BRB Systems USA TX-101 Instruction Manual

Fully wireless counter release system
Hide thumbs Also See for TX-101:
Table of Contents

Advertisement

Quick Links

Fully Wireless Counter Release System
IMPORTANT:
using this system. Improper use of this system can cause serious injury.

Table Of Contents

(1) Safety Information........................................................................................
(2) Installation......................................................................................................
(3) Set Up
(3.1) Counter Set Up................................................................................
(3.2) Receiver Set Up..............................................................................
(3.3) Transmitter Set Up........................................................................
(3.31) User Modes........................................................................
(4) Operation
(4.1) Counter Operation..............................................................
(4.2) RX-101 Receiver Operation..............................................
(4.3) TX-101 Transmitter Operation.........................................
(5) Counter Codes.....................................................................................................
(6) Maintenance...........................................................................................................
(7) Warranty............................................................................................................
BRB Systems USA Co.
Instruction Manual
Read and understand this manual before assembling, installing or
1
2
4
7
8
10
10
11
16
18
18
21
22
23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TX-101 and is the answer not in the manual?

Questions and answers

Related Manuals for BRB Systems USA TX-101

Summary of Contents for BRB Systems USA TX-101

  • Page 1: Table Of Contents

    (3) Set Up (3.1) Counter Set Up…………………………………………………………………….. (3.2) Receiver Set Up…………………………………………………………………… (3.3) Transmitter Set Up……………………………………………………………… (3.31) User Modes……………………………………………………………… (3.32) TX-101 Transmitter Button Layout Options………….. (4) Operation (4.1) Counter Operation…………………………………………………….. (4.2) RX-101 Receiver Operation………………………………………. (4.3) TX-101 Transmitter Operation………………………………….. (5) Counter Codes………………………………………………………………………………………..

  • Page 2: Safety Information

    Instruction Manual. It is your guide to safe and proper operation of this system.  TX-101 Transmitters are 6V powered by 4 AA batteries. AA batteries are small but powerful and must be treated with respect. Never short the ends of the battery together.
  • Page 3  Disconnect this apparatus from its power source during lightning storms or when unused for extended periods of time.  Use only the attachment parts/accessories supplied by BRB Systems USA Co.  Do not allow liquid entry into the system components.

  • Page 4: Installation

    (2) Installation (2.1) Counter Unit Installation of the Counter should be to the side or rear of the shooting position, in such a place as not to obstruct or distract the shooter. The Counter unit should be mounted either to a post, wall or tree and must be mounted vertically without obstruction between the antenna and the trap house.
  • Page 5 (2.2) RX-101 Receiver Using the cabling as supplied, each RX-101 Receiver should be mounted vertically and within 10ft of the power and release connections of the trap. To lengthen the power/release cabling use a connector that is rated for outdoor use and meets current electrical standards.
  • Page 6 Power From 120Vac Wall Outlet 10ft 120V ac power cord = Receiver power. Plug into GFCI protected 120V outlet. 10ft 2 core cable = trap release connections Trap A. Orientation of wires is not important. 2 pin socket and plug = trap release connections Trap B. Orientation of wires is not important.

  • Page 7: (3.1) Counter Set Up

    (3) Set Up (3.1) Counter Unit Set Up The Counter identity and operation are set via the three 8 position dipswitches. To access the dip switches carefully remove the cover so as not to pull the internal wiring that links between the cover and the enclosure body. Counter Dipswitch Settings Switch numbers are printed on the body of the dipswitch.

  • Page 8: (3.2) Receiver Set Up

    3.2) RX-101 Receiver Set Up The receiver identity and operation are set via the three 8 position dipswitches. Receiver Dipswitch Settings Switch numbers are printed on the body of the dipswitch. CODE The (7) CHN switches must match between TX, RX and Counter- Used to set RF frequency CODE CODE CODE...
  • Page 9 The 7 CHN dipswitches (switches 2-8 of dipswitch SW3) are the primary method of Receiver identification. They set the frequency of the receiver and give 128 possible frequency variations. Using these settings for identification eliminates cross calls between adjacent fields because each field can have a different working frequency. CODE Signal Encoding Dipswitches The CODE dipswitch settings on both the Receiver and Transmitter must match for the system to operate.

  • Page 10: (3.3) Transmitter Set Up

    (3.3) Transmitter Set Up (3.31) User Modes The TX-101 Transmitter and RX-101 Receiver combine to make a multi-purpose trap controller, capable of basic single trap release through more complex sequences of up to 4 traps. Select your required discipline from the list below: ...

  • Page 11: (3.32) Tx-101 Transmitter Button Layout Options

    (3.32) TX-101 Transmitter Button Layout Options Trap Mode - 1Trap Manual or Voice Release Instant or Solo Delay Single Press any A button to release Trap A Following Pairs Skeet/Sporting Mode -2 Traps Use with Solo Delay Manual release Press SEQ Instant or Solo Delay LED lights, buzzer sounds.
  • Page 12 Super Sporting – 3 Traps Manual or Voice Release Instant or Solo Delay Single Press A to release Trap A Pair Press B to release Trap B Press C to release Trap C True Pair Press Pair then Press 2 buttons together of 2 traps required, to release a True Pair Advanced Super Sporting - 3 Traps Manual or Voice Release...
  • Page 13 Quad Sporting– 4 Traps Manual or Voice Release Instant or Solo Delay Single - Target is released when button is released Press and release A to release Trap A Press and release B to release Trap B Press and release C to release Trap C Press and release D to release Trap D True Pair Press 2 buttons together of 2 traps required, to...
  • Page 14 Using the tables and descriptions below as a guide, set your selected discipline and button layout into the TX-101 transmitter. The Transmitter identity and operation are set via the three 8 position dipswitches accessed by removing the battery cover and the batteries.
  • Page 15 CHN Channel Dipswitches The CHN dipswitch settings on both the Receiver and Transmitter must match for the system to operate. These will be preset when the unit is shipped and so under most circumstances should not need you to change them. The 7 CHN dipswitches (switches 2-8 of the top dipswitch) are the primary method of Transmitter identification.

  • Page 16: (4.1) Counter Operation

    (4) Operation Counter Operation Dongles To release a target using the BRB Wired Counter a Dongle must be inserted into the counter socket. If the Dongle is set to Count Up Mode, then the shooter may release 10,000 individual targets before the count will need to be reset. If the Dongle is set to Count Down Mode then then the club will program the required number of individual targets into the Dongle using the clubhouse Console.
  • Page 17 Once the shooter has chosen the mode of operation, the Counter has read the Dongle count and established that count/credit remains, then a target can be released. A target can be released in any way that the TX-101 Transmitter has been set up. Payment When the shooter has finished, the Dongle is removed from the Counter.

  • Page 18: (4.2) Rx-101 Receiver Operation

    TX-101 Transmitter Operation The TX-101 has no power on switch. When you want to use it simply press the appropriate button or sequence of buttons. The unit awakens immediately and releases the target(s).
  • Page 19 Voice Release Operation When either the supplied lapel microphone, or the optional full size microphone are plugged in to the TX-101 Transmitter, the unit automatically recognizes that it is in voice release mode. A target now cannot be released manually.
  • Page 20 2 target user selectable Skeet sequence Release of targets is as follows: “PULL”–1 target is released - BANG - “PULL”–2 target is released. The Skeet button layout on the TX-101 now becomes: Skeet Mode – 2 Traps Voice Release Pair Use with Instant Release...

  • Page 21: Counter Codes

    (5) Counter Codes 0= Reverse connections. In and Out are backwards. Tally Trap Counter only. 2 = Insert Dongle. Ground ID change required. 3= Bad ground ID. Dongle is from another ground. 4= Need 4 characters. If less than 4 characters are input into ground ID. 5= Bad Dongle.

  • Page 22: Maintenance

    (6) Maintenance The rugged manufacture of the BRB TX-101 and RX-101 should ensure many years of trouble free use if it is not abused and given simple maintenance.  Do not allow any component to be immersed in water.  Regularly inspect the power/trap control cords for damage. If any wear or damage is found, replace immediately.

  • Page 23: Warranty

    BRB systems USA Co. does not warrant uninterrupted or error-free operation of the product. BRB Systems USA Co. shall not be liable for loss of revenue or profits, failure to realize savings or other benefits, or any other special, incidental or consequential damages caused by the use, misuse or inability to use this product, regardless of the legal theory on which the claim is based, even if BRB Systems USA Co.
