GolfAchiever II Quick Setup Manual

1. Remove GolfAchiever's components from the
shipping box. Be sure that all components
have arrived safely. A component list appears
on page 7 of the User Manual.
4. Attach the triangle to the L-Frame by first insert-
ing the bottom tab into the notch (inset 1), then
latching the top clamp onto the arm (inset 2).
7. Run the Diagnostics Program. Be sure that all
laser levels are reading above 20. If you find
low readings, go to page 31 of the User Manual
for instructions on Aligning the Lasers.
QUICK SET-UP GUIDE
2. Insert a tee into the mat. Attach the mat to the
Base Holder by placing the "D" cut grooves
found at the top-right and -left side of the mat
onto the "D" shaped tabs of the Base Holder.
5. Place hitting turf into position on the hitting
mat.
8.
After starting the software, you must enter a
player, select a club, select a tee height, select
ball type, select right or left, and then hit the
play button to begin using your GolfAchiever.
3. Attach the GolfAchiever II L-frame to the Base
Holder by placing the base arm into the Base
Holder's ridge. Be certain that the Azimuth pin is
placed securely into the Azimuth Pin Slot (see inset).
6. Install the GolfAchiever and Diagnostics
program on your computer (install CD). After
software installation, attach the power and serial
cables to the L-Frame and your computer.
9. This is what your GolfAchiever II system
should look like when fully assembled. You
are ready to use your new GolfAchiever II.
Set up and swing away!
OVER —>
