMPORTANT: use “ : ” (two points) to separate hours: minutes: seconds By setting desired time into CCM, the instrument starts automatically the measurements, repeats every 5 second and stores the measurements up to count 100 measures.
- Page 25 2. copy this file into CCM 3. disconnect the CCM from the PC 4. reboot CCM by switch OFF and switch ON 5. after confirming the security message, the display shows: a. Auto Read detected = if have setup only time to start b.
-
Page 26: Data Download
The data downloading operation has been designed to improve the speed and simplicity of use. The data generated by the CCM are stored in csv (comma separated value), which is a text file with value separators. This allows the user to read, edit and process the downloaded data via various software including MS Excel. -
Page 27: Data Format
USER MANUAL 5.2. Data Format Measurement by measurement, the device forwards, to the only data.csv file generated, all the information about a measurement. More specifically, the stored data are ordered as follows: Date & Time Total value Measurement (expressed in %) For workers. ... -
Page 28: Jig - General Information
Figure 6-1. CCM and JIG 6.2. Description The JIG is built on an iron base, with a connector to be plugged to the CCM's Jig room, an iron locking stirrup designed for the HAND plate, and adaptive connectors designed for the contact current meter. This guarantees a stable support during the test procedure. -
Page 29: Kit Case
USER MANUAL 6.4. Kit case In Figure 6-2 is shown the complete Kit for the CCM: Figure 6-2. Case In Figure 6-3 is shown the inner compartment of the case: Figure 6-3. Case compartment - 29 -... -
Page 30: Jig - Functioning
7.2. Install the CCM on the JIG To install the CCM on the JIG in order to be able to make a calibration, first of all we need to remove the TIP from the CCM, simply by sliding it out, as shown in Figure 7-2. -
Page 31: Ground Plane" Test
Figure 7-3. Set Up the JIG The next step is to lock down the CCM with the special JIG lock using the knobs, so that the HAND plate will be connected to the lock sma connector (the result is shown in Figure 7-4). -
Page 32: Hand" Test
USER MANUAL As already described on the CCM manual, the GROUND PLANE measure has to be done before the HAND measure. To properly connect the device plane connector to the generator we will use our N-sma cable and the R45 resistance as in Figure 7-5. -
Page 33: Certificate Measurements
In this band (from 40 Hz to 2,5 kHz) the limit for workers is 1 mA, so the 100% is equal to 1 mA. To test the correct functioning of the CCM at low frequencies, please set the frequency of the generator at 1 kHz and the power at -13.01 dBm. -
Page 34: Medium Band
100%, corresponding to a 20 mA. 7.5.3.High band In this band (from 100 kHz to 110 MHz - to 10 MHz for the CCM-A version) the limit for workers is 40 mA, so the 100% is equal to 40 mA. Within the high frequencies range, setting the frequency at 10 MHz and the power at +19.03 dBm, you will obtain... -
Page 35: Software Update
USER MANUAL 8. Software update 7.6. Instruction for Firmware upgrade Installation of new versions of CCM firmware requires to follow these steps: 1. Go to MPB web site on download section (http://www.gruppompb.uk.com/download.asp#mpb) 2. Download the new release of firmware (file CCM_ver1_xx.txt) Figure 8-1 3.
