Carrier KGALB0101KIT Installation Instructions

KGALB0101KIT
NOTE: Read the entire instruction manual before starting the
installation

SAFETY CONSIDERATIONS

WARNING
!
FIRE, EXPLOSION, ELECTRICAL SHOCK
HAZARD
Failure to follow this warning could result in personal
injury, death and / or property damage.
Improper installation, adjustment, alteration, service,
maintenance, or use can cause carbon monoxide poisoning,
explosion, fire, electrical shock, other conditions, which
could result in personal injury or death.
distributor or branch for information or assistance. The
qualified installer or agency must use only factory- -
authorized kits or accessories when servicing this product.
Installing and servicing heating equipment can be hazardous due
to gas and electrical components. Only trained and qualified
personnel should install, repair, or service heating equipment.
Untrained personnel can perform basic maintenance functions
such as cleaning and replacing air filters. All other operations
must be performed by trained service personnel. When working
on heating equipment, observe precautions in the literature, on
tags, and on labels attached to or shipped with the unit, and other
safety precautions that may apply.
PART NUMBER
327558--- 101
336996--- 101
327801--- 201
337802--- 201
337803--- 201
IIK--- KGALB--- 04
MULTIPOISE, NON---CONDENSING FURNACES

Installation Instructions

Consult your
Table 1 – Kit Contents
LABEL KIT FOR FIXED SPEED, 2---STAGE
AND VARIABLE SPEED, 33.3 IN (846 MM)
Follow all safety codes. In the United States, follow all safety
codes including the National Fuel Gas Code (NFGC) NFPA No.
54- -2006/ANSI Z223.1- -2009. In Canada, refer to the National
Standard of Canada, Natural Gas and Propane Installation Codes
(NSCNGPIC), CAN/CGA- -B149.1 and .2- -2010.
Wear safety glasses and work gloves. Have a fire extinguisher
available during start- -up, adjustment procedures, and service
calls.
Recognize safety information. This is the safety- -alert symbol
When you see this symbol on the furnace and in instructions or
manuals, be alert to the potential for personal injury.
Understand the signal
CAUTION, and NOTE. The words DANGER, WARNING, and
CAUTION are used with the safety- -alert symbol. DANGER
identifies the most serious hazards which will result in severe
personal injury or death. WARNING signifies hazards which
could result in personal injury or death. CAUTION is used to
identify unsafe practices which would result in minor personal
injury, or product and property damage. NOTE is used to
highlight suggestions which will result in enhanced installation,
reliability, or operation.
INTRODUCTION
This instruction covers the installation of safety, service and
information labels used on Fixed Speed, 2- -speed and
Variable- -speed, 80 AFUE, 33.3- -in. (846mm) high, induced- -
combustion furnaces.
PART NAME
Label, Warning
Label, Clearance, and Warning
Label, Info
Label, Info
Label, Info
Installation Instructions
1
words DANGER, WARNING,
!
!
.
