Datum Storage Ez2 Drawer Installation Instructions

Hide thumbs Also See for Ez2 Drawer:

Ez2 Drawer Installation Instructions

Lock Optional

Figure B

Figure A

Large Part of

Slide & Bracket

Release Lever

Step 2:

desired location on cabinet with two #10-24 x 1/2" Type 'F'

Phillips Pan Head Screws as shown in Detail C.

Detail C

#10-24 x 1/2"

Screw

Step 1:

Pay close attention to how Slide

properly functions before disassembling to

aid in reassembling later. Remove Large

Part of Slide that is riveted to Bracket by

engaging Release Lever to allow this part to

slide off.

Attach each Bracket with Large Part of Slide to

Bracket

Page 1

Inside of Cabinet

Table of Contents

Do you have a question about the Ez2 Drawer and is the answer not in the manual?

Page 1 Ez2 Drawer Installation Instructions Figure A Large Part of Slide & Bracket Step 1: Pay close attention to how Slide properly functions before disassembling to aid in reassembling later. Remove Large Part of Slide that is riveted to Bracket by engaging Release Lever to allow this part to slide off.
Page 2 Ez2 Drawer Installation Instructions Step 3: Install Drawer by reassembling parts of Slide. Note: Before adding additional drawers or shelves above the drawer just installed, be sure there is clearance for media being stored. Detail E Reassemble Parts of Slide If you need assembly assistance, please contact Customer Service at 1-866-217-0330 (Monday through Friday 8:00 AM - 5:00 PM E.S.T.)
