- Page 1 SCHWAN SC20 CHILLED FILTERED WATER SC20 Install & User Guide 100% recycled paper...
-
Page 2: Specifications
Specifications Model SC20 Dimensions 410 x 210 x 290 (mm) Weight 12kg Power consumption 120W Temp control AUTO (pre-set) Tank 1.8L (stainless steel) Capacity 4.5 LPH (10 Supply water temperature 4 - 38 Water pressure 140 - 400 kPa Current 0.8A... - Page 3 Water supply must be microbiologically safe. PROPERTY DAMAGE In situations where any water leakage could result in damage to property, the complete Schwan SC20 Installation should be installed over a Drained Safe Tray, plumbed to an appropriate drain.
- Page 4 Installation Unit must be installed by a registered plumber and all work must comply with AS/NZS 3500.1 and AS/NZS 3500.2. Filter and chiller must be protected by a PRV. Chiller must not be hard wired. Tap must be over a drained sink or font. Chiller requires ventilation Filter Copper pipe...
- Page 5 Tap mounting 265mm 135mm 12mm hole in benchtop for tap mounting shaft and 50mm of solid flat sub- strate beneath for tap to clamp to. Both top and bottom mounting surfaces must be flat and smooth. Rubber washer Bench top Rubber washer Plastic washer Steel plate...
- Page 6 Ventilation 125mm air gap around both sides and back of unit for air circulation and cupboard must be ventilated. Front of unit must be placed with enough dis- tance from the door for air to enter the entire radiator, but be as close as possible to vent in kick board.
- Page 7 Water supply Filter Water supply connection is only for use on copper water pipes. For all other pipes use a standard 15mm stop tap and a 1/4inch JG adapter.
-
Page 8: Filter Change
Start-up Open supply valve. Purge air from all water lines by operating valve of gooseneck tap to which chiller is connected. Steady stream assures all air is removed. Connect to electrical power. Filter change Disconnect electrical power. Shut off water supply. Release pressure in water line by operating valve of gooseneck tap to which chiller is connected.
