TECHNICAL INFORMATION

795
845
All dimensions shown in millimeters.
Dimensions shown may vary within permitted tolerances.

BEFORE YOU START

●
Before commencing installation, carefully remove packaging/protective film and check for
damage. If damaged, report immediately to supplier.
●
Check the packs and make sure that you have all parts listed. If not, contact the supplier.
●
Ensure the water feeds and waste connection points are positioned appropriately for the
installation.
●
Care should always be taken when drilling into walls and floors to avoid any sunken wires
or pipes.
●
The bath should be fully protected during the installation process.
●
Please note: Although these instructions are comprehensive, it is always recommended
that a technically competent installer should undertake installation.
Appropriate safety equipment/workwear should be used
10/09/2013
318
398
725
250
348
850
A
Centres of leg adjusters
10:24 Page 2
1695
1695
B
Tempo Arc
Tempo Cube
Figure 1
695
695
(±5)
560
510
A B
400 450
450 520
