- Page 1 Refrigerator user manual Free Standing Appliance English Imagine the possibilities Thank you for purchasing this Samsung product. NW2-FDR_DA68-01868A-26_EN.indd 1 7/3/2019 4:56:58 PM...
- Page 2 Safety information • Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efficiently. • This appliance is not intended for use by persons (including children) with...
- Page 3 • Never start up an appliance showing any signs of damage. If in doubt, consult your dealer. The room must be 1 m³ in size for every 8 g of R-600a refrigerant inside the appliance. The amount of refrigerant in your particular appliance is shown on the identification plate inside the appliance.
- Page 4 Safety information Important safety symbols and precautions: Please follow all safety instructions in this manual. This manual uses the following safety symbols. WARNING Hazards or unsafe practices that may result in severe personal injury, property damage, and/or death. CAUTION Hazards or unsafe practices that may result in severe personal injury and/or property damage.
- Page 5 Severe warning signs for transportation and site WARNING • When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. - Refrigerant leaking from the pipe work could ignite or cause an eye injury.
- Page 6 Safety information • Do not plug several appliances into the same multiple power strip. The refrigerator should always be plugged into its own individual electrical outlet which has a voltage rating that matches the voltage listed on the refrigerator’s rating plate. - This provides the best performance and also prevents overloading of house wiring circuits, which could cause a fire hazard from overheated wires.
- Page 7 • If any dust or water is in the refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of fire. • Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
- Page 8 Safety information • Children should be supervised to ensure that they do not play with the snap rings used for door adjustment or the water tube clips. - There is risk of death by suffocation if a child swallows a snap ring or water tube clip.
- Page 9 Installation cautions CAUTION • Allow sufficient space around the refrigerator and install it on a flat surface. - Keep the ventilation space in the appliance enclosure or mounting structure clear of obstructions. • Allow the appliance to stand for 2 hours before loading foods after installation and turning on.
- Page 10 • If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung Electronics service center. • If any dust or water is in Refrigerator, pull out power plug and contact your Samsung Electronics service center.
- Page 11 • Do not let children step on a drawer. - The drawer may break and cause them to slip. • Do not leave the doors of the refrigerator open while the refrigerator is unattended and do not let children enter inside the refrigerator. •...
- Page 12 Safety information • Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. This may result in an electric shock, fire, problems with the product, or injury. Do not put a container filled with water on the appliance.
- Page 13 • If the interior or exterior LED lamp has gone out, contact your nearest service center. • If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact your Samsung Electronics service center. - Failing to do so may result in an electric or fire hazards.
- Page 14 Safety information Usage cautions CAUTION • Do not re-freeze frozen foods that have thawed completely. Do not place carbonated or fizzy drinks in the freezer compartment. Do not put bottles or glass containers in the freezer. - When the contents freeze, the glass may break and cause personal injury.
- Page 15 - Any changes or modifications performed by a 3rd party on this finished appliance are not covered under Samsung warranty service, nor is Samsung responsible for safety issues that result from 3rd party modifications. • Do not block the air vents inside the refrigerator.
- Page 16 Safety information • When the refrigerator got wet by water, pull out the power plug and contact your Samsung Electronics service center. • Do not strike or apply excessive force to any glass surface. - Broken glass may result in a personal injury and/or property damage.
- Page 17 Cleaning cautions CAUTION • Do not spray water directly on the inside or outside the refrigerator. - There is a risk of fire or electric shock. • Do not use a hair dryer to dry the inside of the refrigerator. •...
- Page 18 Safety information • Do not use abrasive or harsh cleansers such as window sprays, scouring cleansers, flammable fluids, muriatic acid, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on exterior surfaces (doors and cabinet), plastic parts, door and interior liners, and gaskets. - These can scratch or damage the material.
- Page 19 • Cyclopentane is used in the insulation. The gases in the insulation material require a special disposal procedure. Please contact your local authorities in regard to the environmentally safe disposal of this product. • Keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children.
- Page 20 Safety information Saving Energy Tips • Install the appliance in a cool, dry room with adequate ventilation. Ensure that it is not exposed to direct sunlight and never put it near a direct source of heat (a radiator, for example). •...
- Page 21 This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product specific regulatory obligations e.g. REACH, WEEE, Batteries, visit our sustainability page available via Samsung.com...
-
Page 22: Table Of Contents
Reassembling the freezer door (Drawer type) Reassembling the freezer door (Swing type) How to reverse the door (Option) Adjusting the doors Making minor adjustments between doors OPERATING YOUR SAMSUNG Parts and features REFRIGERATOR Using the control panel Controlling the temperature... -
Page 23: Setting Up Your Refrigerator
Setting up your refrigerator Getting ready to install the refrigerator Congratulations on your purchase of this Samsung Refrigerator. We hope you enjoy the state-of-art features and efficiencies that this new appliance offers. Selecting the best location for the refrigerator •... -
Page 24: Installation Of The Water Line
All installations must be in a accordance with local plumbing code requirements. NOTE • Water line Kit and water filter are not covered by Samsung’s Warranty. The manufacturer (or dealer, installer) of them is responsible for any defects and all the loss caused by water filter & water line kit. •... -
Page 25: Using The Water Filter (Not Provided)
NOTE • You can purchase the necessary filter cartridge at the retailer where you purchased this refrigerator. Make sure you buy the SAMSUNG filter cartridge (Replacement cartridge Plastic line (Provided) Filter cartridge No : DA29-10105J) to ensure the best performance. -
Page 26: To Use Without The Water Filter Section
Setting up your refrigerator To use without the water filter section Connecting to the water supply line • Shut off the main water supply line and turn the Ice maker to the 1. Cold Water 5. Compression Sleeve off position. line 6. - Page 27 CAUTION After the water supply has been installed check all the joints to ensure there are no leaks. • Samsung Warranty does not cover THE WATER LINE INSTALLATION. • The cost of the water line installation is at the customers expense, unless the retailer has covered this expense in the delivery charge.
-
Page 28: Setting Up The Refrigerator
Setting up your refrigerator Setting up the refrigerator Now that you have your new Refrigerator installed in place, you are ready to set up and enjoy the features and functions of the appliance. By completing the following steps, your Refrigerator should be fully operational. -
Page 29: Disassembling The Fridge Door
Disassembling the fridge door WARNING Be careful not to drop and scratch the fridge door while removing the fridge door! Socket wrench Top Table 1. Remove the 3 screws holding 2. Disconnect electric wire on 3. Remove the 3 hex bolts that down the top table and the top of the refrigerator. -
Page 30: Disassembling The Freezer Door (Drawer Type)
Setting up your refrigerator Disassembling the freezer door (Drawer type) Middle Hinge 1. Separate the Cap on the 2. Remove the screw attached to the left and right middle hinges Middle Hinge. with a philips screwdriver (+). Remove the 2 hex head bolts attached to the left and right middle hinges with an allen wrench (Ø... -
Page 31: Disassembling The Freezer Door (Swing Type)
Disassembling the freezer door (Swing type) Middle Hinge 1. Separate the Cap on the 2. Remove the screw attached to the left and right middle hinges Middle Hinge. with a philips screwdriver (+). Remove the 2 hex head bolts attached to the left and right middle hinges with an allen wrench (Ø... -
Page 32: Reassembling The Fridge Door
Setting up your refrigerator Reassembling the fridge door 1. Insert and tighten the 2. Insert and tighten the 2 hex 3. Replace the middle hinge screw into the left and right head bolts into the left and cap. middle hinges with a philips right middle hinges with an screwdriver (+). -
Page 33: Reassembling The Freezer Door (Drawer Type)
Reassembling the freezer door (Drawer type) Slot 1. Pull out the rails to the full 2. Hang the freezer door front 3. With the 10 mm wrench, length on each sidle of the onto open slot on the sides. reattach 4 bolts to connect cabinet evenly. -
Page 34: How To Reverse The Door (Option)
Setting up your refrigerator How to reverse the door (Option) Unplug the refrigerator or disconnect the power. 1. Remove 3 screws on the 3. Disassemble 2 connectors. (a 4. Disassemble ground wire by hinge cover. housing and a reed switch) removing 1 screw on each side. - Page 35 12. Separate the Cap of the front 14. Remove 2 bolts of each hinge 16. Separate low hinge shaft leg Cover. (pull out inside of with the 10 mm wrench. by using 5/32” wrench and Cap) disassemble low hinge leg 15.
- Page 36 Setting up your refrigerator 22. Place the hole in the bottom 23. Replace the middle hinge connected to the freezer. of the freezer door over the 24. Insert and tighten the screw into the left and right middle hinges low hinge. with a philips screwdriver (+).
-
Page 37: Adjusting The Doors
Adjusting the doors After putting the doors back on the Refrigerator, make sure the Refrigerator is level so that you can make final adjustments. If the Refrigerator is not level, it will not be possible to get the doors perfectly even. For example, when the left side is lower than the right side, insert a flat-blade screwdriver into a notch on the left control lever, and turn it clockwise or counter clockwise to level the door. -
Page 38: Making Minor Adjustments Between Doors
Setting up your refrigerator Making minor adjustments between doors Remember, a level Refrigerator is necessary for getting the doors perfectly even. If you need help, review the previous section on leveling the Refrigerator. When the left door is When the left door is lower than the right higher than the right door. -
Page 39: Operating Your Samsung Refrigerator
Use this page to become more familiar with the parts and features of the Refrigerator. Fridge Option Freezer Drawer Type Swing Type 1. Water tank 2. Vegetable & Fruit Drawer 3. Shelf 4. Door bin 5. Freezer drawer bin Operating your samsung refrigerator _39 NW2-FDR_DA68-01868A-26_EN.indd 39 7/3/2019 4:57:25 PM... -
Page 40: Using The Control Panel
C is reached or after 2 and a half º hours. Press the E.Saver button for better energy efficiency. If water drops E.Saver appear on the doors, turn the Energy Saver function off. 40_ Operating your samsung refrigerator NW2-FDR_DA68-01868A-26_EN.indd 40 7/3/2019 4:57:25 PM... -
Page 41: Controlling The Temperature
(Blinking will stop when the refrigerator reaches normal temperature. If for some reason it does not stop after a long period of time, contact a Samsung service center.) Setting the fridge temperature If you want to control the fridge temperature, follow as below. - Page 42 (Blinking will stop when the refrigerator reaches normal temperature. If for some reason it does not stop after a long period of time, contact a Samsung service center.) If you want to make ice faster (Controlling the Power Freeze) Press the Power Freeze button.
-
Page 43: Making Ice
3. Put the Ice-cube trays back in position. And close the freezer door. 4. Once the water has become frozen, turn the dials on the Ice cube trays to empty Ice cubes into the storage bin. Operating your samsung refrigerator _43 NW2-FDR_DA68-01868A-26_EN.indd 43 7/3/2019 4:57:27 PM... -
Page 44: Removing And Relocating The Fridge Accessories
• To get the best energy efficiency of this product, please leave all selves, drawers and baskets on their original position like as illustration in page 39. 44_ Operating your samsung refrigerator NW2-FDR_DA68-01868A-26_EN.indd 44 7/3/2019 4:57:29 PM... -
Page 45: Removing The Freezer Accessories
To remove the drawer - Pull the drawer out fully. Tilt up the rear of the bin and lift it out to remove. To relocate the drawer - Place the bin into the rail assembly. Operating your samsung refrigerator _45 NW2-FDR_DA68-01868A-26_EN.indd 45 7/3/2019 4:57:30 PM... -
Page 46: Using The Water Dispenser (Option)
30 %. Overview Press lever Locking device Water tank cap Water tank Water supply device 46_ Operating your samsung refrigerator NW2-FDR_DA68-01868A-26_EN.indd 46 7/3/2019 4:57:31 PM... - Page 47 Fix the water supply device tightly into the fixing hole. The door will not be closed automatically when the water supply device is pulled out for a long time because of cold leaking. Operating your samsung refrigerator _47 NW2-FDR_DA68-01868A-26_EN.indd 47 7/3/2019 4:57:33 PM...
-
Page 48: Cleaning The Refrigerator
Operating your samsung refrigerator Cleaning the refrigerator Caring for your Samsung Refrigerator prolongs the life of your appliance and helps keep it odor and germ free. WARNING • Do not use benzene, thinner, home/car detergent, or Clorox™ to clean the refrigerator. -
Page 49: Replacing The Interior Light
Replacing the interior light LED Lamps To replace the lamps of the refrigerator, contact a local Samsung service center. WARNING • The lamps are not user-serviceable. Do not attempt to replace a lamp yourself. This can cause electric shock. -
Page 50: Troubleshooting
Troubleshooting PROBLEM SOLUTION The Refrigerator does not • Check that the power plug is properly connected. work at all or it does not chill • Is the temperature control on the display panel set to the correct sufficiently. temperature? Try setting it to a lower temperature. •... - Page 51 PROBLEM SOLUTION There is a bad smell in the • Check for spoiled food. Refrigerator. • Foods with strong odors (for example, fish) should be tightly covered. • Clean out your freezer periodically and throw away any spoiled or suspicious food. Frost forms on the walls of •...
- Page 52 CAUTION Clean the ice box if there are some small pieces of ice on the bottom. Throw away the coherent ice if the ice maker is not used for long time. Set “ICE OFF” for saving energy if the ice maker will not be used for long time. If you want to buy and use a tool of shoveling ice, put it into special place of ice box or take it out.
- Page 53 Efective temperature range The refrigerator is designed to operate normally in the temperature range specified by its class rating. (This table is not applicable for Austrailia) Ambient Temperature range ( ° Class Symbol IEC 62552 (ISO 15502) ISO 8561 Extended Temperate +10 to +32 +10 to +32 +16 to +32...
- Page 54 Memo NW2-FDR_DA68-01868A-26_EN.indd 54 7/3/2019 4:57:35 PM...
- Page 55 Memo NW2-FDR_DA68-01868A-26_EN.indd 55 7/3/2019 4:57:35 PM...
- Page 56 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Contact Center Web Site 1300 362 603 (Other) AUSTRALIA www.samsung.com/au/support 1300 425 299 (HHP) 0800 726 786 (All Product)
