Photocells - Microgate WITTY User Manual

2.2 P
HOTOCELLS
To switch on the photocell press the ON button for one second; the status LED blinks with a green light (if
the battery status is sufficient) or with an orange light (if the battery status is low). A continuous beeping
sound is produced until the correct alignment with the reflector (or a similar reflecting surface) is found.
To switch off the photocell press the button until the LED turns red, then release it.
Witty User Manual - EN - v1.5
ON/OFF button
Status Led
USB connector for charging
and updating the firmware
3.5mm jack for photocell
pair and external inputs
P. 10 / 171
