Summary of Contents for jobmate YT9108

  • Page 2: Table Of Contents

    CONTENTS Know Your Product....................4 Description of Symbols................... 5 Contents of Petrol Lawnmower................6 General Safety Instructions..................7 Additional Safety Instructions for Petrol Lawnmower..........9 Assembly Instructions....................10 Operation.......................11 Starting the Engine..................12 Stopping the Engine..................12 Tips for Using This Petrol Lawnmower............12 Maintenance......................

  • Page 3: Know Your Product

    KNOW YOUR PRODUCT 1 Height adjustment lever 2 Brake control bar 3 Upper handle 4 Quick release clip 6 Grass catcher 7 Wheel 8 Lower handle 9 Start rope 10 Engine TECHNICAL SPECIFICATIONS Engine: 99cm³, 1.75kW Motor type 4-stroke, air-cooled Displacement 99CC No-load speed...

  • Page 4: Description Of Symbols

    DESCRIPTION OF SYMBOLS SAFETY ALERT SYMBOLS Safety alert symbols are used to draw your attention to possible dangers. These symbols, and their explanations, deserve your careful attention and understanding. The safety warnings do not by themselves eliminate any danger. The instructions or warnings they give are not substitutes for proper accident prevention measures.

  • Page 5: Contents Of Petrol Lawnmower

    DESCRIPTION OF SYMBOLS (CONT.) Very hot surface. Do not touch hot exhaust silencer, gearbox or cylinder. You may burn yourself. These parts become very hot during operation and remain very hot during operation and can remain very hot for a long period even after the equipment has been switched off.

  • Page 6: General Safety Instructions

    GENERAL SAFETY INSTRUCTIONS • Read the operating instructions carefully. Familiarise yourself with the settings and the correct use of the machine. • Never allow children or other persons who are not familiar with the operating instructions to use the machine. Local regulations may stipulate a minimum age for operators.
  • Page 7 GENERAL SAFETY INSTRUCTIONS (Cont.) should wrap completely around the handle. the device if it has not been correctly set up or is not complete or securely assembled. • Take care that the handles are dry and clean and that there is no petrol mix on them.

  • Page 8: Additional Safety Instructions For Petrol Lawnmower

    ADDITIONAL SAFETY INSTRUCTIONS FOR PETROL LAWNMOWER • DO NOT USE ANY FUEL other than that recommended in the operating instructions. Do not use petrol that has not been correctly mixed with 2-stroke engine oil. Otherwise, there is a risk of permanent damage to the motor whereby the manufacturer‘s guarantee will be void.

  • Page 9: Assembly Instructions

    ASSEMBLY INSTRUCTIONS WARNING! Folding or unfolding the handle improperly can damage the cables, causing an unsafe operating condition. • Do not damage the cables when folding or unfolding the handle. • If a cable is damaged, contact an Authorized Service Dealer. 1.Carefully take out the upper handle and lower handle, rotate out the quick release clips on both sides, then assemble them.

  • Page 10: Operation

    ASSEMBLY INSTRUCTIONS (CONT.) 3. Install the whole catcher onto the groove of the back of the deck. Figure 7. 4. Lower the rear door. OPERATION 1. Filling the Engine oil. 1.1 Remove the dipstick (Figure 8.) tube until the oil level reached the Full line the dipstick.

  • Page 11: Starting The Engine

    OPERATION (CONT.) moving blade, causing serious injury. • Stop the engine and wait for all moving parts to stop. Attention! If the engine has been running, the muffler will be hot and can 4. Adjust the cutting height as desired. Figure 10. Starting the Engine time using, thereafter, you only need to press once for the engine to start.

  • Page 12: Maintenance

    OPERATION (CONT.) • Avoid striking solid objects with blades. Never deliberately mow over any object. • If the mower strikes an object or starts to vibrate, immediately stop the engine, disconnect the wire from the spark plug, and examine the mower for damage. •...
  • Page 13 MAINTENANCE (CONT.) Preparation before Maintenance 1. Stop the engine and wait for all moving parts to stop. 2. Disconnect the spark plug wire from the spark plug and hook it onto the retaining post (Figure 14) before performing any maintenance procedure. 3.
  • Page 14 MAINTENANCE (CONT.) reaches the Full line on the dipstick (Figure 18). Do not 5. Install the dipstick securely. 6. Dispose of the use oil properly at a local recycling centre. Replacing the Blade Important: You will need a torque wrench to install the blade properly. If you do not have a torque wrench or are uncomfortable performing this procedure, contact an Authorized Service Dealer.

  • Page 15: Warranty

    WARRANTY POLICY Congratulations on your purchase of Petrol Lawnmower. In order to get maximum benefit from your new purchase, please be aware of the warranty provisions outlined in this document. 2 YEAR [REPLACEMENT/REPAIR] WARRANTY Your Petrol Lawnmower. is guaranteed for a period of 24 months from the original date of purchase.
  • Page 16 Mitre 10 or Mitre 10 MEGA store where the product was purchased from, for the warranty to be applicable. Please retain your Proof of Purchase. Only the original owner is covered by the manufacturer’s warranty and must have purchased the product from a Mitre 10 or Mitre 10 MEGA store in New Zealand. What is not covered under warranty? •...
