GolfAchiever Quick Setup Manual

QUICK SET-UP GUIDE
1. Remove GolfAchiever's components from the shipping
box. Be sure that all components have arrived safely. A
component list appears on page 7 of the User Manual.
3. Install the GolfAchiever and Diagnostics program on your
computer (install CD). After software installation, attach the
serial and power cables to the L-Frame and your computer.
5. Attach the mat-holders to the L-Frame by pushing the
back of the mat holder into the slot on the L-Frame and then
rotating the mat holder 90 degrees. Slide the mat holders to
far opposite ends of the base slot.
2. Attach the triangle to the L-Frame by tightening the thumb
screws (see inset). For a hitting location , be sure that you
place the GolfAchiever on a firm, flat, and level surface.
4. Run the Diagnostics Program. Be sure that all laser levels
are reading above 20. If you find low readings, go to page 31
of the User Manual for instructions on Adjusting the Lasers.
6. Insert a tee into the black hitting mat. Attach the black
mat to the L-Frame via the mat holders. Start with the mat
holder on the outside of the L-Frame, connect it, then slide
the mat onto the other mat holder. Be sure that the mat hold-
ers sit flush into their circular moldings under the mat.
OVER —>
