Money Controls ARDAC WACS-2 Specification And Adjustment Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Specification and Adjustment Manual
World Acceptor Cassette System
ARDAC Brand WACS-2
ARDAC-2 Protocol
Money Controls Manual Part Number 44x477
Rev. 8
BANKNOTE ACCEPTORS IN MANY COUNTRIES AROUND THE WORLD

Advertisement

Table of Contents
loading

Summary of Contents for Money Controls ARDAC WACS-2

  • Page 1 Specification and Adjustment Manual World Acceptor Cassette System ARDAC Brand WACS-2 ARDAC-2 Protocol Money Controls Manual Part Number 44x477 Rev. 8 BANKNOTE ACCEPTORS IN MANY COUNTRIES AROUND THE WORLD...
  • Page 2 8. – May 16, 2003 Added references for Smart Cassette and Docking Station. Updated host simulator instructions. Added DB-9 references and general updates. Converted from revision letters to revision numbers to accommodate Money Controls part number system. 44X477 Rev. 8 05/ 16/ 03...
  • Page 3 Money Controls, Inc. who may make copies as needed to support sales efforts or end users of this equipment. Money Controls, Inc. reserves the right to revise the product or contents of this manual at any time without notice or obligation.

  • Page 4: Table Of Contents

    ARDAC WACS-2 Specification and Adjustment Manual Table of Contents TABLE OF CONTENTS..............................0-3 DESCRIPTION AND SPECIFICATIONS....................... 1-1 – W 2 (WACS-2)..............1-1 YSTEM ESCRIPTION ORLD CCEPTOR ASSETTE YSTEM ...................................1-3 ERMINOLOGY ...........................1-4 UBASSEMBLY UMBERS ...........................1-5 HASSIS OUNTING ECOMMENDATIONS ....................................1-5 EATURES ..................................1-7 PECIFICATIONS ..............................1-10...
  • Page 5 ARDAC WACS-2 Specification and Adjustment Manual ..........................4-9 IAGNOSTIC ENCH PERATIONS ..............................4-14 ENSITY ALIBRATION MAINTENANCE................................5-1 ..................................5-1 NTRODUCTION ...................................5-1 DJUSTMENTS .................................5-1 ALIBRATION ....................................5-2 LEANING ................................5-3 LEANING NSTRUCTIONS ...............................5-4 SING A LEANING ARDAC-2 & DIAGNOSTIC INTERFACE ......................6-1 ..................................6-1 NTRODUCTION ....................................6-1 ESCRIPTION ............................6-2...

  • Page 6: Description And Specifications

    Description and Specifications System Description – World Acceptor Cassette System 2 (WACS-2) The Money Controls World Acceptor Cassette System 2 (ARDAC WACS-2) identifies, collects, and stacks paper currency or the equivalent into a secure, lockable, removable cassette stacker. The WACS-2 is a modular system consisting of a note acceptor, cassette stacker, and mounting chassis.
  • Page 7 ARDAC WACS-2 Specification and Adjustment Manual Figure 1-1 WACS-2 System Components 44X477 Rev. 8 05/ 16/ 03...

  • Page 8: Terminology

    For convenience and clarity several terms are used interchangeably throughout this manual. These and other system terms and components are illustrated in Figure 1-1. The terms Money Controls World Acceptor Cassette System 2, ARDAC WACS-2 and System describe the complete system, which includes all three modules (note acceptor, cassette stacker, and chassis).

  • Page 9: Main Subassembly Part Numbers

    Specification and Adjustment Manual Main Subassembly Part Numbers The part numbers for the ARDAC WACS-2 main modules are listed below. Figure 1-1 illustrates these modules and various other subassemblies of the System. Refer to Section 8, Diagrams and Parts Listings for more details parts information.

  • Page 10: Chassis Mounting Recommendations

    Bolt both sides of the chassis to the housing. (Bottom support is not required.) Features The Money Controls World Acceptor Cassette System 2 (WACS-2) has a number of features which minimize the need for maintenance, and simplify installation and operation: MODULAR DESIGN: The acceptor and cassette stacker are easily removed from the chassis.
  • Page 11 ARDAC WACS-2 Specification and Adjustment Manual Figure 1-2 Phantom view: Top, Front, and Sides 44X477 Rev. 8 05/ 16/ 03...

  • Page 12: Specifications

    ARDAC WACS-2 Specification and Adjustment Manual Specifications NOTE SIZE RANGE: 62mm x 120mm to 83mm x 172mm ACCEPTANCE RATE: 95% or better on first insertion with street-grade notes. STACKER CAPACITY: 500 notes, minimum, in street-grade condition. STACKER LOCKS: Dual locks, 0.625" to 1.125" barrel length...
  • Page 13 ARDAC WACS-2 Specification and Adjustment Manual Input Volts VS Input Current Input Voltage Input Volts VS Input Current Chart 1-1 The use of WACS2 with a 12VDC–24VDC supply board operating at 12VDC can create a hazardous condition. This is only when operating at 12VDC.
  • Page 14 ARDAC WACS-2 Specification and Adjustment Manual Figure 1-3 Dimension Drawing (Standard 83mm Note Path System) 44X477 Rev. 8 05/ 16/ 03...

  • Page 15: Connector Description

    The external wiring harness is permanently mounted to the chassis connector, and provides cabling and termination for the power supply, and Host I/O or Money Controls Host Simulator connections. Connector Specifications Figure 1-5 shows the pin-outs of the main chassis to note acceptor connections.

  • Page 16: Main Chassis Connector To System

    ARDAC WACS-2 Specification and Adjustment Manual MAIN CHASSIS CONNECTOR TO SYSTEM WIRING HARNESS PIN # FUNCTION HARNESS COLOR Stacker Present White / Red RS-232 RX Violet Ground Green Memory Button (Smart Only) Blue (Smart only) Ground (Non-Smart only) Green (Non-Smart only)

  • Page 17: Host Interface Connections

    +12 to 24VDC White / Orange Ground Green Money Controls Part Numbers: 35x592 housing with 35x593 pins Figure 1-6 Two pin Power Connector Host Interface Connections The DB-25 connector is used for communication with the host machine and can also be connected to a P.C. so that the acceptor can be run with a Host Simulator program.

  • Page 18: Dip Switch Settings And Functions

    ARDAC WACS-2 Specification and Adjustment Manual Figure 1-8 WACS-2 Diagnostic Interface DIP Switch Settings and Functions The microprocessor board used in the System note acceptor has 1bank of eight DIPswitches. These switches set the System’s operating mode and enable or inhibit acceptance of certain notes. For the location of these DIPswitches, refer to Figure below.
  • Page 19 ARDAC WACS-2 Specification and Adjustment Manual SWITCH BANK 1 SWITCH OFF (Enable) SWITCH ON (Inhibit) SWITCH 1-1 NOTE 1 ACCEPT NOTE 1 INHIBIT NOTE 1 SWITCH 1-2 NOTE 2 ACCEPT NOTE 2 INHIBIT NOTE 2 SWITCH 1-3 NOTE 3 ACCEPT NOTE 3...
  • Page 20 ARDAC WACS-2 Specification and Adjustment Manual ZEALAND NORWAY POLAND RUSSIA 1000 SAUDI ARABIA SINGAPORE SLOVENIA 1000 5000 10,000 SOUTH AFRICA SRI-LANKA 1000 SWEDEN SWITZERLAND TAIWAN TURKEY 50,000 100,000 250,000 500,000 1,000,000 U.A.E. U.S.A. with $2 U.S.A. w/o $2 UGANDA 5,000...

  • Page 21: Host Machine Installation

    WACS-2 systems of the same type. To install Money Controls World Acceptor Cassette System 2 (WACS-2) unit into the host equipment: Fit the chassis into the host equipment and secure it in place by the mounting nuts captive in the chassis body.

  • Page 22: Power Supply And Voltage Requirements

    ARDAC WACS-2 Specification and Adjustment Manual Power Supply and Voltage Requirements The WACS-2 operates from an external regulated 12 to 24 Volt DC power supply. Section 1, Description and specifications, has details on the recommended power requirements. Connection of the WACS-2 System to the Host WACS-2 units connect to the host equipment through the DB-25 or DB-9 connector on the chassis.

  • Page 23: Programming New Firmware Into An Eprom / Flash

    New firmware can be ordered already programmed into an EPROM / FLASH, or delivered by e-mail. If new firmware is required, it must be programmed into a suitable 1 Meg EPROM or FLASH device. Money Controls recommends using the parts listed below.

  • Page 24: Check The Dip Switch Settings And Re-Set As Required

    ARDAC WACS-2 Specification and Adjustment Manual Refer to Figure 2-1 and replace the old EPROM / FLASH with the new one: Make sure all power is disconnected from the bill acceptor. Note the orientation of the EPROM / FLASH and pin-1 notch.
  • Page 25 ARDAC WACS-2 Specification and Adjustment Manual Carefully push the cassette into the chassis until the connector at the back of the acceptor seats properly into the connector at the back of the chassis, and the acceptor-retaining latch on the left side of the acceptor catches the latch on the left side of the chassis.

  • Page 26: System Power-Up

    ARDAC WACS-2 Specification and Adjustment Manual System Power-up NOTE Before applying power to the system, check that there are no notes in the acceptor. Wait until the stacker cycles twice before inserting notes. The stacker punch cycles once at the beginning and once at the end of the power-up self- calibration sequence.

  • Page 27: System Operation

    This section of the manual describes operation of the three system modules and subassemblies. The Money Controls World Acceptor Cassette System 2 (WACS-2) consists of the following three modules, which are mounted and interconnected as shown Figure 3-l.
  • Page 28 ARDAC WACS-2 Specification and Adjustment Manual Figure 3-1 World Acceptor Cassette System 2 44X477 Rev. 8 05/ 16/ 03...

  • Page 29: Operational Notes - Acceptor

    ARDAC WACS-2 Specification and Adjustment Manual Figure 3-2 Removing and Opening Acceptor Operational Notes - Acceptor The note acceptor used in the WACS-2 System is a belt-driven, horizontal note acceptor. The acceptor identifies notes through the use of a Microprocessor controlled, self-calibrating sensing system. Sensors located above and below the note path scan both sides of the note.

  • Page 30: Removal Of The Note Acceptor

    ARDAC WACS-2 Specification and Adjustment Manual Removal of the Note Acceptor The note acceptor positively locks into the System chassis. A spring-loaded release on the left side of the acceptor engages a tab on the chassis to lock the acceptor in place. All connections between the note acceptor and the rest of the System are made or broken automatically through a 14-pin connector on the back of the note acceptor and its mate on the chassis.
  • Page 31 ARDAC WACS-2 Specification and Adjustment Manual Figure 3-3 Cassette Drive-Down and Punch Mechanisms Opening The Cassette Stacker CAUTION DO NOT FORCE THE STACKER COVER WIDE OPEN. Refer to Figure 3-4. Open the stacker cover by lifting the front edge only until the cover is perpendicular to the top of the stacker.
  • Page 32 ARDAC WACS-2 Specification and Adjustment Manual Figure 3-4 Figure 3-5 Maximum Opening Angle Stacker Components Closing and Locking The Cassette Stacker While firmly supporting the cassette stacker, use only fingers to move the front edge of the cover from its open position above the stacker, to its closed position at the top front edge of the stacker.

  • Page 33: Operational Notes - Chassis

    ARDAC WACS-2 Specification and Adjustment Manual Operational Notes - Chassis Like the cassette stacker, the chassis is an electronically passive device. Its main function is to provide alignment and a mounting shell for the acceptor and cassette inside the host. The acceptor and cassette should smoothly slide into the chassis, and easily lock into position.
  • Page 34 ARDAC WACS-2 Specification and Adjustment Manual Power-up Sequence During the power-up sequence, the following occur: Unit checks RAM and ROM for accuracy. The acceptor checks the note path for covered sensors. If a note was stopped in the note path when the system was powered-down, it will cover some of the sensors.
  • Page 35 ARDAC WACS-2 Specification and Adjustment Manual Dual Density Values Dual density calibration values are stored in the EEPROM of the Microprocessor. It is not necessary to recalibrate the optical density values unless: The Microprocessor Board or microprocessor has been replaced.

  • Page 36: System Diagnostics

    IBM-compatible personal computer (PC), 80286, or better, running at 16MHz (minimum). This PC must have one available serial (COM) port capable of running at 19,200 baud. Money Controls ARDAC-2 Host Simulator Software. An extension or adapter cable may be required to connect the 25-pin connector on the chassis to the PC serial port (9-pin or 25-pin).

  • Page 37: Ardac-2 Simulator Connections

    Connect the WACS-2 DB-25 (Or optional DB-9) connector to the computer serial port. Host Software Installation Money Controls will provide a copy of the Money Controls ARDAC-2 Host Simulator software 59x105-3 on 3.5” floppy diskette, CD-ROM or through e-mail to individuals or organizations authorized by Money Controls. Before installation or operation of the Host Simulator, set aside a master copy of the package.

  • Page 38: Running The Host Software

    Running the Host Software Communication Port Settings While the computer’s serial port may support a variety of parameters, the Money Controls ARDAC-2 Host software supports only those parameters detailed as the Diagnostic Communications Parameters in the Specifications table of Section 1, Description and Specifications.

  • Page 39: Host Software Main Screen Display

    Host Software Main Screen Display NOTE The Host Simulator software is based on a program, which is used for several Money Controls products. Some commands and setup options may not pertain to the WACS-2. A screen resembling Figure 4-2 appears on your monitor when the simulator software starts. This is the...
  • Page 40 ARDAC WACS-2 Specification and Adjustment Manual From Host The “From Host” window shows and interprets the characters that are being sent to the acceptor. In addition to characters that the protocol part of the program generates, any character that is typed on the keyboard will be sent to the acceptor.
  • Page 41 ARDAC WACS-2 Specification and Adjustment Manual Figure 4-3 Options Menu Figure 4-4 “F2 for more” Screens 44X477 Rev. 8 05/ 16/ 03...
  • Page 42 ARDAC WACS-2 Specification and Adjustment Manual Figure 4-5 “Message Window” screen STATUS MEANING ELEMENT The stacker is under control of the acceptor. The acceptor is in escrow mode. The acceptor is in debug mode. The host will automatically reconfigure the acceptor on receipt of a request for reconfigure.

  • Page 43: Ardac-2 Host Simulator Set-Up

    ARDAC WACS-2 Specification and Adjustment Manual ARDAC-2 Host Simulator Set-up After the connections have been made, ensure that the note acceptor and cassette are installed and fully seated in the chassis. Then proceed with the following steps: Apply power to the computer. Allow the computer to boot and load operating system.

  • Page 44: Diagnostic (Bench) Mode Operations

    ARDAC WACS-2 Specification and Adjustment Manual Diagnostic (Bench) Mode Operations With Setup mode enabled, the technician can operate the System directly from the P.C. keyboard. The Host software will monitor and control: Monitoring Note Acceptance Calling Up Calibration Voltages Controlling the Note Transport Motor...
  • Page 45 ARDAC WACS-2 Specification and Adjustment Manual To Monitor Note Acceptance: Each time a note is inserted in the note acceptor, the computer display will return one of two message strings. If the note is accepted, the display responds in the following format (actual messages or numbers may...
  • Page 46 ARDAC WACS-2 Specification and Adjustment Manual ERROR MEANING Note Handling Error (improper transportation of note) Stalled motor 2nd note in transport Transport jammed Note position error Long note Short note Host disabled Host has disabled acceptor Stacker cassette full or missing Message sent to host, but no response received.
  • Page 47 ARDAC WACS-2 Specification and Adjustment Manual To Show Calibration Voltages: After communications are established and the acceptor has been enabled, press the V key. A display similar to the one below will appear on the computer display. Ardac OS>>> V Top Vis Voltage = 1.99 Volts (102)
  • Page 48 ARDAC WACS-2 Specification and Adjustment Manual To Show Smart Cassette Data: After communications are established and the acceptor has been enabled, press the “Y” key. A display similar to the one below will appear on the computer display. Chassis SN = 01 3e 1b 52 07 00 00 6a...

  • Page 49: Dual Density Calibration

    Dual Density Calibration Card (Money Controls part number 49x307) is required to perform this calibration procedure. If this card is not available, obtain one from Money Controls before starting this procedure. Please note that the unit is calibrated at the factory and should not need routine re-calibration by the end user.
  • Page 50 ARDAC WACS-2 Specification and Adjustment Manual Using only a Money Controls 49x307 Calibration Card, insert the card into the acceptor. As shown below: The card is drawn into the acceptor and returned after a second. The message “Calibration Passed” and the new calibration values display on the monitor. The unit is calibrated.

  • Page 51: Maintenance

    ARDAC WACS-2 Specification and Adjustment Manual Maintenance Introduction The Money Controls World Acceptor Cassette System 2 (WACS-2) provides maximum performance with a minimum of service and maintenance. Typical maintenance consists of periodic inspection and cleaning Sensor Surfaces Drive Components Note Path Components Adjustments The WACS-2 sensors are self-adjusting and do not require routine electronic calibration.

  • Page 52: Cleaning

    ARDAC WACS-2 Specification and Adjustment Manual Cleaning Banknote handling devices normally build up a film of oil and dirt from the banknotes themselves. The WACS-2 has been designed to operate for extended periods of time between cleanings. If excessive dirt builds up on the transport drive mechanism or sensors, poor acceptance may result.

  • Page 53: Cleaning Instructions

    ARDAC WACS-2 Specification and Adjustment Manual Cleaning Instructions Clean the acceptor and note path as follows: Turn off power to the System. Locate the release tab on the left side the acceptor. Press the tab inward, and while maintaining pressure on the tab, slide the note acceptor out of the chassis (Figure 5-1).

  • Page 54: Using A Cleaning Card

    Insert Money Controls 49X315 cleaning card while holding end of cleaning card firmly. The motors should run for a couple of seconds. Do not allow the entire card to be pulled inside machine.

  • Page 55: Ardac-2 & Diagnostic Interface

    ARDAC WACS-2 Specification and Adjustment Manual ARDAC-2 & Diagnostic Interface Introduction The DB-25 (DB-9 optional) interface connector provides interface to the WACS system communication lines. This interface is used by the host machine and can also be used to run the acceptor on a test bench with a computer running a host simulator program.

  • Page 56: Communications Parameters

    Specification and Adjustment Manual Communications Parameters While the computer’s serial port may support a variety of parameters, the Money Controls ARDAC-2 interface supports only those parameters detailed as the Diagnostic Communications Parameters in the Specifications table of Section 1, Description and Specifications. Make sure the simulator software sets the computer’s serial port for the specified parameters.

  • Page 57: Bench Mode Using Diagnostic Connector

    ARDAC WACS-2 Specification and Adjustment Manual Bench Mode using Diagnostic Connector The host simulator program must be loaded onto a computer and set to enter set up mode as listed in section 4 of this manual. A screen similar to the following should appear: World Acceptor/Cassette System: (Copyright (c) 2003 Ardac Inc.)
  • Page 58 ARDAC WACS-2 Specification and Adjustment Manual ACAL = Density auto calibration mode C = caps dump M = Mag calibration P = previous note caps dump R = register dump S = number of points per note V = auto zero voltage dump Y = Read Smart Cassette data (If smart option is installed.)
  • Page 59 ARDAC WACS-2 Specification and Adjustment Manual To Show Smart Cassette Data: After communications are established and the acceptor has been enabled, press the “Y” key. A display similar to the one below will appear on the computer display. Chassis SN = 01 3e 1b 52 07 00 00 6a...

  • Page 60: Recommended Spare Parts And Diagrams

    This section provides service, repair, and recommended spare parts information. The parts diagrams listed in Table 7-1 may be ordered from the Money Controls Service Department. The Money Controls address, phone, and fax numbers are provided in the front of this manual.
  • Page 61 ARDAC WACS-2 Specification and Adjustment Manual Top Sensor Board The top sensor board is located within the lid of the acceptor. The top cover must be removed to gain access to this board. Motor Driver Board The motor driver board is located inside the note acceptor, on the right side of the acceptor (the side containing the motors and drive gears).
  • Page 62 ARDAC WACS-2 Specification and Adjustment Manual Figure 7-2 Exploded view 44X477 Rev. 8 05/ 16/ 03...
  • Page 63 ARDAC WACS-2 Specification and Adjustment Manual MONEY CONTROLS INCORPORATED 88X3327, 88X3328, 88X3337 SERIES PARTS LIST ITEM PART# DESCRIPTION 02X6807 TOP SENSOR PLATE (88X3327, 88X3337) 02X6842 TOP SENSOR PLATE (88X3328) 02X2587-0030 TOP TNT HEAD (88x3327, 88x3337) 02X2587-0032 TOP TNT HEAD (88x3328)
  • Page 64 ARDAC WACS-2 Specification and Adjustment Manual # 10 02X2587-0031 TNT HEAD BOTTOM (88x3327, 88x3337) # 10 02X2587-0033 TNT HEAD BOTTOM (88x3328) # 11 02X6514 REAR NOTE PRESENT LED 02X6513 HARNESS 56X0146 # 12 02X6592 FRONT LED BOARD 02X6423 HARNESS 68X0005...
  • Page 65 ARDAC WACS-2 Specification and Adjustment Manual # 31 17X0874 EMITTER/SENSOR PCB MOUNT # 32 17X1340 LED COVER # 33 17X1346 PULLEY SPACER # 34 17X1350 GRAY SCALE # 35 80X1135 LABEL 12 TO 24VDC # 36 17X1792 EPROM COVER # 37...
  • Page 66 ARDAC WACS-2 Specification and Adjustment Manual 30X276 #6-32 X .19 P.H.M.S INT SEMS PHILLIPS 30X363 M3 6MM LG. P.H.MS. PHILLIPS 30X370 #4-40 X .19 P.H.M.S. W/SEMS PHILLIPS 37X28 FISH PAPER INSULATOR, RIBBON CABLE 85X8 LUBRIPLATE 31X9 WALDES RING (.25 SHAFT) 31X18 WALDES RING (.125 SHAFT)

  • Page 67: Gathering Note Data Using The Wacs-2 System

    Windows Hyper Terminal™ provided with Windows is recommended, but any communications or terminal software, which can log data to disk, may be used. A Money Controls WACS-2 Note Acceptor with standard chassis, as illustrated in Figure 8-1. The WACS-2 includes the note acceptor, stacker and chassis with harness.

  • Page 68: How To Gather Data

    5UR.LFT where 5 is the denomination, UR is for UP-RIGHT and .LFT is for left justified. For further information or assistance in gathering note data, contact: Money Controls at (001) 440-946-3000. 44X477 Rev. 8 05/ 16/ 03...

  • Page 69: Cassette Docking Station System

    Micro Soft Excel Macro Introduction The Cassette Docking Station System is part of the overall Money Controls IBA4 Smart Cassette System. The Docking Stations download data from the Smart Cassette memories and transfer that data into the Docking Station System’s Host Computer. Software in this computer puts the data into a database format that can be used by data analysis programs.

  • Page 70: Docking Station Software

    Windows 95 or Higher Operating System Microsoft Excel, Version 5.0 or Higher Docking Station Software Money Controls provides two software packages for running the Cassette Docking Station System: Installation Software and Operating Software. Installation Software This software is used only when the system is first installed.

  • Page 71: Replacement Of Microprocessor Eprom

    The Money Controls EPROM (57x752) installed in the Docking Station’s Microprocessor board before shipment from the factory, has the latest version of the system firmware installed. If Money Controls upgrades the firmware, it may be necessary to replace the EPROM. When replacing the EPROM, observe the following precautions: Make sure all power is disconnected from the Docking Station..

  • Page 72: Installation Connections

    Table 1 shows the DIPswitch combinations to set each of the sixteen addresses. Installation of Docking Station Host Software Prior to operation of the Docking Station System, the Microsoft Excel program and the Money Controls Docking Station System Software must be installed on the System Host Computer.

  • Page 73: Initial Set-Up: The Chassis Number To Game Id Map

    Smart Cassettes. Refer to Figure B-4: When the Money Controls chassis is manufactured, it is given a unique Smart Chassis ID Number. The chassis is then installed permanently in a specific game. When the cassette and acceptor modules are installed in the smart chassis, the acceptor reads the chassis number and downloads it to the cassette memory.
  • Page 74 ARDAC WACS-2 Specification and Adjustment Manual Chassis Number to Game ID Mapping Procedure The following procedure covers the simplest Docking Station System: one Host Computer connected to one Docking Station. The mapping procedure can also be performed with a multiple docking station system.

  • Page 75: Docking Station System Host Computer- Normal Operation (Host.exe)

    If the Docking Station System has been shutdown, apply power to all of the Docking station and the Host Computer. Start the Host Computer and start the Host.exe program. Most of the functions performed by the Money Controls Docking Station System Host Software are transparent to the user during Normal Operation.

  • Page 76: Docking Station(S) - Normal Operation

    ARDAC WACS-2 Specification and Adjustment Manual Docking Station(s) - Normal Operation Figure B-3 Docking the Cassette Operation of the Docking Station is fully automatic except for insertion and removal of Stacker Cassettes. The Red and Green lights on the Station Control Panels prompt the station operators to insert (green) and remove (red) the cassettes, as the system software requires.

  • Page 77: Micro Soft Excel Macro

    Once the Money Controls Docking Station System Host Software has placed data into the Docking System database, it can be accessed and analyzed by many means. Money Controls has created a Microsoft Excel spreadsheet macro to access and analyze the stored data.
