Summary of Contents for Levil Aviation iLevil 3 AW
- Page 1 iLevil Wireless Integrated Avionics Module Instruction Manual AD-AHRS, GPS, ADS-B 978 / 1090 MHz Receiver, Data recorder...
- Page 2 3 AW CARD PORT ADS-B ANTENNA ANTENNA DB 15 MINI USB POWER/GPS DYNAMIC STATIC SERIAL PORT PORT PRESSURE PRESSURE ADS-B CHARGING ON/OFF SWITCH...
-
Page 3: Package Contents
Package Contents • Wireless iLevil3 AW • USB to Mini USB cable • ADS-B Antenna • GPS Antenna • DB15 male connector • User Manual • SD Card Charge before use When using the iLevil3 AW as a “portable” device, you must first charge the internal batteries: •... - Page 4 Alignment • Attach the supplied ADS-B antenna and GPS antenna. See top label for reference. • Align the airplane icon on the iLevil’s top label with the roll axis of your aircraft. • ON/OFF switch should face the back of the aircraft. •...
- Page 5 Connecting to your favorite App The iLevil series offers the most compatibility with Apps on both iOS and Android platforms. • Turn ON your iLevil withthe ON/OFF switch. (LEDs will light up) • Tap Settings icon on your tablet. • Tap WiFi and connect to the iLevil3 – xxxx network, where “xxxx” is the unique serial number. •...
-
Page 6: Led Indicators
LED Indicators Label Status Description Power/GPS Slow Blink Green: Power ON / No GPS Fix Solid Green: Power ON / GPS fix acquired Power Off ADS-B Slow Blink Green: Traffic Received Solid Green: Weather and traffic received Off: No traffic or Weather received Charging Charging Solid Green:... -
Page 7: Magnetic Heading
Magnetic Heading There are two ways to obtain heading information from the iLevil, depending on the navigation App of choice, you may choose between the following: -True Track: Heading information based on GPS track. -Magnetic Heading: Heading information determined by a combination of 3-axis magnetometer and gyros that form part of the internal AHRS. -
Page 8: Specifications
Specifications AHRS WIFI • 360 degree pitch and bank operation • Android and iOS compatible • GPS Independent attitude. • Supports up to 7 devices connected simultaneously (UDP • 300 deg/sec max turn rate broadcast) • 4Gs max rating. • Supports multiple protocols: •... -
Page 9: Environmental Requirements
Environmental requirements • Temperature range: -10° to 40 ° C (14 ° F to 104 ° F). • Antenna with clear view to sky for best GPS reception. • For best ADS-B reception, antenna with line of sight view with ADS-B ground based towers and min 2000 ft. •... - Page 10 Levil Data Relay The iLevil3 AW features three RS-232 serial ports that can be used for data transfer between tablets and other avionics in the cockpit. For more information check the iLevil Relay feature on our website www.aviation.levil.com or email: info@levil.com DB15 pin description PIN 1: 5V IN PIN 10: AUX Relay port 0 RX (receive)
- Page 11 AHRS Utility APP AHRS utility is a free application designed to display AHRS data graphically and numerically. User must be connected to the Wi-Fi network of the iLevil. • • The application will NOT display airplane attitude based on the internal gyros of your iPad/iPhone or GPS data. Air data is only available on the AW model.
- Page 12 Engine Config: User must have a compatible EIS connected to the iLevil to display this information. All gauges can be set up to display desired information. NOTE: Device Config option should only be used with the advice of Levil Aviation Tech Support. Any settings changed incorrectly in this tab can lead to iLevil malfunctioning!
- Page 13 Data Recording (SD CARD) The iLevil will automatically begin recording if the unit is powered on with an SD card already inserted. • If the iLevil is powered on with NO SD card inserted, recording will begin by simply inserting SD card. •...
- Page 14 Data Recording (SD CARD) How to change Callsign: Open AHRS Utility • • Tap on the Device Config tab. Scroll down to find Callsign. • Tap and type desired Callsign • Press Apply • How to use Triggers: Triggers are for use while recording in .csv format.
-
Page 15: Helpful Tips
Helpful Tips • If you encounter WiFi connection problems, try resetting the tablet’s WiFi (disable/enable) • If using Apple devices, you may use our free AHRS Utility App to see battery percent, GPS signal power, ADS-B diagnostics etc. • Do Not switch the iLevil ON/OFF button swiftly when resetting power to the iLevil. •... - Page 16 Contact Us Technical Support: General Information: Sales: 407-542-3971 407-542-3971 407-542-3971 techsupport@levil.com info@levil.com sales@levil.com www.aviation.levil.com/support www.aviation.levil.com www.aviation.levil.com 1704 Kennedy Point Suite 1124 Oviedo, Fl 32765...
