- Page 1 SCRIBE-MASTER COPE-PRO Patent No.: GB2441513 Please read these instructions before use.
-
Page 2: Table Of Contents
GUARANTEE _______________________ 16 If you require further safety advice, SPARE PARTS technical information or spare parts, please call Scribe-Master Technical – Spare Parts List ____________________ 17 – Spare Parts Diagram ________________ 18 Support or visit FREQUENTLY ASKED QUESTIONS ____ 19... -
Page 3: Safety
SM/COPE-PRO SAFETY covering to contain long hair. power tool or accessory by cord or pull it to disconnect from the socket. WARNING: 5. Consider working environment. Do Keep cord from heat, oil and sharp not use the product in the rain or in Observe the safety regulations in the edges. - Page 4 SM/COPE-PRO the workbench, with table surface at surfaces are cleaned to remove dirt, Do not switch router on with the cutter touching the workpiece. At the grease, oil and water. approximately hip height. end of the cut, release the router 10.
-
Page 5: Items Enclosed
SM/COPE-PRO ITEMS ENCLOSED ITEMS REQUIRED n Plunge router with suitable collet fitted. n 30mm guide bush. n Suitable workbench, table or mitre saw stand. n Pozi No.2 screwdriver. ® n Handtools. DESCRIPTION OF PARTS (see next page) A Main top plate... - Page 6 SM/COPE-PRO DESCRIPTION OF PARTS DIAGRAM...
-
Page 7: Accessories
SMC/02X1/4HSS Heavy Duty Bag Ref. SM/CBP The carry case is specifically designed for maximum protection and ease of transportation for the Scribe-Master PRO. (Feet need to be removed for transportation). Chop Saw Stand Mounting Kit Ref. SM/MKP The bench mount kit is designed to work with a variety of mitre saw stands. -
Page 8: Assembly
SM/COPE-PRO ASSEMBLY n Check that there is no damage or imperfections on your new jig. n Check that all the components are enclosed. n Please recycle all packaging. n Read all the safety instructions prior to use. Fitting the Feet n Stand the jig on its back end and screw on the six feet. -
Page 9: Jig Overview & Setup Position
SM/COPE-PRO Jig Overview and Setup Position Rear material slide Spelch block lock down knobs Set out channel Comb locking knobs retaining guide Back cut marker Router base plate Rear material slide Rear material slide Combs Comb assembly Letter box slide stops &... -
Page 10: Operation
OPERATION Spelch block not yet in position Fitting the Spelch Block n Prepare a piece of timber 170x25x65mm 6-5/8 x 1 x 2 1/2 inches. to become the spelch block. n Push the spelch block up tight to the spelch block retaining guide. -
Page 11: Setting Up The Workpiece In The Rear Material Slide
Setting up the Workpiece in the Rear Material Slide n Cut an off-cut from the workpiece to be scribed. This should be a square cut and of a size the operator feels comfortable with. (recommend 1-1/2 to 2 inches - 40-50mm wide). n Place the workpiece into the set out channel on the top plate ensuring that the most intricate part is pushed up tight against the... -
Page 12: Aligning The Combs & Comb Assembly
Aligning the Combs and Comb Assembly n Ensure the comb assembly is in the set-up position. (The comb assembly will underline the words “SET-UP” marked on the top plate). n The uppermost lock down bolt should be tightened whilst the lower should be left slightly loose, this allows the combs to be tightened. -
Page 13: Moving The Combs To Cutting Position
Moving the Combs to the Cutting Position n To remove the off-cut of the workpiece from the rear material slide, undo the front lock down knob from the rear material slide and lift out. Loosen the rear knob and slide the rear material slide stop back. -
Page 14: Adding The Workpiece
Adding the Workpiece n Slide the workpiece in between the top plate and the base plate. n Ensure that the most intricate part of the moulding is touching the spacers (opposite side to the roller stops) and the split out block, with the back of the workpiece touching the base plate rubber strips. - Page 15 n The router must be set so that the depth of cut clears the bottom of the workpiece by 2mm. n Move the router baseplate to the left hand side and engage the guide pin against the run in part of the combs (set by the rear material guide stops).
-
Page 16: Accessories
ACCESSORIES Please use only Scribemaster original accessories. Tenon Slide Plate Accessory Ref. SM/TSP The tenon slide plate allows the jig to be used to cut tenons and trenches when the 30mm guide bush and a suitable size cutter is fitted (cutter not included). The accessory is placed onto the lower top plate, and the clamp bar is placed under the lower top plate and held by two machine screws. -
Page 17: Maintenance
MAINTENANCE Please use only Scribemaster original spare parts and accessories. The jig has been designed to operate over a long period of time with a minimum of maintenance. Continual satisfactory operation depends upon proper tool care and regular cleaning. Keep the jig away from direct moisture. Cleaning n Regularly clean the jig with a soft cloth. - Page 18 Please use only Scribemaster original spare parts. SM/COPE-PRO - SPARE PARTS LIST v1.0 01/2015 Qty. Desc. Ref. Base Plate WP-SMP/01 Lower Top Plate WP-SMP/02 Top Plate WP-SMP/03 Rear Material Slide WP-SMP/04 Letter Box Slide WP-SMP/05 Router Base Plate WP-SMP/06 Machine Screw Csk M8 x 45mm Socket S/S...
-
Page 19: Spare Parts Diagram
SM/COPE-PRO - SPARE PARTS DIAGRAM v1.0 01/2015 Please use only Scribemaster original spare parts. SM/MKP Mounting Kit Accessory SM/TSP Tenon Slider Plate Accessory -18-... -
Page 20: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Q. Can the jig deal with out of plumb walls? A. Yes, the jig can be adjusted to cut out of plumb walls. Q Can the jig do back cuts to deal with out of square corners? A. - Page 21 SM/COPE-PRO GUARANTEE REGISTRATION Please cut out and return this slip within 28 days of purchase to register this product for a 12 month guarantee Title _________________________ First Name _________________________ Surname _________________________ Company _________________________ Address1 _________________________ Address2 _________________________ Address3 _________________________ Town...
- Page 22 Thank you for purchasing this product. We are confident it will give you excellent service. WARRANTY DETAILS If your Scribe-Master product becomes defective due to faulty materials or workmanship within 12 months of purchase, we guarantee to replace all defective parts free of charge, or at our discretion, replace the unit free of charge provided that: Proof of the date of purchase is provided.
- Page 23 SM/COPE-PRO TECHNICAL & CUSTOMER SUPPORT Scribemaster Ltd. Unit13, Poulton Close Business Centre Dover CT17 0HL England Tel: 0044(0)1304 204050 info@scribemaster.com www.scribemaster.com...
- Page 24 Scribemaster Ltd. Unit13, Poulton Close Business Centre Dover CT17 0HL England Tel: 0044(0)1304 204050 info@scribemaster.com www.scribemaster.com RECYCLABLE © Copyright Scribemaster 2015. No part of this publication may be reproduced, stored or transmitted in any form without prior permission. Our policy of continuous improvement means that specifications may change without notice. Scribemaster Ltd. cannot be held liable for any material rendered unusable or any form of consequential loss.
