3.5" WIRELESS REARVIEW SYSTEM
2.4GHz WIRELESS
POWER LEAD
MONITOR
TFT Panel: High Grade (A-Type) Colour LCD
LCD Size: 89mm (3.5-inch) Diagonal
Picture Format: 4:3
Resolution: 480 x 234 Pixels
Contrast: 200:1
Controls: Normal/Mirror/Invert Image
Connection: Cig Power Socket
Input Voltage: DC12V (+/- 20%)
Wireless Frequency: 2.4 GHz
Typical Wireless Range: 20 metres
JS358W
PLUG n PLAY HITCH SYSTEM
IP69
WEATHER
P R O O F
CAMERA
LCD
CAMERA
Lens: 1/4" CMOS
Image Sensor: OC7959
Pixels (PAL): 580 x 540
Viewing Angle: 120°
White Balance: Automatic
Night Vision: 6 IR LED
Ingress Protection: IP67
Power Input: DC9V Battery (not supplied)
Wireless Transmission: 2.4GHz
Mounting: Magnetic/Adhesive or Screw-on
• 20m Typical Range
• Magnetic/Adhesive/Screw-on Cam Mounting
• Normal/Mirror/Invert Image
IR CAMERA
With no wires and no fuss, this
quick & simple plug & play wireless
solution is designed as a universal
hitch
system
to
horse floats, caravans, forklifts
&
other
vehicle
2
suit
trailers,
applications.
YEAR
Advertisement
Table of Contents
Related Manuals for Audioxtra AXIS JS358W
Summary of Contents for Audioxtra AXIS JS358W
- Page 1 JS358W 3.5” WIRELESS REARVIEW SYSTEM PLUG n PLAY HITCH SYSTEM With no wires and no fuss, this quick & simple plug & play wireless solution is designed as a universal hitch system suit trailers, horse floats, caravans, forklifts & other vehicle applications.
- Page 2 Introduction Please read all of the installation instructions carefully before installing the product. Improper installation may void the warranty. Congratulations on purchasing an AXIS Rear View Backup Camera System. With this manual, you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle.
- Page 3 Camera & Monitor Placement Plug monitor into lighter socket Place between ball and hitch Or behind trailer Troubleshooting Static, fuzziness or blue screen on Monitor • Battery may be weak, try an alternative battery. (Please note: 3-5 hrs battery life on camera). •...
