OLYS MPPT3010 User Manual

Functions

1. Suitable for charging 12V lead-acid battery.
2. Mainly suitable for small off-grid solar power generation systems, such as: home solar power generation system, solar RV ,
ships, Communication base station.
3. Function of manually turning off device, which can prolong the life of battery and controller when the equipment is not in use.
4. Three-stage MPPT charging mode,Constant current charge-constant voltage charge-floating charge.
5. Multiple protection functions ensure that the system works properly.
6. This product uses intelligent single-chip microcomputer design, all workflows are controlled by software, can achieve high
precision and high reliability.
7. The charging mode of high efficiency MPPT is adopted to ensure that the battery works in the best state and greatly prolong
the service life of the battery.
8. With overcharge, overdischarge, overload protection, anti-reverse protection and other automatic control

Attentions

The charge regulator is intended for use in photovoltaic systems with 12V nominal voltages, It shall be used
with vented or sealed (VRLA) lead acid batteries only.

Safety Recommendations:

1.Batteries store a large amount of energy. Never short circuit a battery under all circumstances. We recommend
Connecting a use slow acting type, according to the nominal regulator current) directly to the battery terminal.
2.Batteries can produce flammable gases. Avoid making sparks, using fire or any naked flame. Make sure that the battery
room is ventilated.
3.Avoid touching or short circuiting wires or terminals. Be aware that the voltages on specific terminals or wires can
be up to double the battery voltage. Use isolated tools. Stand on dry ground and keep your hands dry.

Installation

MPPT
Solar Charge Controller
User Manual
MPPT3010
Thank you very much for buying our product
thoroughly before using the prouuct
Please installed in the room, avoiding direct-clearance,
do not install in the wet environment, if used outdoors,
please note that waterproof moisture. Please controller
and the batteries installed in the same place, the controller
can be seized Measuring the battery temperature, charge
voltage regulation.
, Please read
