- Page 1 MANUAL IM635 Operation & Installation Manual Model 8512 Series Programmable Switch Units This documentation may not be reproduced in any form, for any purpose unless authorized in writing by Weinschel, a part of API Technologies Corp. Operation & Installation Manual...
-
Page 2: Table Of Contents
MANUAL IM635 Table of Contents Table of Contents............................2 1. Safety Summary ............................6 1.1. Definitions ............................6 1.2. General Precautions ..........................6 1.3. Detailed Precautions ..........................7 1.4. Safety Symbols ............................. 7 1.5. Electrostatic Discharge Sensitive ......................8 2. General Information ............................ 9 2.1. - Page 3 MANUAL IM635 SHOW COUNTER ..........................20 SET COUNTER ............................. 20 6.4. 488.2 Common Commands ........................20 *CLS ..............................20 *IDN? ..............................20 *OPC ..............................21 *OPC? ..............................21 *ESR? ..............................21 *RST ..............................21 *TST? ..............................21 *SRE ..............................22 *SRE? ..............................
- Page 4 MANUAL IM635 MACRO ADD ............................28 MACRO DELETE ........................... 28 SHOW MACRO ............................. 29 6.7. Show Commands ..........................29 SHOW BUILD ............................29 SHOW EOS ............................29 SHOW SET ............................29 SHOW USB ............................30 Show GPIB ............................30 SHOW NET ............................30 SHOW IPADDR ............................
- Page 5 MANUAL IM635 8.2. USB Driver Installation ........................40 9. Maintenance ............................. 41 9.1. Inspection ............................41 9.2. Preventative Maintenance ........................41 9.3. Machined Surfaces and Hardware ......................41 9.4. Chassis Cleaning ..........................42 9.5. Connector Cleaning ..........................42 9.6. Line Voltage Fuse Replacement ......................42 10.
-
Page 6: Safety Summary
MANUAL IM635 1. Safety Summary 1.1. Definitions The following definitions apply to WARNINGS, CAUTIONS, and NOTICES found throughout this manual. WARNING: An operating or maintenance procedure, practice, statement, condition, etc., which, if not strictly observed, could result in injury and/or death of personnel. Do not proceed beyond a WARNING symbol until all the indicated conditions have been fully understood and/or met. -
Page 7: Detailed Precautions
MANUAL IM635 Personnel working with or near high voltage should be familiar with modern methods of resuscitation. DO NOT wear jewelry (rings, bracelets, metal watches, and/or neck chains) while working on exposed equipment. Be very cautious about using hand tools near exposed backplanes, bus bars, and/or power supply terminals. -
Page 8: Electrostatic Discharge Sensitive
MANUAL IM635 1.5. Electrostatic Discharge Sensitive The equipment documented in this manual contains certain Electrostatic Discharge Sensitive (ESDS) components or parts. Therefore, certain procedures/steps are identified by the use of the symbol . This symbol is used in two ways: •... -
Page 9: General Information
Weinschel 8512 Series Programmable Switch Units represent a new streamlined approach in programmable switches for bench test and subsystem applications. Standard 8512 Series designs house and control up to 14 failsafe or latching electromechanical switches via front panel controls, Ethernet, USB and Serial communications interfaces. -
Page 10: Installation
Figure-3: Front and Rear Panel of 14 channel module 3.1. Rack Mounting The Model 8512 Series can be mounted in any rack or cabinet that conforms to EIA RS-310 or MIL-STD-189. 3.2. Initial Setup The following initial setup procedures should be performed prior to operating the Model 8512. -
Page 11: Supply Voltage And Fuse
Use a calibrated torque wrench to tighten all RF connections. Based on selected options, a typical Model 8512 Series Switch Unit can contain up to 14 SP6T switches on the front or rear panels and support SMA connections. Connectors are per MILSTD-348 interface dimensions and mate nondestructively per MIL-STD-212. -
Page 12: Remote Operation
MANUAL IM635 4. Remote Operation 4.1. RS-232 Serial The RS232 port is available on a DE9M connector and utilizes three signals: TXD, RXD and GND along with the optional RTS and CTS handshaking signals. The connector pinout is configured as a DTE device, so connections to an external DTE device (such as a PC) would require the use of a null-modem cable. -
Page 13: Serial Console Boot Display
When the system powers up in serial Console mode, if you have a terminal emulator attached to the serial port you should see a screen showing the various installed features and system status. A typical screen is shown below. Tuesday, January 20, 2015 1:11:02 PM API Weinschel 8321 Attn System V1.70 firmware: 19311459318H RF config channel count: 12... -
Page 14: Usb
MANUAL IM635 The TELNET server communicates using the standard port 23 typically used by the TELNET protocol. The implementation is a reduced-functionality version and does not support the full protocol, but it should function properly with many clients. The server only supports a single connection, does not require any login, and does not support options negotiation except for the initial state of the echo setting. -
Page 15: Front Panel Control
MANUAL IM635 5. Front Panel Control 5.1. Navigation The Navigation Control provides for menu selection and data entry. It consists of four navigation keys: UP, DOWN, LEFT, and RIGHT, along with a SET key and a Scroll wheel. Menu selections are made by using the UP and DOWN keys to highlight the current selection as indicated by the selection arrow in the first column of the display. - Page 16 MANUAL IM635 Channels The Channels menu is used to display and change the settings of the RF devices installed in the unit. If multiple types of RF devices are installed, you may be presented with an additional menu allowing you to select between the different device types.
-
Page 17: Command Operation
MANUAL IM635 6. Command Operation 6.1. Application Specific Commands RFSW Function: Sets the [select]ed RF Switch to the chosen [setting]. select setting Syntax: RFSW Select Argument(s): Switch number, 1-n or ALL Setting Switch position, must be valid for selected switch Remarks: This command sets the specified RF switch(s) to the position provided by setting. -
Page 18: Show Rfconfig
MANUAL IM635 SHOW RFCONFIG Function: Displays current RF configuration Syntax: SHOW RFCONFIG SHOW RFCONFIG INSTALL Argument(s): INSTALL optional, displays installation details Remarks: This command displays the current RF hardware configuration. The optional INSTALL argument will display hardware related details as to the device type, connections, etc. Example(s): >show rfconfig RF config... -
Page 19: Set Rfconfig Type Settings
MANUAL IM635 type settings SET RFCONFIG Sets the system configurations to the installed hardware Function: // Selects which device set the selection comes from. CHAN, ATTN, or RFSW Syntax: Type Settings //Sets the configuration to use for the chosen type This command is used to define the RF configuration installed in the unit. -
Page 20: Counter
MANUAL IM635 COUNTER? Function: read an device operations counter Syntax: COUNTER? RFSW select Argument(s): select device select 1-n Remarks: This command returns the current setting of the specified device counter Return Value: number of switching operations Example(s): COUNTER? RFSW 1 // read switch 1 counter value // returns switch 1 counter (518 switching operations) SHOW COUNTER... -
Page 21: Opc
MANUAL IM635 *OPC Function: generate operation complete message Syntax: *OPC Argument(s): none Remarks: The Operation Complete command generates an operation complete message in the Standard Event Status Register when all pending operations have been finished. Return Value: none Example(s): *CLS;*OPC *OPC? Function: Operation complete query... -
Page 22: Sre
MANUAL IM635 *SRE Function: Sets the Service Request Enable Register mask Syntax: *SRE mask Argument(s): byte, 0-255 Remarks: This command sets the Service Request Enable Register. The mask parameter represents the bit values of the register, where a bit value of one indicates an enabled condition and a bit value of zero indicates a disabled condition. -
Page 23: Llo
MANUAL IM635 ERR? 0, "no error" Function: Local lockout enable Syntax: enable Argument(s): byte, 0-1 (or OFF/ON) Remarks: This command controls the local lockout function which can be used to disable front panel control. Setting local lockout ON disables local operation, while setting it OFF enables local use. By default, this parameter is OFF. -
Page 24: Serial Port
MANUAL IM635 SET EOS USB RMT 0x0A0D // set usb output sequence as CR-LF SET EOS TCP PMT 0x0A0D // set tcp socket input to terminate on either CR or SET EOS TCP RMT 0x0D // set tcp output sequence as a single CR character SET EOS UDP PMT 0x0A // set udp socket input to terminate on Lf character only... -
Page 25: Set Gpib Addr [Address]
MANUAL IM635 AutoIP Setting AUTOIP mode will enable the AutoIP function and disable DHCP operation for networks where a DHCP server is not available. The existing static IP address (if any) will be erased. You can also use the SET DHCP and SET AUTOIP commands to combine modes and override the default addressing mode operation selected by this command. -
Page 26: Set Netmask
MANUAL IM635 SET NETMASK Function: Sets the network IP address subnet mask ipmask Syntax: SET NETMASK ipmask Argument(s): subnet mask, in the form DDD.DDD.DDD.DDD Remarks: This function sets the default IP subnet mask used when static IP addressing is selected. The default value is 255.255.255.0 Return Value: none Example(s):... -
Page 27: Set Tcp Timeout
MANUAL IM635 SET TCP TIMEOUT Function: Sets the TCP server inactivity timeout tout Syntax: SET TCP TIMEOUT tout Argument(s): inactivity timer value, in seconds (0 - 60) Remarks: This function sets the value of the TCP server inactivity timeout parameter. The TCP server uses this setting in order to automatically close a connection if the client is inactive for a period of time. -
Page 28: Set Netstat
MANUAL IM635 SET NETSTAT Function: network status message events control enable Syntax: SET NETSTAT enable Argument(s): byte, 0-1 (or OFF/ON) Remarks: This function can be used to control the display of network status messages on the serial console, including link up/down and port connect/disconnect messages. A value of 0 (or OFF) disables messages, while any other value (or ON) enables them. -
Page 29: Show Macro
MANUAL IM635 SHOW MACRO Function: display macro contents Syntax: SHOW MACRO Macro Example: // Here we create a poweron macro to change the default setting of four rf switches, RFSW 1-RFSW 4 // after setting the defaults, adding a *RST will reinitialize the RF hardware to the new default values MACRO OPEN // open macro for editing... -
Page 30: Show Usb
MANUAL IM635 Syntax: Show Set Argument(s): none Remarks: Outputs a list of all the current settings for various set commands. Returns: Various Example(s): >show set serial baudrate: 115200 IP address = 10.0.0.2 subnet mask = 255.255.255.0 gateway = 0.0.0.0 addr_conf = 0x03 (DHCP) tcp keepalive timeout = 30 server port = 10001 telnet_conf =... -
Page 31: Show Ipaddr
MANUAL IM635 SHOW IPADDR Function: Shows IP address mode and status Example(s): // Example #1: SET IPADDR DHCP status: no DHCP server found, using AUTOIP >show ipaddr IP address : 169.254.127.57 subnet mask: 255.255.0.0 default IP : 0.0.0.0 DHCP client: enabled server IP: none detected addr stat: not bound AutoIP client: enabled... -
Page 32: Show Net Udp
MANUAL IM635 port 10001: socket 1 connected to 10.100.103.113 SHOW NET UDP Function: Shows UDP server settings/status Example(s): >show net udp udp server port: 20000 SHOW NET TELNET Function: Shows TELNET server settings/status Example(s): >show net telnet timeout: 300 flags echo: 1 keepalive: 1 neg options: 1... -
Page 33: Delay
MANUAL IM635 mode enables the console, and =3 disables the console. Modes 0 and 1 (OFF and ON) update the nvm setting, while modes 2 and 3 (ENABLE and DISABLE) do not. Return Value: none Example(s): USB CONSOLE ON // turns on the USB console and updates nvm setting USB CONSOLE ENABLE // turns on USB console for this session only USB CONSOLE 0... -
Page 34: Time
MANUAL IM635 TEMP? 30.0 TIME? Function: reads execution time Syntax: TIME? Argument(s): none Remarks: This function returns the current execution time from the start of the command message, in msecs. Return Value: msecs integer32 Example(s): CMDSTATS 0; TIME?; DELAY 10; TIME 1;11 TIMESTAMP TIMESTAMP? -
Page 35: Factory Preset
MANUAL IM635 FACTORY PRESET FACTORY PRESET VERIFY Function: Sets all NVM parameters to their factory default setting. Syntax: FACTORY PRESET FACTORY PRESET VERIFY Argument(s): none Remarks: The FACTORY PRESET command restores all NVM parameters to the factory default. The default settings will take effect on the next restart. -
Page 36: Instrument Security Procedures For Secure Environments
MANUAL IM635 7. Instrument Security Procedures for Secure Environments This section describes the types of memory and their usage in units based on the 193R-11459 controller board, including the 8320, 8321, and 8331 series. It provides the specific steps required to declassify an instrument through memory clearing or sanitization procedures. - Page 37 MANUAL IM635 4. Write all 0's (0x00) to all locations. Verify the locations contain 0. 5. Write all 1's (0xFF) to all locations. Verify the contents contain 0xFF. Sanitization can be performed using the RS232 serial interface. Connect to the unit as in normal operation and send the command FACTORY SANITIZE.
-
Page 38: Firmware And Drivers
Note: any CRC and version numbers displayed will change depending on the actual data file used. To get into bootloader mode, use the command RUN LOADER from the main application command prompt. API Weinschel Model xxxxx Vx.xx firmware: 19311459xxx >run loader When the bootloader executes in 'loader' mode, you should see a sign-on message similar to: >run loader... - Page 39 MANUAL IM635 Command Definition Allow Configuration word update Allow Data Memory update Blank check Download and program HEX file Download and program with 10 second wait Erase Data Memory Erase Program Memory Reset (reboot) Run application in Program Memory Checksum Program Memory (display only) Checksum Program Memory and update ID locations Since there is limited memory available to the microcontroller, there is only space for a single application.
-
Page 40: Usb Driver Installation
To exit the bootloader and run the main application, use the RN command (or cycle power). When the unit reboots, you should see the new version sign on message. running app... API Weinschel Model xxxxx Vx.xx firmware: 19311459xxx 8.2. USB Driver Installation A signed USB driver is included in the software bundle shipped with the unit. -
Page 41: Maintenance
MANUAL IM635 9. Maintenance The following paragraphs provide general inspection and maintenance guidelines for the unit. 9.1. Inspection Perform a visual inspection in conjunction with the maintenance activities schedule when a malfunction is suspected, or whenever an assembly is removed or replaced. 9.2. -
Page 42: Chassis Cleaning
MANUAL IM635 9.4. Chassis Cleaning Clean chassis using a lint-free cloth moistened with water and mild detergent. For harder to clean areas, such as inside corners of chassis, use a vacuum cleaner. 9.5. Connector Cleaning Where small amounts of rust, corrosion, and/or oxide deposits are present on connectors, clean externally with a soft-bristle brush, aluminum wool, or internally with an acid brush;... -
Page 43: Replacement Parts List And Drawings
MANUAL IM635 10. Replacement Parts List and Drawings The assembly/component locations and schematic diagrams for the Model 8512 are located in the Appendix by the drawing number. Drawing find numbers have also been included in the manuals RPL to help locate components or hardware. -
Page 44: Contacting Weinschel
11.1. Manufacturer Warranty PRODUCTS - Weinschel, a part of API Technologies Corp., warrants each product it manufactures to be free from defects in material and workmanship under normal use and service anywhere in the world. Weinschel’s only obligation under this Warranty is to repair or replace, at its plant, any product or part thereof that is returned with transportation charges prepaid to Weinschel by the original purchaser within TWO YEARS from the date of shipment. -
Page 45: Appendix
MANUAL IM635 12. Appendix 12.1. Revision History Revision Date Description of Changes 8/16/19 ERN19-085 Initial Release The remaining pages of this user manual are reserved for supporting documentation and drawings. Appendix Page 45... - Page 46 MANUAL IM635 Bill of Materials (193-8500-038) REV:C Find No. Part Number Description Count Ref. Deg. Vendor MFG. Part No. 193-8214 ENCLOSURE 193-8196 COVER 193R-11459-038 ASSY, PCB, CONTROLLER, W/BOOTLOADER 001R-740-12 POWER SUPPLY, 12V, 65W, 5.25A 193R-11579-000 ASSY, PCB, 128-BIT I2C DIGITALI/O, 16- PORT 193-8359-1 DISPLAY, LCD, SETUP &...
- Page 47 ACCEPTANCE TEST PROC MODEL 8512 188-002 DISK, MODEL 8512, INCL MANUALS, TOOLS, DRIVERS & SOFTWARE 089-4557 ICD, SWITCH MATRIX, ELECTRICALSPECS MODEL 8512-XX-XX 088-264 PROCEDURE, CREATING MAC ADDRESS LABEL IM635-1 MANUAL, MODEL 8512 SERIES ILLUSTRATIONS PLs & SPECS Appendix Page 47...
- Page 48 A8-J2 (S3) A5-J3 A8-J2 (S4) A5-J4 A8-J2 (S5) A5-J5 A8-J2 (S6) A5-J6 PIN 1 OF CABLE CONNECTOR API Weinschel, Inc. CAGE CODE 93459 MADE IN THE USA W10 THRU W15 MODEL: 8512-C6-XX-F DETAIL E SERNO: XXXX SCALE 2 : 1 ROTATED 90°...
- Page 51 [.53] 13.5 AIR VENT [.53] INTERFACE CONTROL DRAWING UNLESS OTHERWISE SPECIFIED CONTRACT NO. DIMENSIONS ARE IN INCHES API Weinschel, Inc. 30° TOLERANCES ARE: 30° FRACTIONS DECIMALS ANGLES THIS DOCUMENT CONTAINS CONTROLLED TECHNICAL DATA UNDER THE JURISDICTION .XX .01 1/2 ...
