heat-timer EPU-D Installation And Operation Manual page 43

Heat‐Timer Corp.
Table 2: Temperature Sensor Chart
Temperature
°F
OPEN
‐30
‐20
‐10
0
10
20
25
30
35
40
45
50
55
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
SHORT
Value (Ohms)
°C
150000
‐34 117720
‐29 82823
‐23 59076
‐18 42683
‐12 31215
‐7 23089
‐4 19939
‐1 17264
2 14985
4 13040
7 11374
10 9944
13 8714
16 7653
21 5941
27 4649
32 3667
38 2914
43 2332
49 1879
54 1524
60 1243
66 1021
71
77
82
88
93
99
104
110
116
121
Troubleshooting 43
842
699
583
489
412
349
297
253
217
187
100
059840‐00 Rev. A
