National Instruments PXIe-6672 Calibration Procedure

CALIBRATION PROCEDURE
NI PXIe-6672
Contents

Conventions

»
This document describes how to write a calibration procedure for the
10 MHz oscillator frequency of the NI PXIe-6672 timing and
synchronization module.
Conventions ............................................................................................ 1
Software .................................................................................................. 2
Documentation ........................................................................................ 2
Calibration Interval ................................................................................. 3
Password ................................................................................................. 3
Test Equipment ....................................................................................... 3
Test Conditions ....................................................................................... 3
Calibration Procedure ............................................................................. 4
Initial Setup...................................................................................... 4
Verification ...................................................................................... 4
Measuring the Frequency ......................................................... 6
Adjustment....................................................................................... 9
Reverification................................................................................... 13
The following conventions apply to this document:
The » symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.
This icon denotes a note, which alerts you to important information.
This icon denotes a caution, which advises you of precautions to take to
avoid injury, data loss, or a system crash. When this symbol is marked on a
product, refer to the Read Me First: Safety and Radio-Frequency
Interference for information about precautions to take.
