- Page 1 Installation Manual Intelligent EV Charging Station R7 and R22 Series V191002 Installers please provide end user with the accompanying User Manual As well as standard installation tools the following is required: • T20 TORX SECURITY BIT • NO.2 SQUARE DRIVE BIT •...
-
Page 2: Please Note
Please note Read all instructions before installing or using this product. This Installation Manual is current at the time of printing. Evnex Ltd. reserves the right to make changes to this document or the products described without notice. For questions relating to this product, its use or installation, please refer... -
Page 3: Table Of Contents
Checklist..........................21 Installing the front cover ....................22 Operation ..........................23 Status display ........................23 Initialisation ......................... 23 Charging process ........................ 24 LED modes / fault conditions..................... 25 Technical information ......................26 Troubleshooting ........................28 Evnex R-Series Installation Manual | V191002... -
Page 4: Introduction
Introduction Product description The Evnex R-Series charging stations are a cost effective smart charging solution, available in both single phase 7kW, and three phase 22kW configurations. When connected to a compatible OCPP (Open Charge Point Protocol) server, the Evnex R-Series charging stations become an excellent choice for smart-grid managed charging or public charging, where energy metering or access control is required. -
Page 5: General Dimensions
General dimensions Evnex R-Series Installation Manual | V191002... -
Page 6: About This Document
About this document The following document describes the functionality and installation procedures for the Evnex R-Series of electric vehicle charging stations. Scope of this document This document only refers to the following R-Series charging stations, please refer to the correct documentation if this does not apply. -
Page 7: Symbols
You will find the following symbols throughout this document. Please pay attention to the recommendations. CAUTION – Failure to follow these directions may cause minor injury or damage to equipment. WARNING – Failure to follow these directions may cause serious injury or death. Evnex R-Series Installation Manual | V191002... -
Page 8: Safety Information
Do not use extension cords or any kind of adapter with this • product • This product should not be used by children Avoid installing this product in locations that are prone to flooding • Disclaimer Evnex R-Series Installation Manual | V191002... -
Page 9: Installation
Evnex Limited shall not be liable in any way for damage or injury that occurs when using the product, and all warranties will be void where: • The installation instructions have not been followed correctly • The product has been installed by an unqualified person The product has been tampered with or modified •... -
Page 10: Site Selection
Ensure that the attachment surface is flat - an uneven surface may • warp the enclosure and prevent installation of the front cover Consider signage locations for warnings such as “Trip Hazard” if • applicable Evnex R-Series Installation Manual | V191002... -
Page 11: Mounting Notes
The mounting locations on the top left and right corners of the unit are NOT TO BE DRILLED in standard installations. These mounting points are for non-standard installations and require additional sealing. Evnex R-Series Installation Manual | V191002... -
Page 12: Fasteners
Fasteners Locate the packet labelled INSTRUCTION MANUAL & FASTENERS containing the following: *No.2 square bit required **Torx T20 security bit required Evnex R-Series Installation Manual | V191002... -
Page 13: Opening The Unit
The cover has a tether to decrease risk of wire strain. This tether can be looped into the recess in the top right corner of the enclosure to keep the cover out of the way during installation. Evnex R-Series Installation Manual | V191002... -
Page 14: Mounting Unit
The location of the optional rear entry hole (M25 or M32) is also provided, along with the optional M12 hole location. M12 and M32 holes need to be drilled by the installer if required. Evnex R-Series Installation Manual | V191002... -
Page 15: Timber Framed Wall Mounting Example
Timber framed wall mounting example Evnex R-Series Installation Manual | V191002... -
Page 16: Solid Wall Mounting Example
Recommended hole depth is 40mm with a 7mm masonry bit. For all types of installation ensure that the washers are installed on the screws and that the sealing plugs are installed after the screws are firmly tightened. Evnex R-Series Installation Manual | V191002... -
Page 17: Wiring Connection
The R-Series are ‘mode 3’ charging stations. Due to their high current consumption, they must be connected to a dedicated feed from the main distribution board. The R-Series of charging stations are not designed to charge vehicles that require ventilation systems during charging. Evnex R-Series Installation Manual | V191002... -
Page 18: Single Phase Wiring Example
Single phase wiring example Evnex R-Series Installation Manual | V191002... -
Page 19: Three Phase Wiring Example
Three phase wiring example Evnex R-Series Installation Manual | V191002... -
Page 20: Upstream Protection
The RCD must comply with one of the following standards; IEC 61008-1, IEC61009-1, IEC 60947-2 or IEC 62423 The Circuit breaker must comply with one of the following standards; IEC 60898-1, IEC 60947-2 or IEC 61009-1. The RCBO must comply with IEC 61009-1. Evnex R-Series Installation Manual | V191002... -
Page 21: Setting The Maximum Charge Current
Depending on the capacity of your upstream supply, the maximum charging current can be set during installation. To do this, download the ‘Evnex Installation’ app from the Apple store for iOS, or the Google Play store for Android. 1. Download the installation app 2. -
Page 22: Closing The Unit
Check that the seal is properly pushed into the groove all the way around and that there is nothing preventing the cover closing or sealing properly. Install the cover, tightening the ten cover fasteners using a T20 Torx security bit Evnex R-Series Installation Manual | V191002... -
Page 23: Installing The Front Cover
Installing the front cover Evnex R-Series Installation Manual | V191002... -
Page 24: Operation
OCPP server. When the NETWORK light begins to fade in and out slowly, the charging station has successfully established a connection with the server. Evnex R-Series Installation Manual | V191002... -
Page 25: Charging Process
It is normal to notice the sound of the contactor inside the charging station closing or opening during the beginning or end of the charging process. During the charge, the CHARGE light on the unit will glow green. Evnex R-Series Installation Manual | V191002... -
Page 26: Led Modes / Fault Conditions
Single flash Single flash RFID tag detected 5 flashes RFID tag not recognised Do not use the charging station if the plug and lead or socket are cracked, frayed, or damaged in any way Evnex R-Series Installation Manual | V191002... -
Page 27: Technical Information
RX(X)-TXX-LTE series LTE bands (LTE-M)…….…..………………………1, 2, 3, 4, 5, 8, 12, 13, 18, 19, 20, 25, 26, 28 Communication and protocols OCPP version…………………………………………………………………………………………….1.6J (JSON) Mobile app configuration………………………………………………………………………..Bluetooth LE RFID……………………………………………………………………………….……ISO/IEC 14443, 13.56MHz Energy metering……………………………………………………………..………………..Yes, MID certified Evnex R-Series Installation Manual | V191002... - Page 28 °C Ground fault detection…………...…………………………………………………………………………….…Yes Connections / terminals Mains input………………….…………………………………………………...………………………10mm2 max SIM card…………………………………….………………………………………...……………..Nano SIM (4FF) Dimensions Height……………..……………………………………………………………………………..……………………373mm Width……………………………..…………………………………………………………………...………………212mm Depth…………………………………………..……………………………...………………………………………142mm Regulatory The product complies with the following standards • IEC 61851-1:2017 • IEC 61851-21-2:2018 • RoHS Evnex R-Series Installation Manual | V191002...
-
Page 29: Troubleshooting
The unit responds with 5 red flashes Ensure that the RFID card is when swiping an RFID card recognised and correctly loaded in the back office software Evnex R-Series Installation Manual | V191002... - Page 30 Problem Solution Red FAULT indicator on Check the mobile app or back office software for the cause of the fault If any issues persist, please contact customer support. SDoC available on request. Evnex R-Series Installation Manual | V191002...
